- Page 2 To User Dear user, thank you for choosing XAG's products. For safety purposes and better user experience, it is highly recommended that you read this manual carefully and strictly follow the instructions hereof. Contact Us Manufacturer: Guangzhou Xaircraft Technology CO., LTD.
-
Page 3: List Of Items
RTK positioning module. Its four knobs and many buttons, specially designed for the XAG agricultural drones, plus WiFi+4G networking and dual SIM dual standby make it possible to operate the farm equipment easily without an app, thus enhancing the efficiency of manual remote operation. - Page 4 Overview ① ② ③ ④ ⑨ ⑤ ⑩ ⑥ ⑦ ⑧ ⑪ ㉑ ⑯ ⑳ ⑫ ⑮ ⑰ ⑬ ⑭ ⑱ ⑲ 1. Antenna 9. Neck Strap Ring 17. SIM1 Card Slot 2. RTK Module 10. Stop Button 18. F3 Knob 3.
-
Page 5: About Buttons
About Buttons Button Operation Description Joystick Self-calibration Mode: next Short Press Stop Button Hover the aircraft; Remote controller goes into manual operation mode Long Press Keep the aircraft on "Auxiliary Mode" or "Autono- mous Mode" Enter/exit Mapping Mode; In Mapping Mode, short press L1 to mark the current position, and short Fn Button Long Press... -
Page 6: Status Indicators
Mapping Mode: Fly to Mark, Mark by Remote Con- Short Press troller L1 Button Auxiliary Mode: proceed with "Auxiliary Mode" Mapping Mode: form a close shape Long Press Auxiliary Mode: Enable "Auxiliary Mode"; Long press again to set the current height as the alti- tude for the auxiliary mode. - Page 7 Description Battery Indicator Single Flashing Green Fast charging Description Mobile Network Indicator Solid Green LAN communication normal Single Flashing Green LAN/WAN communication Solid Yellow LNT mode communication normal Solid Red Communication error SIM card not detected Description Wireless Communication Indicator Solid Green Communication with aircraft normal Single Flashing Green...
-
Page 8: Joystick Mode
Description Function Indicator B Solid Green Manual spray - On Manual spray - Off Single Flashing Yellow Running low on pesticide Buzzer When the buzzer is on, the beep code will tell you the status of the remote controller and the aircraft. - Page 9 Ascend Left Joystick Right Joystick Descend Left Right Chinese Hand (Mode 3) Left Joystick Right Joystick Ascend Descend Left Right Note To access the Joystick Mode, please go to the "XAG One" App - "Remote Controller Details" - "Joystick Settings".
-
Page 10: How To Use
How to Use Install Phone Holder ① Insert the phone holder into the slot; ② Rotate the knob clockwise to tighten the holder. ① ② Charge Connect the Type-C end to the charging port of the remote controller and the USB-A end to the charger. - Page 11 Warning You must charge it with the charging device provided by XAG. Otherwise, you shall be held liable for any product failure or damage arising therefrom. This product is designed for XAG's products only and there is a strong possibility that this device is incompatible with non-XAG products.
- Page 12 Unfold Antennas Spread out the antennas and adjust them to the suitable positions. Rotate the antennas clockwise to adjust the direction. Note Users can adjust the antenna direction to get the strongest signal when piloting the aircraft with the remote controller as the signal strengths vary according to the antennas' positions. The signal between the remote controller and the aircraft is affected by factors such as antenna positions, antenna tightness, obstacles and Wi-Fi signal interference.
- Page 13 1. Open "XAG One" App, tap © on in the upper right corner on "Field" page and select "Add a Device" (or tap on "Me" - "Device" - " © " to add a device).
- Page 14 2. Open "XAG One" App. On the "Field" page, tap on 0 in the upper right corner and select "create a Field". Select © in the bottom right corner to select the remote controller for mapping.
-
Page 15: Firmware Update
Before using the device, if the main screen prompts "New Firmware Available", be sure to update the firmware to the latest version. 1. Open the "XAG One" App and tap on "New Firmware Available" to get to the firmware update screen. -
Page 16: Joystick Calibration
Please follow the steps below to calibrate the joysticks manually or complete the calibration through "Joystick Calibration" under "Remote Controller Details" in the "XAG One" App. How to Calibrate 1. -
Page 17: Specifications
Specifications Model M3ARC3AH Dimensions 170×135×65 mm Operating Frequency SRRC: 2.4000 GHz to 2.4835 GHz; 5.725 GHz to 5.850 GHz Effective Isotropic Radiated Power 2.4 GHz SRRC : ≤ 20 dBm (EIRP) 5.8 GHz SRRC : ≤ 33 dBm GSM 900: 880 – 915 MHz, 925 – 960 MHz; DCS 1800: 1710 –... - Page 18 -20℃ to 25℃ (three months to one year) Ambient Temperature for Storage -20℃ to 45℃ (one month to three months) -20℃ to 55℃ (less than a month) Max. Effective Signal Range 1000 m Charging Voltage/Current 5 V / 2 A, 9 V / 1.5 A, 12 V / 1.5 A Warning Buzzer Supported GPS: L1/L2...
- Page 19 5. To the maximum extent permitted by law, XAG shall not be liable for any loss caused by your use of this product outside this Disclaimer or the instructions in this User Manual.
- Page 20 Otherwise, improper operation may cause injury to user or others, or cause damage to the product and property loss. Safety awareness is of great importance during operation. Do NOT use any components that are not provided or suggested by XAG. Please install and use the product by strictly following XAG's instructions.
- Page 21 This document is subject to update without prior notice. © Guangzhou Xaircraft Technology CO., LTD. All Rights Reserved. All information in this User Manual (including but not limited to any text description, illustrations, photos, methods, processes, etc.) belongs to Guangzhou Xaircraft Technology CO., LTD. and is protected by copyright law. Without written authorization, no individual or institution is allowed to reproduce, extract, translate, distribute, or otherwise reproduce or quote any content hereof.
