- Page 1 Manual No: 577013-869 • Revision: E 2 To 1 Sensor Input Box Installation Guide...
- Page 2 If “lost” equipment is delivered at a later date and is not needed, Veeder-Root will allow a Return to Stock without a restocking fee. Veeder-Root will NOT be responsible for any compensation when a customer chooses their own carrier.
-
Page 3: Table Of Contents
Table of Contents Introduction System Requirements ......................1 Contractor Certification Requirements ................1 Product Marking Information .....................2 Related Documents ....................2 Safety Warnings .......................3 Safety Precautions ......................4 2 to 1 Sensor Input Box Kits .....................4 Installation Sensor Input Box Dimensions ..................5 Installation Procedure .......................5 Field Wiring Connections ....................8 Epoxy Sealing Cable Field Connections .................10 Sensor Setup... -
Page 4: System Requirements
Introduction The Veeder-Root 2 to 1 Sensor Input Box is designed for use in brine filled, double wall dispenser sumps and connects to a sump or position sensitive sump sensor installed on the base of the sump and to a mini-hydrostatic sensor monitoring the interstice brine. -
Page 5: Product Marking Information
RELATED DOCUMENTS Documents Required to Install Equipment This intrinsically safe apparatus is only for use as part of a Veeder-Root Automatic Tank Gauging System (ATG Console with probes and sensors). To install intrinsically safe apparatus, use the specific control drawing that... -
Page 6: Safety Warnings
Introduction Safety Warnings Product Label Contents I.S. CIRCUIT FOR HAZLOC SENSOR F/N 857390-XXX CL I, DIV. 1, GP.D S/N XXXXXX CL I, ZONE 0 -40°C < Ta < +60°C AEx ia IIA Ex ia IIA MANUAL NO. 577013-869 TC=T4 SECURITE INTRINSEQUE Safety Warnings To protect yourself and your equipment, observe the following warnings and important information: WARNING... -
Page 7: Safety Precautions
2 to 1 Sensor Input Box Kits The 2 to 1 Sensor Input Box is available in two kits: • Mini-Hydro and Dispenser Pan/Sump Sensor Kit (P/N 330020-536) Contains Hydrostatic Sensor Form No. 794380-304 and Sump Sensor Form No. 794380-208 •... -
Page 8: Installation
Installation Sensor Input Box Dimensions The Sensor Input Box housing dimensions are shown in Figure 1. sensors\seniodim.eps Figure 1. Sensor Input Box dimensions LEGEND FOR NUMBERED BOXES IN Figure 1 1. Cover screws T-10 Torx (2) 2. 2 Conductor (#22 AWG), PVC jacketed cable (6 ft.) 3. -
Page 9: Figure 2. Sensor Input Box Installation Example
Installation Installation Procedure 3. Note which sensor cord grip entry is marked for the mini-hydrostatic sensor on the label then remove the cover of the Sensor Input Box and set it aside. Keep the o-ring in its groove in the inside of the cover. 4. -
Page 10: Figure 3. Stripping Cable Jacket And Two Conductor Ends
Installation Installation Procedure 5. Push the end of the cable into the box cord grip port labeled mini-hydrostatic sensor and straight into the box until the end reaches the terminal block labeled MINI-HYDROSTATIC SENSOR ONLY. Strip back the ends of the cable jacket and wires as shown in Figure 3. -
Page 11: Field Wiring Connections
Installation Field Wiring Connections CONSOLE ONLY sensors\seniowir.eps Figure 4. Attaching cables to Sensor Input Box Terminals LEGEND FOR NUMBERED BOXES IN Figure 4 1. Position sensitive or sump sensor connects to PAN/SUMP SENSOR ONLY terminal block 2. Cable (connects to TLS console cable in sump junction box) 3. -
Page 12: Figure 5. Sensor Input Box Field Connections
Installation Field Wiring Connections 3. Get a cord grip bushing and nut from the installation kit. Slide the tapered end of the bushing into one of the sump junction box fittings and loosely screw on the cord grip nut. Push the end of the cable from the Sensor Input Box into the loosened cord grip and into the junction box. -
Page 13: Epoxy Sealing Cable Field Connections
Installation Epoxy Sealing Cable Field Connections Epoxy Sealing Cable Field Connections Get the epoxy seal pack from the installation kit and follow the instructions in Figure 6 869-2.eps Figure 6. Epoxy Sealing Wire Connections LEGEND FOR NUMBERED BOXES IN Figure 4 When temperature is below 50°F (10°C), keep resin in a warm place prior to mixing (e.g., in an inside pocket next to body). -
Page 14: Sensor Setup
Sensor Setup TLS-450PLUS Console 1. Navigate to Menu>Setup and touch Devices (Figure 7) and then touch Liquid Sensor (Figure 8). Figure 7. Setup Screen Figure 8. Selecting Device Setup... -
Page 15: Figure 9. Configuring The Device
Sensor Setup TLS-450PLUS Console 2. Select the desired sensor from the bottom device ribbon (7 in the example below) and touch the Enabled radio button configuring it. Figure 9. Configuring the Device 3. In the Address field touch the down arrow and select the sensor’s location on the USM. Figure 10. -
Page 16: Figure 11. Device Label Entered Example
Sensor Setup TLS-450PLUS Console 4. Touch in the Label field and enter on the popup keyboard, the location (up to 20 alphanumeric characters) of the selected Sensor Input Box. Typical entries would be: Dispenser 1 sump or Dispenser 2 sump, etc. (This information will appear on sensor status and sensor alarm reports to make it easier to identify the location of alarms.) Figure 11. -
Page 17: Figure 13. Model Selected Example
Sensor Setup TLS-450PLUS Console 6. Figure 13 shows the Model selected. Figure 13. Model Selected Example In the Category field touch to the down arrow and select the sensor category, in the example in Figure 14, Dispenser Pan. Figure 14. Device Category Selected 8. -
Page 18: Tls-350 Console
Sensor Setup TLS-350 Console TLS-350 Console At the TLS-350 console front panel key pad, press MODE until you see the message: SETUP MODE PRESS <FUNCTION> TO CONT The Liquid Sensor Setup function allows you to enter information about Sensor Input Boxes and their attached sensors installed in the dispenser sumps. -
Page 19: Liquid Sensor Location
Sensor Setup TLS-350 Console you have entered a choice for all positions, press ENTER to confirm your entry. The system displays the following message: SLOT # - X X X X X X X X PRESS <STEP> TO CONTINUE Press STEP. If more than one module is installed, the system automatically advances to the SENSOR CONFIG message for the next module. -
Page 20: Setting Up Additional Liquid Sensors
Sensor Setup TLS-350 Console SETTING UP ADDITIONAL LIQUID SENSORS If you have additional liquid sensors to configure, press STEP, if necessary, until you see the ENTER SENSOR LOCATION message. Press TANK to select another sensor and follow the procedures described above beginning with the section “Liquid Sensor Location”...
