- Page 1 Oil Filtering Machine Model OF-CN-0057 Item 49104 Instruction Manual Revised - 06/14/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model OF-CN-0057 Section Page General Information --------------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------------- 4 - 5 Technical Specifications ------------------------------------------------------------------------------- 6 Installation ----------------------------------------------------------------------------------------------- 6 - 7 Operation -------------------------------------------------------------------------------------------------- 7 - 8 Maintenance ------------------------------------------------------------------------------------------------- 9 Troubleshooting ------------------------------------------------------------------------------------------ 10... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 6: Technical Specifications
Technical Specifications Model OF-CN-0057 Item Number 49104 Power 1/3 HP Electrical 110-120V / 60Hz / 1 Filtering Capacity 3.5 GPM Capacity 57 L / 60.2 QT Net Weight 119.1 lbs. / 54 kgs. Packaging Weight 132.3 lbs. / 60 kgs. -
Page 7: Working Instructions & Operation Flow
Installation 12. After using, the oil hose must be inserted into the hose slot in filtering chamber. 13. Clean up the filter before proceeding filtering. 14. Do not immerse the cable/cord into hot oil. 15. Do not carry out filtering operation if the oil temperature is higher than 160℃ or lower than 120℃. 16. -
Page 8: Operation
Operation • Check the drain valve (6) is tightened to avoid leakage. • Check the power voltage of the working environment complies with the requirement of this manual. Warning: do not direct the nozzle of the oil hose to the operator or the person present. Hot oil may cause severe injury. -
Page 9: Routine Inspection
Maintenance ROUTINE INSPECTION It is necessary to check the machine daily. Check the machine regularly can avoid serious accident happens. Stop using if user feels that there are some problems in the circuit or machine. Check the situation of the machine before or after using every day. -
Page 10: Troubleshooting
Troubleshooting Problem Possible Causes Solution Press the button, the indicator is Power is disconnected. Connect the power. not on and the motor cannot start/ The breaker is not switched on. Switch on the breaker. activate. Overload protection caused by Cool down and press the reset pump seizing. - Page 11 Figure Drawings...
- Page 12 Figure Drawings...
- Page 13 Figure Drawings Description Position Description Position Description Position Selection switch. Circuit breaker. Pre-filtering basket. Working indicator. Drain valve. Filtering mesh net. Motor rotating direction selecting Quick disconnect. Holding ring of filtering paper. rod. Motor reset button cover. Oil hose.
-
Page 14: Parts Breakdown
Parts Breakdown Model OF-CN-0057 49104... - Page 15 Parts Breakdown Model OF-CN-0057 49104 Item No. Description Position Item No. Description Position Item No. Description Position 1/2 Straight Connector (Male AQ199 Oil Tank Assembly for 49104 AQ217 Handle Assembly for 49104 AQ230 Thread) for 49104 Filter Opening Tube Mounting...
-
Page 16: Electrical Schematics
Electrical Schematics Model OF-CN-0057 49104 Description Position Description Position Description Position Pump/Motor 1/3HP, 115/230V, Rocker Switch, 16A, 250VAC Switch, Limit-SPDT 50/60Hz Cord, Plug-Molded, 14-3 Nema Switch, Toggle 3PDT On-Off-On Switch, Limit-SPDT 5-15P... -
