- Page 1 COOL100 Series Villa Elevator Control Panel Starting Guide V1.2 2019.10...
- Page 2 Villa Elevator Control Panel Starting Guide Thank you for purchasing COOL100 Series Villa Elevator Control Panel manufactured by Shenzhen Hpmont Technology Co., Ltd., and hope you can start your cool and wonderful life. Version and Revision Records Version time: 2019/10 Version: V1.2...
-
Page 3: Table Of Contents
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. CONTENTS 1. COOL100 Description ..................1 1.1 Model ..........................1 1.2 Nameplate ........................1 1.3 Installation ........................2 1.4 Wiring ..........................3 1.4.1 Main Circuit ........................4 1.4.2 Safety Circuit ........................5 1.4.3 Inspection Circuit ......................6 1.5 Seperated Inspection Box .................. -
Page 4: Cool100 Description
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 1. COOL100 Description 1.1 Model COOL100-4T7P5 Villa elevator control panel COOL Type = COOL100 Power Supply Voltage 220 - 240VAC = 2 380 - 460VAC = 4 Input Phase Single/three phases input = D... -
Page 5: Installation
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. Optional Functions BRAKE GOV COIL ENCODER COLOUR WIFI FILTER INSTALL COIL BRACKET 110VDC 24VDC YELLOW √: Optional √: Optional √: Optional 24VDC 220VAC SINCOS GREEN /: No /: No /: No... -
Page 6: Wiring
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 1.4 Wiring Brake resistor box Regulator 101 103 FW COM1 L1 L2 L3 N PE Distribution Brake BK+ BK- COOL100 cabinet Brake feedback KBK1 KBK2 301 Encoder Motor wires Regulator Up fina... -
Page 7: Main Circuit
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 1.4.1 Main Circuit The following figure shows as MT700-PG1-ABZ. Single phase input wiring COO L100 MT700- PG1-ABZ Three-phase four-wire input wiring COO L100 MT700- PG1-ABZ Figure 1-2 Main circuit - 4 -... -
Page 8: Safety Circuit
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 1.4.2 Safety Circuit Seperated Inspection Box COOL100 MTCC-MCB-D +24V MTCC-KCB-D STMnA STMn STM1 STM1A Car top emergency stop Front door Back door 118A SJM1 SJM2 hall door hall door Safety gear... -
Page 9: Inspection Circuit
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 1.4.3 Inspection Circuit Seperated Inspection Box COOL100 MODBUS Inspection up NO input Inspection down NO input JX Inspection NC input Car Top MTCC-CTB-C1 Inspection Box Car top inspection MTCC-KCB-R5 Figure 1-4 Inspection circuit Car Top Inspection Function Setting It’s already set by factory, please do not change the parameter at will. -
Page 10: Seperated Inspection Box
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 1.5 Seperated Inspection Box Figure 1-5 Separated inspection box Table 1-1 Separated inspection box description Inspection Box Description With mains electricity: Press and hold the button for 5s, the elevator system starts/turned off. - Page 11 COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. Table 1-2 Key notes for separated inspection box Button Description Language selection: Long press the “MENU” button to enter the language selection interface, then • click the “MENU” button to select the Chinese/English interface language, and after 3s there is no selection to set the current interface language).
-
Page 12: Cool100 Adjustment
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 2. COOL100 Adjustment 2.1 Parameter Setting 1. Make sure the control panel is wired correctly and powered on. Note: Make sure the EPO switch is closed before powering up (EPO switch is set to “l”). - Page 13 COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. Ref. Code Function Recommended Value Remark Door zone signal is set F12.02 MCB X2 terminal function 3 (Door zone) with one sensor and up/down leveling signal is set with two sensors F12.03...
- Page 14 Note: 1. Please see the “COOL100 Series Villa Elevator Control Panel User Manual” for more parameter descriptions. 2. Check the function status of the corresponding terminal. You can check D02.01 (MCB terminal X1 - X16), D02.02 (MCB terminal X17 - 22) and D03.01 (CTB terminal X1 - X14);...
-
Page 15: Motor Parameter Auto-Tuning
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 2.2 Motor Parameter Auto-tuning Asyn. Motor - Parameter Auto-tuning Set F00.07 as 0 (keypad control). Set F10.10 as 1 (static auto-tuning) or 2 (rotation auto-tuning), then press key of keypad to do parameter auto-tuning. The motor does not rotate at static auto-tuning but rotate at rotation auto-tuning. - Page 16 Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide Syn. Motor - Static Auto-Tuning Before do the static auto-tuning, please refer to the table above to set the parameters. Set F00.07 = 1 (distance control), F10.10 = 1 (static angle auto-tuning).
-
Page 17: Shaft Self-Learning
The shaft self-learning can be interrupted in the following cases: 1) The inspection switch switches to normal position, this time alarms self-learning fault. 2) Operation fails. If the shaft self-learning is unsuccessful, you may refer to “COOL100 Series Villa Elevator Control Panel User Manual”. Note Check F19.12, F19.13 to confirm that you learn the correct forced Dec position. -
Page 18: Leveling Method
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide 2.4 Leveling Method When F03.17 (upper and lower leveling adjustment independent enable) = 0, general adjustment leveling parameter is F19.03. When F03.17 (upper and lower leveling adjustment independent enable) = 1, the general upper adjustment leveling parameter is F03.15, and the general down... -
Page 19: Adjustment For Comfortable Feeling
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 2.6 Adjustment for Comfortable Feeling 2.6.1 Start Adjustment 1. How to Set Pretorque Parameter For brake itself, the opening time is different, while the brake response time is affected by the ambient temperature (too high brake coil temperature will cause the brake delayed response), the appropriate increase in curve run delay time F02.01. -
Page 20: Run Adjustment
Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide Ref. Code Function Setting Range Default Remark Define the initial speed of the system starting, the appropriate F02.02 Starting speed 0 - 0.030m/s 0m/s starting speed can overcome the static friction, which can be set to 0.003... -
Page 21: Acc. And Dec. Curve (S Curve) Adjustment
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 2.6.3 Acc. and Dec. Curve (S Curve) Adjustment COOL100 do Acc and Dec in S curve, so that the impact of Acc and Dec will be the minimum, start and stop will be more smooth. - Page 22 Shenzhen Hpmont Technology Co., Ltd. COOL100 Series Starting Guide Ref. Code Function Definition Bit6: Self-driving drive mode 0: Time setting, 50s not leveling drive • 1: Speed setting, after 10s of rolling, the speed is less than • F26.28 Bit7: Emergency beep prompt mode 0: Continuous •...
-
Page 23: Electric Release Function
COOL100 Series Starting Guide Shenzhen Hpmont Technology Co., Ltd. 2.8 Electric Release Function Note: This function should be operated by elevator professionals. In the absence of mains electricity and ARD shutdown or abnormal conditions, the electric release function can be used to realize the jog release to let the car reach the leveling area. - Page 24 The minimum time can be set to 1s. • Please see the "COOL100 Series Villa Elevator Control Panel User Manual" for more parameter descriptions and product details. - 21 -...
