3-2 C 3: N
HAPTER ETWORK
Accessing the User
Interface
I C C
NTERFACE ARD ABLING
To access the UI of the corresponding NAC, connect the following cables
to the NIC's console port.
Callout Number
1
2
3
Description
RJ-45 connector to NIC's console port
DB-25 male connector to modem for remote operations
DB-25 female-to-female null modem adapter to PC or
terminal COM port
