aldes CAR3 Installation Operation & Maintenance

Constant airflow regulator
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Available languages

Available languages

Table of Contents

EN
Installation Operation Maintenance
CAR3
Constant Airflow Regulator
www.aldes-na.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAR3 and is the answer not in the manual?

Questions and answers

Related Manuals for aldes CAR3

Summary of Contents for aldes CAR3

  • Page 1 Installation Operation Maintenance CAR3 Constant Airflow Regulator www.aldes-na.com...

  • Page 2: Airflow Setting

    Each diameter has a unique range for both low- and high-pressure variants. The CAR3-L (low-pressure) is designed for systems with pressures between 0.12 and 1.2 in. w.g. (30 to 300 Pa), and CAR3-H (high- pressure) between 0.4 and 2.8 in. w.g. (100 to 700 Pa). Factory calibration of the CAR3 is available on request.

  • Page 3: Installation

    The CAR3 should be installed in accordance with all applicable building and mechanical codes. If installed in a metal duct or duct collar with a flexible duct connector (listed to UL 2043), the CAR3 must be inserted at least 1.2 times the duct diameter from the flexible duct and/or duct connector.

  • Page 4: Maintenance And Warranty

    ©2020 American ALDES Ventilation Corporation and ©2020 ALDES Canada. Reproduction or distribution, in whole or in part, of this document, in any form or by any means, without the express written consent of American ALDES Ventilation Corporation, is strictly prohibited. The information contained within this document is subject to change without prior written notice.
  • Page 5 Guide d’installation et de maintenance CAR3 Module de régulation de débit d’air FAIT AUX www.aldes.com...

  • Page 6: Réglage Du Débit D'air

    0,12 in. w.g. Chaque diamètre a une gamme unique pour les variantes de basse et de haute pression. Le CAR3-L (basse pression) est conçu pour les systèmes avec des pressions comprises entre 0,12 et 1,2 in. w.g.
  • Page 7 (répertorié selon UL 2043), le CAR3 doit être inséré au moins 1,2 fois le diamètre du conduit à partir du conduit flexible et/ou du connecteur de conduit.

  • Page 8: Entretien Et Garantie

    CAR3. Il n’y a aucun risque de dépôt de poussière ou d’obstruction car le CAR3 n’a pas de voies de ventilation sujettes au colmatage. Si l’application prévue comprend de l’air lourdement chargé...

This manual is also suitable for:

Car3l4r4Car3l5r5Car3l6r6Car3h5r5Car3h4r4Car3h6r6
