Digital multifunction wall control

Advertisement

Quick Links

Model

611242-FC: Digital Multifunction Control with Free Cooling setting

Description

Decora™-style wall mount electronic controller with dehumidistat, compatible with Aldes
HRV and ERV air exchange systems.

Characteristics

Compact and elegant design that fits discretely in every decor
High-accuracy, fast-response humidity sensor
Liquid-crystal display showing the current humidity level, setpoint, and operation mode
4-button keypad to select the mode of operation, the setpoint value, and the fan speed
Blue LED backlight configurable as a night light
Two energy-friendly modes with automatic exchange and exchange-recirculation cycles
Timer-controlled high-speed exchange modes for high occupancy conditions: birthdays, celebrations, etc.

Specifications

Power entry:
Initial relative humidity pression
Relative humidity setting range
Relative humidity display range
Maximum load, high-speed control output:
Maximum load, low-speed control output:
Timer input:
Operating temperature range:
Storage temperature range:
Dimensions:
Digital Multifunction Wall Control
22 to 26 VAC, 60 Hz
± 4%, from 20% to 80% RH at 25°C
10% to 90%
25% to 99% (LO/BAS is displayed if under 25% RH)
10 Watts maximum (0.42 A @ 24 VAC)
0.24 Watts maximum (0.01 A @ 24 VAC)
Compatible with Aldes Timer 611228
0 to 50°C (32 to 122°F)
-20 to 50°C (-4 to 122°F)
Height 102.7 mm, Width 44.3 mm, Depth 28.5 mm
(4.04 in x 1.74 in x 1.12 in)
611242-FC - Installation - R6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 611242-FC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for aldes 611242-FC

  • Page 1 Installation guide Model 611242-FC: Digital Multifunction Control with Free Cooling setting Description Decora™-style wall mount electronic controller with dehumidistat, compatible with Aldes HRV and ERV air exchange systems. Characteristics • Compact and elegant design that fits discretely in every decor •...
  • Page 2 H/E80-HRG, 7292, 7295 H/E80-HF, H/E110-TF, H/E80-HRX H/E80-HR, H/E95, H120, E130-HF H/E130, H/E150, H/E190, H/E215, H/E240-Ri, H/E280 H/E650-Fi, H/E1100-Fi, H/E1600-Fi, H/E1800-Fi H/E650-Ri, H/E1100-Ri, H/ (Light Commercial without E1600-Ri, H/E1800-Ri (Light recirculation kit) Commercial with Recirculation Kit) 611242-FC - Installation - R6...
  • Page 3 7. Connect the power cable of the air exchange system and verify the proper operation of the system. Figure 1 Not used Air exchange system, green Air exchange system, red Air exchange system, COM Air exchange system, 24VAC Figure 2 611242-FC - Installation - R6...
