- Page 1 DIGITAL VIDEO SURVEILLANCE RECORDER Instruction Manual English Version 4.0 SERIES: L500 Series www.lorexcctv.com Series Includes: L504 (4CH); L508 (8CH); L516 (16CH) © Copyright 2007 LOREX Technology Inc.
- Page 2 Thank you for purchasing this Digital Video Surveillance Recorder. Lorex is committed to providing our customers with a high quality, reliable security product. The L500 Series combines advanced performance with easy operation and great economy to offer a whole new class of digital video recorders to 'high end' residential, commercial and industrial CCTV applications.
-
Page 3: Important Safeguards
Important Safeguards Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. - Page 4 Important Safeguards Service 13. Servicing - Do not attempt to service this video 19. Cleaning - Unplug the video product from the wall equipment yourself as opening or removing covers outlet before cleaning. Do not use liquid cleaners or may expose you to dangerous voltage or other aerosol cleaners.
-
Page 5: General Precautions
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge Lorex TECHNOLOGY INC. http://www.lorexcctv.com... -
Page 6: Dvr Features
/ Recovery to ensure the HDD is functioning properly, ultimately prevents losing video data • Browser Based Remote Client: View and control your DVR from any internet connected PC with Internet Explorer (does not require Lorex Client software). • VGA and Composite video outputs for connection to any computer or TV monitor •... -
Page 7: Table Of Contents
Table of Contents Table of Contents Getting Started ..................9 Front Panel - 4 Channel ..............10~13 Front Panel - 8 / 16 Channel ..............14 Back Panel - 4 Channel ..............15~16 Back Panel - 8 / 16 Channel ..............17 Remote Control .................. - Page 8 DDNS SETUP ........................... 63 Troubleshooting ..................64 DVR Specifications - Appendix #1 ............ 65~67 Lorex Client Software Requirements - Appendix #2 ....... 68 Connecting a Slave (Spot-Out) Monitor - Appendix #3 ......69 Connecting Motion / Alarm Device - Appendix #4 ........70 Connecting PTZ Cameras - Appendix #5 ..........
-
Page 9: Getting Started
Getting Started Getting Started The system comes with the following components: DIGITAL VIDEO POWER ADAPTOR SURVEILLANCE RECORDER REMOTE CONTROL HARDWARE & SOFTWARE MANUALS, QUICK START GUIDE & SOFTWARE CD CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE. -
Page 10: Front Panel - 4 Channel
Front Panel - 4 Channel Front Panel - 4 Channel 1. DVD-RW DRIVE - Backup data to a DVD using the Archive menu options. 2. IR LED - Receives the signal from the Remote Control 3. INDICATOR LEDs - Indicates the DVR status: •... - Page 11 Front Panel - 4 Channel Front Panel - 4 Channel 4. PLAYBACK / NAVIGATION CONTROLS - Controls the playback of video, and navigates in the main screen in Menu and Search Modes. • Playback Controls (cont.): REVERSE SPEED BUTTON - Reverses the playback of the currently displayed Video.
- Page 12 PTZ BUTTON - Accesses the PTZ (Pan/Tilt/Zoom) Menu. Refer to the Pan/Tilt/ Zoom menu for options. NOTE: PTZ option will only work with PTZ type cameras (not provided with this unit). Visit the Lorex website at http://www.lorexcctv.com for a full range of Pan/Tilt/Zoom Cameras.
- Page 13 Front Panel - 4 Channel Front Panel - 4 Channel 8. CHANNEL SELECT BUTTONS - Press to select a channel to display in Full Screen Mode. Number of channels will vary by model (4, 8 or 16 Channels). The numbers are also used to enter the Password when logging into the DVR.
-
Page 14: Front Panel - 8 / 16 Channel
Front Panel - 8 / 16 Channel Front Panel - 8 / 16 Channel The front panel options on the 8 and 16 channel versions work in the same way as the 4 channel version, however the placement of the buttons is slightly different. Refer to the descriptions in the Front Panel - 4 Channel section for details on functions. -
Page 15: Back Panel - 4 Channel
Back Panel - 4 Channel Back Panel - 4 Channel 1. BNC VIDEO INPUTS - Channel 1~4 Camera inputs (used to connect Cameras with BNC connection type). Cameras with BNC connections require an additional power adaptor. NOTE: Additional BNC Inputs are available on the 8 and 16 channel models. 2. - Page 16 Back Panel - 4 Channel Back Panel - 4 Channel 7. SPOT OUT - Video Output port to connect the unit to a secondary DVR or TV. Sequences through all channels regardless of the onscreen images. 8. NTSC/PAL SWITCH - Set the unit to either NTSC (North America) or PAL (Europe). 9.
-
Page 17: Back Panel - 8 / 16 Channel
Back Panel - 8 / 16 Channel Back Panel - 8 / 16 Channel The back panel options on the 8 and 16 channel versions work in the same way as the 4 channel version, with two exceptions: • No looping Video Outputs. •... -
Page 18: Remote Control
System Setup Controls Remote Control Listed below is a quick reference for the Remote Control. POWER BUTTON - MENU BUTTON - Turns the system power Opens the Main Menu ON/OFF (system setup) REMOTE ID* - CHANNEL BUTTONS - Configure when using Press select multiple systems.*... -
Page 19: Mouse Control
Mouse Control Mouse Control Connect a mouse to one of the USB ports located on the front of the unit. Mouse Controls The mouse behaves in the same way as a PC mouse - use the Left and Right Buttons to open menus and change options: LEFT BUTTON - RIGHT BUTTON -... -
Page 20: Display Modes
Display Modes Display Modes Initial Loading Sequence • Press the POWER button located on the front panel of the DVR to start the unit. • The DVR will perform a Hard Drive check • The unit will initially load to a split screen view, displaying either 4 or 8 cameras (depending on model). - Page 21 Display Modes Network Connectivity Indicator The Network Indicators appear when a remote connection is made to the unit via the Remote Agent software, or through the Internet Explorer Web Client: • Green: Indicates that the network connection is stable. • Blue: Indicates that the network connection experiencing difficulties.
-
Page 22: Zoom Mode
Display Modes Zoom Mode • Displays the Camera in ZOOM Mode. • Use the Arrow keys to adjust the Zoom location. • Press the Return key to exit ZOOM Mode. Covert Camera Mode • Displays the Camera in Covert Mode. •... -
Page 23: Ptz (Pan/Tilt/Zoom) & Focus Controls
PTZ (Pan/Tilt/Zoom) & Focus Controls PTZ (Pan/Tilt/Zoom) & Focus Controls The PTZ / Focus Menus will only work with PTZ type cameras (not included): PTZ Control Screen Focus Control Screen Press the PTZ Button on the front panel of Press the PTZ Button a second time to the system, or on the Remote Control to access the Focus Control Screen: access the PTZ Control Screen:... -
Page 24: System Power Off
System Power Off System Power Off DVR Shutoff • Press the Power Button on the front panel or remote control for one second to turn off the DVR. • The LED indicators on the front of the System will remain ON. System Shutdown Prompt System Shutoff •... -
Page 25: Search Mode
Search Mode Search Mode Search mode allows you to locate previously recorded video by Date and Time, or by Event Type. • Press the Search Button on the front panel or Remote Control • Enter the User Name and Password (if required). -
Page 26: Search By Event
Search Mode Search By Event Searches the system based on Event Type (Alarm, Motion, Continuous or System). • Press the right arrow button on the front panel or remote control to access the Search By Event screen. • Select From and To dates, Events (Alarm, Continuous, Motion and Other) and Cameras •... -
Page 27: Menu Navigation Controls & Tips
Menu Navigation Controls & Tips Menu Navigation Controls & Tips Menu Navigation Controls Navigation Controls - Move Up/Down/Left/Right. Enter Button - Press this button to select and change the values in a menu option. Return Button - Complete modifications of a menu option; exit a menu Virtual Keyboard Control The Virtual Keyboard control becomes available when keyboard input is needed for entering information such as... -
Page 28: System Setup Controls
Menu Navigation Controls & Tips System Setup Controls • Enter the MENU screen by pressing the MENU button. Enter the password (if required), and select the SYSTEM SETUP option. • Scroll through the 6 options by pressing the UP, DOWN, LEFT and RIGHT buttons on the Front Panel or Remote Control. -
Page 29: Display Menu
Display Menu Display Menu The Display Menu controls: OSD - Onscreen display settings control the camera titles, event indicators, and general screen settings. MONITOR - Display settings for Alarm and Events SEQUENCE (8/16 CH ONLY) - Controls for the display of video images in Sequence Mode SPOT-OUT (8/16 CH ONLY) - Sends camera video to a secondary monitor (by... -
Page 30: Monitor (8/16 Ch Only)
Display Menu OSD (Onscreen Display) • Motion Sensor Display - Turns the display of the Motion Sensor to: - Active: Display motion sensor of motion detection area. - Inactive: Display motion sensor except motion detection area. - Off: No display of motion sensor. •... -
Page 31: Sequence (8/16 Ch Only)
Display Menu SEQUENCE (8/16 CH ONLY) Sets the Sequence Mode for the display of available channels. • Activation - Turns the Sequence ON/ OFF. NOTE: Up to 16 different Sequence Mode settings can be configured, however only ONE can be active at a time. •... -
Page 32: Sequence Setup Mode
Display Menu SEQUENCE SETUP MODE 1. Press the ENTER button. Setup 2. Select the Display Mode (5 different Mode is active. Display Options - Single, Quad, 6, 8A & 8B) / Left Click to change. 3. Press the Number Keys to Select 4. -
Page 33: Spot-Out (8/16 Ch Only)
Display Menu SPOT-OUT (8/16 CH ONLY) Sends the Specified camera video to a secondary Monitor (via the Spot Out Port on the back of the unit). • Check or Uncheck the selected Cameras to have the video sent to a Secondary Monitor in Sequence. -
Page 34: Camera Menu
Camera Menu Camera Menu The Camera Settings and Controls: CAMERA TITLE - Settings for the onscreen display of individual Camera Titles. COLOR SETUP - Color settings for individual cameras. PTZ SETUP - Configuration for PTZ type cameras (not included with the system). MOTION SENSOR - Configuration for Video Motion Detection. -
Page 35: Color Setup
Camera Menu COLOR SETUP Displays the settings for Brightness, Contrast, Tint and Color for individual cameras. • Press the ENTER Button and select a camera. • Set the Brightness, Contrast, Tint and Color for each camera. These settings range 1(low)~100(high) •... -
Page 36: Ptz Properties
Camera Menu PTZ PROPERTIES • Channel No. - Camera Number. • PTZ Driver - The compatible driver selected for the PTZ Camera. • Auto Focus - Sets the Automatic camera focus to ON/OFF. • Auto Iris - Sets the Automatic Shutter to ON/OFF. -
Page 37: Sound Menu
Sound Menu Sound Menu The System Sound settings: AUDIO - Settings for the system Audio for Live and Remote monitoring. BUZZER - Settings for System Buzzer (audible alerts). SOUND • Live Audio - Turns Live System Audio (from the Audio on the terminal) to ON/ OFF. -
Page 38: System Menu
System Menu System Menu The System Setting controls contain: DATE/TIME - Date and Time controls for the system. NETWORK - Network and remote access controls. MAIL - Mail setup USER MANAGEMENT - Controls for system users. SYSTEM MANAGEMENT - System specific settings and controls DATE/TIME •... -
Page 39: Network
Information will need to be assigned manually. • DDNS (Dynamic DNS) - Allows the System to be accessed using a fixed domain (website URL) without entering the IP address. Lorex offers a free DDNS Service http:// ddns.strategicvista.net If you use the DDNS, there is no need to enter the IP Address with every connection. -
Page 40: Network
IP address of the local DNS Server (i.e. local Router). • DDNS Server - Set to the free DDNS Server provided Lorex (ddns.strategicvista.net). • Net Client Port - Default port of 6100. Used for remote connection. • Web Server Port - Default port of 80. -
Page 41: User Management
System Menu USER MANAGEMENT • User setup consists of 3 groups: Administrator, Manager or User. • Up to 7 new users can be added to the system. • ADD - Opens the ADD New User screen to configure the new user settings NOTE: A maximum of 4 users can be remotely connected to the System simultaneously. -
Page 42: System Management
System Menu SYSTEM MANAGEMENT • System Information - Navigate to the PRESS button, and choose ENTER to display the System Information. • System Name - Input a name for the system using the Virtual Keyboard. • FW Update - Navigate to the PRESS button, and choose ENTER to update the System Firmware. -
Page 43: System Management
System Menu SYSTEM MANAGEMENT Firmware Update New firmware is periodically available for download from the www.Lorexcctv.com website. The firmware on the unit can be updated via the USB Port: • Download the new firmware from the website. Copy the files from the PC to the USB Memory Stick. -
Page 44: System Management
System Menu SYSTEM MANAGEMENT Factory Defaults The System can be returned to the Factory default settings: • Select the ‘Factory Defaults’ option by selecting the PRESS button. • Choose OK to reset the unit, or CANCEL to exit without resetting. NOTE: If the System is reset to Factory Defaults, all settings will be lost (except the Date and Time). -
Page 45: Event / Sensor
Event / Sensor Event / Sensor The Event Sensor Setting controls contain: HDD EVENT - Checks the Hard Drive for errors. ALARM IN - Configuration settings for an external Alarm sensor (i.e. Door / Window Sensors). ALARM OUT - Sends a signal to an external device when an alarm is detected. -
Page 46: Alarm Input
Event / Sensor ALARM INPUT Configurations for any external alarm device (i.e. a Door or Window Sensor). Refer to the appendices for hardware configuration details. • Operation - Sets the Alarm Sensor Connection Status (Enable / Disable) for an external alarm (i.e. Door or Window Sensors). -
Page 47: Alarm Out
Event / Sensor ALARM OUT • Duration - Sets the Reacted Relay Time. (5sec~5min or Until key-in) • HDD Event - Turns the Alarm ON/OFF when the Hard Drive experiencing problems. • Alarm - Sends the Alarm Out when an Alarm Event is detected (set to ON/ OFF). -
Page 48: Email Notification
Event / Sensor EMAIL NOTIFICATION • Notification - Sets the E-Mail notification ON/OFF. • HDD Event - A notification is sent if a Hard Drive event is detected (set to ON/ OFF). • Notifications can be enabled for each channel for: Alarm Video Loss Motion can be selected... -
Page 49: Disk Management
Disk Management Disk Management • Record Time Limit - Setup for the Recording Time Limit (between 12 hours ~1 month) NOTE: The Record Time Limit refers to the length of time data will be kept on the drive. For example: The Record Time Limit is set to 7 days. -
Page 50: Recording Menu Controls
Recording Menu Controls Recording Menu Controls • Enter the RECORDING MENU screen by pressing the MENU button. Enter the password, and select the RECORDING MENU option. • Scroll through the 3 options by pressing the UP, DOWN, LEFT and RIGHT buttons on the Front Panel or Remote Control. -
Page 51: Recording Operations
Recording Menu Controls Recording Operations • SCHEDULE MODE- Sets the Scheduled Recording Mode to Daily or Weekly. • PRE EVENT RECORDING - When an alarm is detected, the Pre Alarm will begin recording before the Alarm was detected (retrieved from video cache). The Pre Alarm Recording Time can be set to between 1~5 seconds. -
Page 52: Continuous / Motion Parameter Mode
Recording Menu Controls Continuous / Motion Parameter Mode Parameters for each camera are set by hour using the Time Interval bar. Press the ENTER key to select the Interval Bar, and navigate using the arrow keys. Select an Hour (highlighted in Green), and press ENTER again to open the Camera Settings for the selected hour. -
Page 53: Continuous / Motion Schedule Mode
Recording Menu Controls Continuous / Motion Schedule Mode Sets the Timer or Motion recording for each channel (by hour). Press the ENTER key to enter the Camera Selection window, and navigate using the arrow keys. Select an Hour (highlighted in Green), and press ENTER again to open the settings window. -
Page 54: Alarm Setup Mode
Recording Menu Controls Alarm Setup Mode • PARAMETER MODE - Contains the general recording parameters for each camera • SCHEDULE MODE - Contains the schedule recording settings for each camera. NOTE: Audio Recording ONLY works on Channels 1~4 (4CH) and specified Channels 1~2 (8/16CH). -
Page 55: Alarm Schedule Mode
Recording Menu Controls Alarm Schedule Mode • Sets the Alarm recording for each channel (by hour). • Press the ENTER key to enter the Camera Selection window, navigate using the arrow keys. • Select an Hour (highlighted in Green), and press ENTER to set to Alarm (highlighted) or None (no highlight): NONE ALARM... -
Page 56: Archiving
Archiving Archiving The Archive feature copies data from the Hard Drive to a USB backup media such as a Memory Stick or USB Hard Drive • Enter the ARCHIVING screen by pressing the MENU button. Enter the password, and select the RECORDING MENU option. -
Page 57: Error Messages
Archiving Archiving Options Once the Start Time, End Time and Channel Selections have been completed, select the START Button A Drive Usage report will be displayed: • Amount of space (in MB) needed • Start and End Times for Each Channel, with size of recordings (in MB) •... -
Page 58: Network Connectivity Overview
Network Connectivity Overview Network Connectivity Overview The DVR can be remotely controlled using your existing network and the provided software. 1. Connect the DVR to the Router using the supplied Ethernet Cable. Power the DVR on. NOTE: The DVR must be connected to the router prior to powering on the system. This allows the system to communicate on your network 2. -
Page 59: Ip & Mac Address
Network Connectivity Overview IP & MAC Address The IP & MAC Addresses are necessary for DDNS Setup (for remote access to the DVR). To Locate the System information, Press the ENTER button on the Front Panel or Remote Control while viewing the Cameras. -
Page 60: Setting Up Your Ddns Account
Setting Up Your DDNS Account Lorex offers a free DDNS service for use with your System. A DDNS account allows you to set up a web site address that points back to your Local Network. The following outlines how to set up your free DNS account. - Page 61 Network Connectivity Overview 1. Click the Create New Account link at the bottom of the form to submit your request. 2. Your Account information will be sent to you at the E-mail Address you used in Step 3. Service provider: dns1.strategicvista.net User Name: tomsmith1...
-
Page 62: Router Port Forwarding
Network Connectivity Overview Router Port Forwarding How do I enable Port Forwarding on my Router? You will need to enable port forwarding on your Router to allow for external communications with your DVR for ports: • TCP/IP PORT 6100 • WEB PORT 80 Computers, DVRs, and other devices inside your network can only communicate directly with each other within the internal network. -
Page 63: Ddns Setup
Once the DDNS settings have been configured online, the information must be entered on the DVR to allow for remote connection via the Lorex Client Software (or through Internet Explorer): 1. Access the Main Menu Setup screens, and navigate to the SYSTEM option. Press the ENTER button to access the setup. -
Page 64: Troubleshooting
When a malfunction occurs, it may not be serious and can be corrected easily. The following describes the most common problems and solutions. Please refer to the following before calling Lorex Technical Support: Problem: DVR Unit is not receiving power, or is not powering up Check: •... -
Page 65: Dvr Specifications - Appendix #1
DVR Specifications - Appendix #1 DVR Specifications - Appendix #1 General Specifications Video Standard NTSC / PAL Video Inputs 4 / 8 / 16 BNC @ 1.0Vp-p, CVBS, 75ohms Video Outputs ALL: 1 x Spot Out / 1 x Monitor Out 4 CH ONLY: 4 x CH Loop Out / 1 x VGA Out / 1 x SVHS Out Image Size... - Page 66 DVR Specifications - Appendix #1 DVR Specifications - Appendix #1 Alarm Specifications Alarm Inputs 4, 8 or 16 x TTL, programmable as NC or NO Alarm Outputs 1 x relay with NO/NC Contact 30V DC/1A, 125 VAC/0.5A resistive Activity Detection 16x16 Grid Sensitivity Levels: 10 Covert Camera Operation...
- Page 67 360 mm x 389mm x 66 mm Weight 8.6 lbs 3.9 kg As our products are subject to continuous improvement, Lorex Technology Inc. and its subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE...
-
Page 68: Lorex Client Software Requirements - Appendix #2
* Additional Hard Drive space required for recording. Recorded file size will vary depending on recording quality settings Please refer to the Lorex Client Software User Guide included with your DVR for further details. Visit the Lorex support website at http://www.lorexcctv.com for information on Windows Vista compatibility. -
Page 69: Connecting A Slave (Spot-Out) Monitor - Appendix #3
Connecting a Slave (Spot-Out) Monitor - Appendix #3 Connecting a Slave (Spot-Out) Monitor - Appendix #3 Connections to a Slave Monitor and/or Spot-Out Monitor (not included with the System) can be made through the SPOT OUT, MONITOR OUT, LOOP OUT (4 CH ONLY) and VGA (4 CH ONLY) ports on the back of the DVR. -
Page 70: Connecting Motion / Alarm Device - Appendix #4
Connecting Motion / Alarm Device - Appendix #4 Connecting Motion / Alarm Device - Appendix #4 Motion detection and Alarm controls are enabled through the Menu system on the DVR. Additional motion sensor devices can be connected to the system (Motion Sensors, Door/ Window Sensors). -
Page 71: Connecting Ptz Cameras - Appendix #5
Connecting PTZ Cameras - Appendix #5 Connecting PTZ Cameras - Appendix #5 PTZ Cameras (not included with this system) can be connected to the PTZ Control Block on the back panel of the System. The PTZ Controls are enabled through the Menu system on the DVR. Additional PTZ Cameras are available at http://www.lorexcctv.com Installing a PTZ (RS-445 Type) PTZ Camera: 1. -
Page 72: Full Connectivity Diagram - Appendix #6
Full Connectivity Diagram - Appendix #6 Full Connectivity Diagram - Appendix #6 The following diagram outlines a general set of connections available with the DVR. ROUTER (Not Included) (Not Included) BNC CAMERAS SLAVE / SPOT OUT SENSOR MONITOR (Not Included) (Not Included) -
Page 73: Hard Drive Replacement / Addition - Appendix #7
Hard Drive Replacement / Addition - Appendix #7 Hard Drive Replacement / Addition - Appendix #7 The System comes with a pre-installed Hard Drive, however the unit will work with a replacement single Hard Drive (up to 500GB) and a second Hard Drive. NOTE: Make sure that the System is OFF and the power cable has been disconnected before changing the Hard Drive. -
Page 74: New Hard Drive Format
Hard Drive Replacement / Addition - Appendix #7 New Hard Drive Format The New Hard Drive MUST be formatted. If a new HARD DRIVE is detected, the system will prompt you to FORMAT the drive. If you do not choose to format the HARD DRIVE, the drive will not be detected by the system. -
Page 75: Using The Storage Calculator - Appendix #8
Using the Storage Calculator - Appendix #8 Using the Storage Calculator - Appendix #8 The Storage Calculator application is used to calculate the amount of recording time available on your Hard Drive, based on the System Recording Settings. This application is located on the Software Installation CD (provided with your System) 1. -
Page 76: Recommended System Tips
What are the recommended tips when setting up my system? - Appendix #9 What are the recommended tips when setting up my system? - Appendix #9 There are several tips outlined below that will assist you in setting up your system: Navigating within the System Menu •... - Page 77 What are the recommended tips when setting up my system? - Appendix #9 3. Select the DATE AND TIME Menu. Change the settings by navigating with the UP/DOWN/LEFT and RIGHT arrow keys. Set the following based on your local Time (and Timezone), and set the current date for the system.
-
Page 78: Formatting The Hard Drive
What are the recommended tips when setting up my system? - Appendix #9 Formatting the Hard Drive Formatting the hard drive after changing the date, and before beginning the recording of YOUR data is recommended, as the system is set to Automatically start recording when powered on (continuous recording setting). -
Page 79: Camera Setup
What are the recommended tips when setting up my system? - Appendix #9 Camera Setup Each camera should be assigned a name that corresponds to its use (i.e. Dock1, BackDoor, Cash3, etc.). This name is displayed onscreen, and helps to identify the camera location easily. 1. - Page 80 What are the recommended tips when setting up my system? - Appendix #9 Backing up your System Configurations it is recommended to back up your system configurations to a Memory Stick. Configuring your system to meet your specific needs can be time consuming - having a backup of your settings will allow you to reset your unit with your personalized settings in the event of an unwanted change.
-
Page 81: Listen-In Audio
How many Audio Channels are available Listen-in Audio? - Appendix #10 How many Audio Channels are available Listen-in Audio? - Appendix #10 How do I enable Listen-In Audio, and how do I set the Listen-in channel? Listen-In Audio is the ability to listen to live audio on ONE channel at a time, between channels 1~4 (4CH) or 1~2 (8/ 16CH). -
Page 82: How Do I Playback Previously Recorded Data
How do I playback Previously Recorded Data? - Appendix #11 How do I playback Previously Recorded Data? - Appendix Search mode allows you to locate previously recorded video by Date and Time, or by Event Type. • Press the Search Button on the front panel or Remote Control •... - Page 83 How do I playback Previously Recorded Data? - Appendix #11 Search By Event Searches the system based on Event Type (Alarm, Motion, Continuous or System). • Press the right arrow button on the front panel or remote control to access the Search By Event screen.
-
Page 84: How Do I Set The Auto-Recording To Off? - Appendix #12
How do I set the Auto-Recording to OFF? - Appendix #12 How do I set the Auto-Recording to OFF? - Appendix #12 The system is set to automatically start recording when powered on. You may wish to change these settings to better suit your security needs. These settings can be changed for an individual camera on one time block, or can be set for multiple cameras for multiple time blocks. - Page 85 How do I set the Auto-Recording to OFF? - Appendix #12 Setting Multiple Time Blocks 1. Enter MENU mode by pressing the MENU button on the front panel of the system (or on the Remote Control). Select the RECORD MENU Option. 2.
-
Page 86: Setting Up Remote Viewing - Appendix #13
(for remote viewing outside your network) Network Setup / Remote Access Overview The DVR can be remotely controlled using your existing network and the Lorex NetViewer soft- ware. 1. Connect the DVR to the Router using the supplied Ethernet Cable. Power the DVR on. The DVR must be connected to the router prior to powering on the system. - Page 87 Setting up Remote Viewing - Appendix #13 System - IP & MAC Address The IP & MAC Addresses are necessary for DDNS Setup (for remote access to IP Address the DVR). To Locate the System information, Press MAC Address the ENTER button on the Front Panel or Remote Control while viewing the Cameras.
- Page 88 Setting Up Your DDNS Account Lorex offers a free DDNS service for use with your System. A DDNS account allows you to set up a web site address that points back to your Local Network. The following outlines how to set up your free DNS account.
- Page 89 Setting up Remote Viewing - Appendix #13 1. Click the Create New Account link at the bottom of the form to submit your request. 2. Your Account information will be sent to you at the E-mail Address you used in Step 3. Service provider: dns1.strategicvista.net User Name:...
- Page 90 Setting up Remote Viewing - Appendix #13 Network - Router Port Forwarding You will need to enable port forwarding on your Router to allow for external communications with your DVR for ports: • TCP/IP PORT 6100 • WEB PORT 80 Computers, DVRs, and other devices inside your network can only communicate directly with each other within the internal network.
- Page 91 Once the DDNS settings have been configured online, the information must be entered on the DVR to allow for remote connection via the Lorex Client Software (or through Internet Explorer): 1. Access the Main Menu Setup screens, and navigate to the SYSTEM option. Press the ENTER button to access the setup.
- Page 92 Setting up Remote Viewing - Appendix #13 Lorex NetViewer Software - Connection Manager The Connection Manager contains the setup information to allow the user to remotely connect to the DVR. Adding a Group Group - Right click on ‘Site’ to add a New Group.
- Page 93 Setting up Remote Viewing - Appendix #13 Adding a Site (Individual Unit Configuration) DVR Information - Enter the information specific to the unit: • Name - Enter a name for the unit. • IP / Domain Name - Enter the IP address or Domain Name for the System.
- Page 94 Setting up Remote Viewing - Appendix #13 Lorex NetViewer Software - Remote Connection Once the site setup profile has been created, a connection can then be made to the DVR: 1. Select the Site profile from the Dropdown List. 2. Press the CONNECT button.
