Summary of Contents for Lorex LH050 ECO SERIES

  • Page 1 Instruction Manual LH050 ECO SERIES...
  • Page 3 Instruction Manual LH050 ECO SERIES #LX400066; r. 1.0/26388/26388; en-US...
  • Page 4 Thank you for purchasing this product. Lorex is committed to providing our customers with a high quality, reliable security solution. This manual refers to the following models: LH0504 (4-channel) For the latest online manual, downloads and product updates, and to learn about our complete line of accessory products, please visit our website at: www.lorextechnology.com...

  • Page 5: Table Of Contents

    Step 9: Verify Camera Image ............11 Step 10: Set the Time ..............11 6.10 Default System Password & Port Numbers ........12 6.10.1 Lorex Stratus Connectivity..........12 6.11 Quick Access to System Information ..........12 Mouse Control .................. 13 Remote Control .................
  • Page 6 Table of contents 15.1.3 Configuring Sequence Time ..........37 15.1.4 Changing the Video-out Resolution ........39 15.1.5 Restoring the System’s Resolution if you see a Blank Screen................. 39 15.1.6 Adjusting Menu Transparency ........... 40 15.2 Record ................... 41 15.2.1 Configuring Pre-recording Settings........41 15.2.2 Configuring the Recording Schedule (Continuous, Motion) ................
  • Page 7 18.1 Supported Apps and Platforms ............ 88 18.2 iPhone..................88 18.2.1 Connecting to Your System Using Lorex Eco Stratus ....88 18.2.2 Lorex Eco Stratus Interface ..........91 18.2.3 Taking Screenshots ............91 18.2.4 Taking Manual Recordings ..........92 18.2.5 Using Remote Playback Mode on iPhone ......92 18.2.6 Viewing Screenshots ............
  • Page 8 Lorex Player 11 Interface Overview ..........116 19.2.1 About the Advanced Config Menu........116 19.3 Converting Backed Up Video to AVI Files ........117 Lorex Player for Mac: Viewing Backed up Video on Mac ....... 119 20.1 Opening Individual Video Files........... 119 20.2 Loading Multiple Video Files............

  • Page 9: Important Safeguards

    Important Safeguards In addition to the careful attention devoted to quality standards in the manufacturing proc- ess of your product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to en- sure your enjoyment and proper use of the product and accessory equipment.
  • Page 10 Important Safeguards 5. Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your location, consult your video dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

  • Page 11: Service

    Important Safeguards 17. Camera Installation - Cameras are not intended for submersion in water. Not all cam- eras can be installed outdoors. Check your camera environmental rating to confirm if they can be installed outdoors. When installing cameras outdoors, installation in a sheltered area is required.

  • Page 12: Features

    Features • Tablet / smartphone viewing and playback • Lorex Stratus Connectivity - 3 step setup • 720p Resolution • HDMI cable included for simple connection to HDTVs • Record to included security grade hard drive with no recurring fees •...

  • Page 13: Getting Started (Lh050 Series)

    Getting Started (LH050 Series) The system comes with the following components: DVR (Digital Video Recorder) DVR Docking Stand 12V DC Power Supply USB Mouse Ethernet Cable HDMI Cable Remote Control Quick Start Guides (may not be exactly as shown) Hard drive size, number of channels, and camera configuration may vary by model. Please refer to your package for specific details.

  • Page 14: Front Panel (Lh050 Series)

    Front Panel (LH050 Series) PWR LED: Power indicator LED. HDD LED: Hard disk activity LED. USB Port: Connect a USB mouse (included) or USB flash drive (not included) for data backup or firmware updates. IR Sensor: IR receiver for the remote control. DVR Docking Stand: Holds the DVR in vertical position.

  • Page 15: Rear Panel (Lh050 Series)

    Rear Panel (LH050 Series) USB: Connect the wireless receiver (included). VGA: Connect a VGA monitor (not included) to view the system interface. HDMI: Connect to an HDMI monitor or TV (not included) to view the system interface. LAN: Connect a CAT 5 RJ45 Ethernet cable (included) for local and remote connectivity. DC12V: Connect the included AC power adapter.

  • Page 16: Basic Setup (Lh050 Series)

    Basic Setup (LH050 Series) 6.1 Step 1: Connect the DVR Docking Stand (OPTIONAL) The DVR can be positioned in an upright, vertical position using the included docking stand, or laid horizontally. • For vertical orientation, position the DVR over the docking stand. Push down on the DVR until you hear a “click”.

  • Page 17: Step 3: Connect The Mouse

    Basic Setup (LH050 Series) 6.3 Step 3: Connect the Mouse • Connect a USB mouse (included) to the front USB port. 6.4 Step 4: Connect the Ethernet cable • Connect an Ethernet cable (included) to the LAN port on the rear panel of the DVR. Connect the other end of the Ethernet cable to a router on your network.

  • Page 18: Step 5: Connect The Monitor

    Basic Setup (LH050 Series) 6.5 Step 5: Connect the Monitor • Connect the included HDMI cable from the HDMI port to the TV or monitor (recommended) OR; • Connect a VGA cable (not included) from the VGA port to the monitor. 6.6 Step 6: Connect the Power Adapter and Turn On the DVR •...

  • Page 19: Step 9: Verify Camera Image

    Basic Setup (LH050 Series) If a firmware upgrade is available: 1. After startup, a notification will appear asking you to upgrade the firmware. Click Yes to upgrade. 2. Enter the system user name (default: admin) and password (default: 000000) and click Apply.

  • Page 20: Default System Password & Port Numbers

    This system features the exclusive Lorex Stratus Connectivity. This is a cloud service that allows you to connect to your system over the Internet via a secure handshake with Lorex’s servers. This means you can easily connect to your system without requiring any network configuration.

  • Page 21: Mouse Control

    Mouse Control The DVR is designed for mouse navigation. To use a USB mouse (included), connect the mouse to a USB port on the DVR. Use the mouse buttons to perform the following: 1. Left-Button: • Click to select a menu option. •...

  • Page 22: Remote Control

    Remote Control You can also control the DVR using the included remote control. 1. Number Keys (1~0): Press to select the desired channel in Full-screen View. • : In Live Viewing Mode, press to open Split-screen View. Press repeatedly to switch between split-screen viewing modes.
  • Page 23 Remote Control 6. Playback Controls: • : In Playback Mode, press to fast forward/increase fast forward speed. • : In Playback Mode, press to rewind/increase rewind speed. • : In Live Viewing Mode, press to open the Search Menu to select video for playback.

  • Page 24: Using The On-Screen Display

    Using the On-Screen Display Use the system’s graphical on-screen display to navigate menus and configure options and settings. 1. Date & Time: Displays the date and time on the system 2. Record Status: Displays the current recording status of the system: C = continuous (normal recording);...

  • Page 25: Using The Virtual Keyboard And Mini-Keyboard

    Using the On-Screen Display 5. Start/Stop Manual Recording: Start or stop DVR recording on all channels. Pass- word required; does not override scheduled recording. 6. Start/Stop SEQ: Start or stop Sequence Mode. In Sequence Mode, DVR automati- cally switches between channels every few seconds. 7.

  • Page 26: Setting The Date And Time

    • (Optional) NTP: Click the Setup button next to NTP to synchronize your DVR’s time and date with a Network Time Protocol (NTP) time server. Lorex provides a free NTP service that automatically updates your DVR’s time for Daylight Savings Time.

  • Page 27: Configuring Daylight Savings Time (Dst)

    10.2 Using a NTP Server to set your System Time A NTP (Network Time Protocol) server syncs your system time with an online time server. Lorex provides a free NTP service that allows your DVR to automatically update the time for Daylight Savings Time.
  • Page 28 Setting the Date and Time 2. Click System. Beside NTP, click Setup. 3. Configure the following: • NTP: Select Enable. • Server Address: Select ntp.lorexddns.net (recommended) as the time server or select another time server. • Time Zone: Select your region’s time zone. 4.

  • Page 29: Recording

    Recording By default, the system is set to immediately record video from connected cameras in Con- tinuous Recording Mode. • Recording—Continuous: Normal, continuous recording. You can set the system to stop recording once the hard drive is full, or to continually record by overwriting previously recorded data.

  • Page 30: Playback

    Playback You can view and back up recorded video on the system through the Search Menu. 12.1 Playing Back Recorded Video To playback a specific date and time: 1. Right-click to open the Menu Bar and click the Record Search button ( 2.

  • Page 31: Using Playback Controls

    Playback 8. Click Play. NOTE The DVR may reduce the frame rate of recorded video when playing back more than one channel. Playback one channel at a time for the maximum frame rate. 12.1.1 Using Playback Controls This system features advanced playback controls that allow you to see when you have re- corded footage and motion events on your cameras.

  • Page 32: Using Zoom In Playback Mode

    Playback If more than four channels are selected, one bar is shown that combines all the selected channels. This means that video available on any selected channel will be shown in the bar. 12.1.3 Using Zoom in Playback Mode You can use Zoom in Playback Mode. This is useful if you need a closer look at recorded video.

  • Page 33: Quick Playback

    Playback 2.2. The box in the lower right-hand corner shows the entire camera picture with a grey box around the zoomed-in area. Click inside the box and drag to move the zoom area. 3. Right-click to exit Zoom Mode and return to Playback Mode. 12.2 Quick Playback Quick Playback mode plays video from the last 30 minutes for the selected channel.
  • Page 34 Playback 3. To control playback: • Click inside the colored bar to fast forward/rewind within the last 30 minutes. • Click to pause/restart playback. • Right-click to exit playback. #LX400066; r. 1.0/26388/26388; en-US...

  • Page 35: Backup

    Backup 13.1 Backing Up Video You can back up video to a USB flash drive (not included) connected to the DVR. NOTE The LH050 Series only has two USB ports. Backing up video requires you to unplug the wireless receiver in order to plug in a USB flash drive.
  • Page 36 Backup 1. Select the format you would like to use to save the video file. Select AVI for compatibil- ity with common video players. Select H264 for uncompressed video (requires Lorex video player software). 2. Click Backup. 3. Under Device List, select the USB flash drive to transfer the backup files to.

  • Page 37: Using Video Clip Backup

    Backup 4. Click OK. Wait for the backup to finish before removing the USB memory drive. NOTE For details on playing back video files, see 13.3 Viewing Backed Up Video, page 31. 13.2 Using Video Clip Backup Video clip backup allows you to select a duration of video during playback mode and save it to a USB flash drive (not included).
  • Page 38 Click Backup to confirm. 8. Select the format you would like to use to save the video file. Select AVI for compatibil- ity with common video players. Select H264 for uncompressed video (requires Lorex video player software).

  • Page 39: Viewing Backed Up Video

    To view video files saved to H264, you must install the Lorex Player software. • For PC instructions, see 19 Lorex Player 11: Playing Backed up Video on PC, page 115. • For Mac instructions, see 20 Lorex Player for Mac: Viewing Backed up Video on Mac, page 119.

  • Page 40: Managing Passwords

    Managing Passwords NOTE By default, the system user name is admin and the password is 000000. Passwords are enabled by de- fault and are required to access the Main Menu. The password is required to log into the system remotely using a computer or mobile device. You will be prompted to create a custom password after you connect for the first time.

  • Page 41: Adding Users

    Managing Passwords 4. Configure the following: • User Name: Enter the desired admin user name. • Password Enable: Select Enable. • Password: Enter your desired password. • Confirm: Re-enter the password. 5. Click Apply to save your settings. 14.2 Adding Users You can allow multiple users to log in to the system.
  • Page 42 Managing Passwords 2. Click System> Users. 3. Click on a row to select a user account. 4. Click the Edit button. 5. Select the menus and channels the user will have access to: • Select the menus the user account will be able to access. •...
  • Page 43 Managing Passwords 6. Click Apply to save your settings. 7. Configure the following: • User Enable: Select Enable to enable the user account. • User Name: Enter the desired user name. • Password Enable: Select Enable. • Password: Enter your desired password. •...

  • Page 44: Using The Main Menu

    Using the Main Menu To open the Main Menu: 1. Right-click to open the Menu Bar and click the Main Menu button ( 2. Enter the system user name (default: admin) and password (default: 000000) and click Apply. • Display: Configure display options (e.g. camera color settings, camera title, video output).

  • Page 45: Display

    Using the Main Menu 15.1 Display The display menu allows you to configure camera image settings and video output settings. NOTE If you want to apply settings to all channels, use the "Copy To" drop-down menu, and select All. Click the Copy button to copy the setting across all channels.
  • Page 46 Using the Main Menu Sequence Mode is on, channel 1 is shown for several seconds before switching to chan- nel 2. To configure the sequence time: 1. Click the Output tab. 2. Click the SEQ Dwell Time field and enter the time (in seconds) that channels remain on-screen before changing to another channel.

  • Page 47: Changing The Video-Out Resolution

    Using the Main Menu 15.1.4 Changing the Video-out Resolution 1. Click the Output tab. 2. Click the drop-down menu beside VGA/HDMI Resolution and select the output resolution. 3. Click Apply to save your settings. 4. Right-click repeatedly to exit all menus. The DVR prompts you to restart. Click OK. 5.

  • Page 48: Adjusting Menu Transparency

    Using the Main Menu 2. Press and hold the Stop ( ) button on the remote control for 6 seconds. The resolu- tion will be reset to 1024 x 768 and the DVR will restart. When the DVR restarts, click Yes to confirm the default resolution.

  • Page 49: Record

    Using the Main Menu 15.2 Record The Record menu allows you to configure recording settings, such as the recording resolu- tion and recording schedule. 15.2.1 Configuring Pre-recording Settings 1. Select the Rec Para tab. 2. In the Channel drop-down menu, select the desired channel you wish to configure. 3.

  • Page 50: Search

    Using the Main Menu 4. Click and drag inside the grid to configure the recording schedule: • The recording schedule is arranged as a grid. Each row represents a recording type (Continuous and Motion), and each box represents half an hour. •...
  • Page 51 Using the Main Menu 3. Click Search. A list of videos populate in the window. 4. Double-click on the file to play it back. #LX400066; r. 1.0/26388/26388; en-US...

  • Page 52: Using The Log Search

    Using the Main Menu 15.3.2 Using the Log Search A log search allows you to search system event logs. To perform a Log search: 1. Click the Log tab. 2. Configure the following to perform a Log search: • Log Type: Select the log type you want to search for. •...

  • Page 53: Network

    NOTE Port forwarding is not required to use the Lorex Stratus Connectivity service. For details on setting up re- mote connectivity, see 16 Connecting to Your DVR Over the Internet on PC or Mac, page 64.

  • Page 54: Changing The Dvr's Client And Http Port

    Using the Main Menu 2. In the Auto Port Forwarding drop-down menu, select Enable. 3. Click Apply to save your settings. 15.4.3 Changing the DVR’s Client and HTTP Port The DVR’s Default Client port is 9000. The default HTTP port is 80. To change the Client port and HTTP port: 1.
  • Page 55 1. Click the Email tab in the Network menu. 2. From the Email drop-down menu, select from: • Default: Uses the Lorex email server to send out notifications. This is the recom- mended selection. • Enable: Uses custom email server settings.

  • Page 56: Configuring Ddns Settings

    3. Right-click until you have exited all menus. You will be prompted to restart. 15.4.5 Configuring DDNS settings Lorex DDNS is available as an optional connectivity option. Please see 22 DDNS Setup— Access your DVR Remotely over the Internet, page 127 for details.

  • Page 57: Alarm

    Using the Main Menu 15.5 Alarm The Alarm menu allows you to configure Motion Detection. 15.5.1 Configuring Motion Detection Configure motion settings to determine the area you wish to monitor for motion events, and the outcome if a motion event occurs. To configure motion settings: 1.

  • Page 58: Device

    Using the Main Menu 15.6 Device The Device menu allows you to configure and format hard drives. 15.6.1 Formatting the Hard Drive CAUTION Formatting the HDD erases all data on the hard disk. This step cannot be undone. 1. Select the HDD tab. 2.
  • Page 59 Using the Main Menu 1. Select the HDD tab. 2. Select the checkbox beside the hard drive you wish to configure. 3. In the Overwrite drop-down menu, select Auto (recommended), select the desired duration the hard drive should retain its data, or select Disable to disable overwrite. 4.

  • Page 60: System

    Using the Main Menu 15.7 System The System tab allows you to configure the system language and video output. • For instructions on how to set the system time, including how to setup automatic Day- light Savings Time adjustments or NTP, see 10 Setting the Date and Time, page 18. 15.7.1 Changing the System Language 1.

  • Page 61: Changing Video Output - Ntsc & Pal

    Using the Main Menu 15.7.2 Changing Video Output - NTSC & PAL To change the video output: 1. Select the General tab. 2. In the Video Format drop-down menu, select NTSC or PAL. 3. Click Apply to save your settings. 15.7.3 Configuring Menu Time Out The Menu Time Out setting allows you to configure how long the system menu will remain on the screen during inactivity.

  • Page 62: Adding Users & Changing The Admin Password

    Using the Main Menu To configure Menu Time Out: 1. Select the General tab. In the Menu Time Out drop-down menu, select the desired time the system menu remains on the screen during inactivity. 2. Click Apply to save your settings. 15.7.4 Adding Users &...

  • Page 63: Setting The Remote Control Id

    Using the Main Menu 15.7.6 Setting the Remote Control ID If you have more than one DVR, you can use the ID function to pair the remote control with a specific DVR. To pair the remote control: 1. On the DVR, right-click to open the menu bar and click 2.

  • Page 64: Advanced

    Using the Main Menu 15.8 Advanced The Advanced menu allows you to load system defaults, upgrade the system firmware, and configure automatic firmware updates. WARNING Do not remove the USB flash drive or power off the DVR during the firmware update. Wait for the system to reboot.
  • Page 65 Using the Main Menu 2. Extract the firmware into a blank USB flash drive. The firmware should be in a folder named dvrupgrade. Ensure that this is the only folder in the USB drive. 3. Insert the flash drive into one of the USB ports. NOTE The LH050 Series only has two USB ports.

  • Page 66: Restoring To Factory Default Settings

    Using the Main Menu 9. Follow the on-screen instructions to update the firmware. WARNING Do not remove the USB flash drive or power off the DVR during the firmware update. Wait for the system to reboot. 15.8.3 Restoring to Factory Default Settings Restoring to factory default settings reverts any setting changes you have made to their original settings.

  • Page 67: Restarting Or Shutting Down The Dvr

    Using the Main Menu 8. Click OK to return to the menu. 9. Right-click until you have exited all menus. The DVR prompts you to restart. 15.8.4 Restarting or Shutting Down the DVR 1. Right-click to open the Menu Bar and click the Main Menu button ( 2.

  • Page 68: Saving Your System Configuration To A Usb Flash Drive

    Using the Main Menu To configure system warnings: 1. Click the Events tab. 2. Configure the following: • Event Type: Select the event that triggers the system to send out a notification. Choose from Disk Full (low hard drive space), Disk Error (hard drive error), or Vid- eo Loss.
  • Page 69 Using the Main Menu To save your system configuration to a USB flash drive (not included): 1. Insert a USB flash drive (not included) into one of the USB ports. NOTE The LH050 Series only has two USB ports. Saving system configuration to a USB flash drive requires you to unplug the wireless receiver in order to plug in a USB flash drive.

  • Page 70: Loading A System Configuration From A Usb Flash Drive

    Using the Main Menu 6. Click OK to save the configuration file to your USB. 7. Click OK to return to the menu. 15.8.7 Loading a System Configuration from a USB Flash Drive 1. Insert a USB flash drive (not included) that contains a saved configuration to a USB port.
  • Page 71 Using the Main Menu 5. Under Device List, select your USB flash drive then select the DVR_Settings file. Click OK. 6. Click OK to import the configuration file. 7. Click OK to restart your system. #LX400066; r. 1.0/26388/26388; en-US...

  • Page 72: Connecting To Your Dvr Over The Internet On Pc Or Mac

    This section refers to Internet setup on PC or Mac, for smartphone/tablet setup, see 18 Mobile Apps: Accessing your DVR Using a Mobile Device, page 88. 16.1 System Requirements Prior to using Lorex Stratus Client, make sure your system meets or exceeds the following system requirements: Description Requirement Pentium®...

  • Page 73: Step 2 Of 3: Obtain The Dvr's Device Id

    3. Reconnect the power adapter to power the DVR back on. 16.3 Step 2 of 3: Obtain the DVR’s Device ID The Device ID is a unique code that allows your system to handshake with the Lorex serv- ers for a secure connection over the Internet.

  • Page 74: Step 3 Of 3: Connect To The Dvr Over The Internet

    Connecting to Your DVR Over the Internet on PC or Mac To find the Device ID: 1. The Device ID is located on a sticker on the DVR. You can also find the Device ID by: • Pressing the button on the front panel or remote control to open the System In- formation window.
  • Page 75 Connecting to Your DVR Over the Internet on PC or Mac 2. Once installation is finished, double-click the Lorex Stratus Client icon ( ) from the desktop. The DVR login screen appears. 3. Configure the following: 3.1. Under Login Type, select Device ID.
  • Page 76 Connecting to Your DVR Over the Internet on PC or Mac 4.1. Under Login Type, select Device ID. 4.2. Under Device ID, enter the DVR’s Device ID. See the label on the top of the DVR to find the Device ID. 4.3.

  • Page 77: Using The Pc/Mac Client Software

    Using the PC/Mac Client Software Upon login, the Live tab opens. The Client Software interface is the same on PC or Mac. 1. Navigation Tabs: Allows you to access the following tabs: • Live: Watch live video. • Playback: View saved video footage. •...

  • Page 78: Changing Viewing Modes

    • P2P (peer-to-peer) indicates that the video is streaming directly from the DVR to the computer running the Client Software. • RLY (relay) indicates that the video is streaming through a Lorex video server. While relay mode is activated, the system will disconnect after 10 minutes of inactivity. Re- lay mode is only used when a direct connection cannot be made between the DVR and computer.

  • Page 79: Showing / Hiding Channels

    Using the PC/Mac Client Software To record video: 1. Click next to the channel that you wish to capture video from. The video will re- cord to the default save directory. 2. Click to stop video recording. 17.4 Showing / Hiding Channels The Active Channel List is a convenient way to show / hide the cameras that display in the main viewing window.

  • Page 80: Changing The Save Directory Of Screenshots Or Recorded Video

    Using the PC/Mac Client Software 17.6 Changing the Save Directory of Screenshots or Recorded Video 1. Click the Local Setting tab. 2. Click beside the desired category to browse for a save directory. 3. Select the desired save directory, and then click OK. 4.

  • Page 81: Video Playback

    Using the PC/Mac Client Software 1. Click the Local Setting tab. 2. Under File Type, select the file format you would like to use when saving video (264 or avi). 3. (Optional) Under Interval, select the maximum length (in minutes) for video saved on the remote computer.
  • Page 82 Using the PC/Mac Client Software 2. In the calendar window, click the desired month, year, and date. Then, perform the following: 2.1. Under the Type drop-down menu, select the desired recording type you wish to search for (Continuous, Motion, or All). 2.2.

  • Page 83: Video Playback Controls

    Using the PC/Mac Client Software 17.8.1 Video Playback Controls 1. Playback Window. 2. Video Content: Drag the line left or right to select the playback time. 3. Volume. 4. Play. 5. Pause. 6. Stop. 7. Step Forward: Click to advance the video by one frame. 8.

  • Page 84: Configuring Display Settings

    Using the PC/Mac Client Software 17.9 Configuring Display Settings 1. Click the Remote Setting tab, and then click Display>Live. 2. Configure the following: • Channel: Select the channel you want to modify. • Name: Enter the channel name if you want to re-name the channel •...

  • Page 85: Configuring Recording Parameters

    Using the PC/Mac Client Software 4. Drag your mouse cursor over the areas you wish to black out. A red box indicates the area that is masked (blocked out). • To remove a privacy area, click on the red box, then click the Delete button. 5.

  • Page 86: Configuring System Recording Quality

    Using the PC/Mac Client Software 2. Configure the following: • Channel: Select the channel you wish to configure. • Week: Select the day of the week you would like to apply the settings to. The recording schedule is arranged as a grid. Each row represents a recording type (Continuous and Motion), and each box represents an hour.

  • Page 87: Configuring Basic Network Settings

    Using the PC/Mac Client Software 17.14 Configuring Basic Network Settings The basic network menu allows you to configure the network protocol type (DHCP or Static). To configure basic network settings: 1. Click the Remote Setting tab, and click Network. 2. Configure the following: •...

  • Page 88: Configuring Email Notification Settings

    17.16 Configuring Email Notification Settings 1. Click the Remote Setting tab, and click Network> Email. 2. In the Email drop-down menu, select Default to use the default Lorex email server (recommended) or select Custom to use your own custom SMTP email server.

  • Page 89: Configuring Ddns Settings

    Internet without requiring port forwarding or DDNS registration (see 16 Connect- ing to Your DVR Over the Internet on PC or Mac for details). Lorex DDNS is also available as an optional connectivity option (see 22 DDNS Setup—Access your DVR Remotely over the Internet, page 127 for details).

  • Page 90: Configuring Motion Detection Settings

    Using the PC/Mac Client Software 4. Click Save to apply your settings. 17.18 Configuring Motion Detection Settings 1. Click the Remote Setting, and click Alarm>Motion. 2. Configure the following motion recording parameters: • Channel: Select the channel you wish to apply the settings to. •...

  • Page 91: Configuring Hard Drive Recording Mode

    Using the PC/Mac Client Software 17.20 Configuring Hard Drive Recording Mode 1. Click the Remote Setting tab, and click Device>HDD. 2. In the Overwrite drop-down menu, select Auto to enable overwrite mode. NOTE When overwrite is enabled, the system deletes the oldest footage (first in, first out) when the hard drive is full.

  • Page 92: Changing The System's Menu Time Out

    Using the PC/Mac Client Software 3. Select DST to enable daylight savings time, or NTP to sync the time with a NTP time server. NOTE Using the NTP feature requires that your DVR have a constant Internet connection. 17.22 Changing the System’s Menu Time Out 1.

  • Page 93: Viewing System Information

    Using the PC/Mac Client Software 17.24 Viewing System Information 1. Click the Remote Setting tab, and click System>Info. 17.25 Configuring Firmware Upgrades Firmware upgrades can provide improved functionality to your DVR. When firmware up- grades become available, you will automatically be prompted to upgrade your system. You must have the latest DVR firmware and client software to connect to the DVR over the Internet.

  • Page 94: Restoring Default Settings

    Using the PC/Mac Client Software You must have the latest DVR firmware and client software to connect to the DVR over the Internet. To upgrade the system firmware: 1. Download and extract the file to your computer’s desktop. 2. Click the Remote Setting tab, and click Advanced>Firmware upgrade. 3.

  • Page 95: Configuring Event Settings

    Using the PC/Mac Client Software 17.28 Configuring Event Settings The Event Settings tab allows you to configure how the system behaves when a system event occurs (e.g. hard drive error, video loss). This is useful if you want your DVR to notify you if there is a potential system problem.

  • Page 96: Mobile Apps: Accessing Your Dvr Using A Mobile Device

    For the latest list of supported apps and devices, visit www.lorextechnology.com/support. 18.2 iPhone Use the Lorex Eco Stratus application to connect to your DVR on the iPhone. Prerequisites • An iTunes account (requires valid credit card number). Your credit card will not be billed when downloading the app.
  • Page 97 Mobile Apps: Accessing your DVR Using a Mobile Device 3. Tap Device Manager. 4. Tap +. #LX400066; r. 1.0/26388/26388; en-US...
  • Page 98 Mobile Apps: Accessing your DVR Using a Mobile Device 5. Configure the following: 5.1. Under Name, enter a name for your DVR of your choice. 5.2. Press the QR code icon ( ) next to Device ID and line up the QR code on the top of the DVR using the camera on your device.

  • Page 99: Lorex Eco Stratus Interface

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.2.2 Lorex Eco Stratus Interface 1. Live View: Tap a channel to select it. Double tap to view a channel in full screen. Swipe left or right to change cameras or pages.

  • Page 100: Taking Manual Recordings

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.2.4 Taking Manual Recordings 1. Tap during live view or playback. • If taking manual recordings from live view: tap the grid area you would like to start recording on. Tap again when you would like to stop recording. •...

  • Page 101: Viewing Screenshots

    You can view screenshots or email them using the app. NOTE To email screenshots, you must have an email account configured in the Email app. Lorex does not sup- port the Email app. Please refer to your device’s user’s guide or www.apple.com...

  • Page 102: Viewing Manual Recordings

    Mobile Apps: Accessing your DVR Using a Mobile Device 3. Tap the screenshot you would like to view. Screenshot Viewing Controls 1. Swipe left or right to select screenshot 2. Send screenshot as email attachment. 3. Begin slideshow (tap inside the picture to stop the slideshow). 4.

  • Page 103: Using Device Manager To Manage Dvr's

    Mobile Apps: Accessing your DVR Using a Mobile Device To view manual recordings: 1. From the Main Menu, tap Record Playback. 2. Tap the DVR you would like to view manual recordings from. 3. Tap the recording file you would like to view. 4.

  • Page 104: Ipad

    3. Change the connection details as needed and then tap Save. 18.3 iPad Use the Lorex Eco Stratus HD application to connect to your DVR on an iPad. 18.3.1 Prerequisites: • Connect your DVR to your router using an Ethernet cable.
  • Page 105 Mobile Apps: Accessing your DVR Using a Mobile Device 4. Tap +. 5. Configure the following: 5.1. Under Name, enter a name for your DVR of your choice. 5.2. Press the QR code icon ( ) next to Device ID and line up the QR code on the top of the DVR using the camera on your device.
  • Page 106 Mobile Apps: Accessing your DVR Using a Mobile Device 6. Tap Save. If this is the first time connecting, you will be prompted to change the DVR password. Tap OK. 7. Enter a new 6 character password and tap Done. This password will be used to con- nect to your system from now on.

  • Page 107: Live View Interface

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.3.3 Live View Interface 1. Device List: Drag cameras to the display area to open a single camera. Drag a DVR to the display area to open all cameras connected to that DVR. 2.

  • Page 108: Using Remote Playback Mode

    Mobile Apps: Accessing your DVR Using a Mobile Device 2. Tap again to stop recording. To view manual recordings, please refer to the sec- tion 18.3.8 Viewing Manual Recordings, page 102. 18.3.6 Using Remote Playback Mode Remote Playback Mode allows you to view recorded video saved on your DVR's hard drive.

  • Page 109: Viewing Screenshots

    Mobile Apps: Accessing your DVR Using a Mobile Device 1. Tap cameras to select them. Red dots will appear in the calendar on days that have video available. 2. Tap a day to select it. 3. Tap 4. Press to start playback. Use the on-screen playback controls. Remote Playback Controls 1.

  • Page 110: Viewing Manual Recordings

    Mobile Apps: Accessing your DVR Using a Mobile Device 3. Tap the screenshot you would like to view. 18.3.8 Viewing Manual Recordings You can view manual recordings using the app. To view manual recordings: 1. Tap 2. Tap the DVR you would like to view manual recordings from. Then, select the day you would like to open.

  • Page 111: Using Device Manager To Manage Dvrs

    Mobile Apps: Accessing your DVR Using a Mobile Device Manual Record Playback Controls 1. Back: Tap to select a different video file. 2. Pause/Play. 3. Stop. 4. Slow. 5. Fast Forward. 6. Next Frame. 7. Screenshot. 8. Mute/Unmute. 9. Playback Bar: Select playback time. 18.3.9 Using Device Manager to Manage DVRs You can use the Device Manager to add, delete, or modify your DVRs.

  • Page 112: Managing Favorites

    Mobile Apps: Accessing your DVR Using a Mobile Device 2. Swipe to the left on the DVR you would like to delete and tap Delete. 3. Tap Delete to confirm. To modify a DVR: 1. Tap 2. Tap on the DVR you would like to modify. 3.

  • Page 113: Android

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.4 Android Use the Lorex Eco Stratus application to connect to your DVR on an Android smartphone or tablet. NOTE The instructions below may differ depending on the model of your Android device.
  • Page 114 Mobile Apps: Accessing your DVR Using a Mobile Device 5. Configure the following: 5.1. Under Device Name, enter a name for your DVR of your choice. 5.2. Press the QR code icon ( ) next to Device ID and line up the QR code on the top of the DVR using the camera on your device.

  • Page 115: Lorex Eco Stratus Interface

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.4.2 Lorex Eco Stratus Interface 1. Live View: Tap a channel to select it. Double tap to view a channel in full screen. Swipe left or right to change cameras or pages.

  • Page 116: Taking Screenshots

    Mobile Apps: Accessing your DVR Using a Mobile Device 18.4.3 Taking Screenshots 1. Tap during live view or playback. • If taking screenshots from live view: Select the grid area you would like to take a screenshot from or tap to take a screenshot from all connected cameras.
  • Page 117 Mobile Apps: Accessing your DVR Using a Mobile Device 2. Tap Select Channel. Select the channel you would like to playback from. NOTE If you receive the message "No video found," close the app and restart it. 3. The calendar shows any days that have recorded video for the selected channel with dots under the date.

  • Page 118: Viewing Screenshots

    18.4.6 Viewing Screenshots You can view screenshots or share them using the app. NOTE To share screenshots, you must configure the apps used for sharing. Lorex does not support 3rd party applications. To view screenshots: 1. From the Main Menu, tap Image Manager.
  • Page 119 Mobile Apps: Accessing your DVR Using a Mobile Device 3. Tap the screenshot you would like to view. Screenshot Viewing Controls 1. Swipe left or right to select screenshot 2. Tap to share screenshot. 3. Begin slideshow (tap inside the picture to stop the slideshow). 4.

  • Page 120: Viewing Manual Recordings

    Mobile Apps: Accessing your DVR Using a Mobile Device To share screenshots: 1. Tap to share. Select an app that you would like to share the file with. Follow the app’s instructions to share the file. 18.4.7 Viewing Manual Recordings You can view manual recordings using the app.

  • Page 121: Using Device Manager To Manage Dvr's

    Mobile Apps: Accessing your DVR Using a Mobile Device Manual Record Playback Controls 1. Playback Bar: Select playback time. 2. Take Screenshot. 3. Slow. 4. Pause. 5. Play/Stop. 6. Fast Forward. 7. Step forward: Advance the video one frame. 8. Mute/Unmute. 18.4.8 Using Device Manager to Manage DVR’s You can use the Device Manager to add, delete, or modify your DVR’s.
  • Page 122 Mobile Apps: Accessing your DVR Using a Mobile Device To modify a DVR: 1. From the Main Menu, tap Device Manager. 2. Tap on the DVR you would like to modify. 3. Change the connection details as needed and then tap Save. #LX400066;...

  • Page 123: Lorex Player 11: Playing Backed Up Video On Pc

    Lorex Player 11 allows you to view your backed up video files from your DVR on your PC. NOTE To view backed up video files on Mac, see 20 Lorex Player for Mac: Viewing Backed up Video on Mac, page 119.

  • Page 124: Lorex Player 11 Interface Overview

    Lorex Player 11: Playing Backed up Video on PC 19.2 Lorex Player 11 Interface Overview 1. Video Window. 2. Rewind. 3. Open File. 4. Previous File. 5. Play. 6. Next File. 7. Stop. 8. Fast Forward. 9. Take Screenshot. 10. Hide/Show Playlist.

  • Page 125: Converting Backed Up Video To Avi Files

    Lorex Player 11: Playing Backed up Video on PC 2. Click Select to change the snapshot save folder. Then select the folder and click OK. 3. Click OK to save changes. 19.3 Converting Backed Up Video to AVI Files The DVR saves its backup files as proprietary video files. To share these files, you must convert them into .AVI files.
  • Page 126 Lorex Player 11: Playing Backed up Video on PC 4. Select the desired file format (.264 , h.264, All File) that you wish to search for. Click Open. 5. Click Start to convert and save the file in the default save folder.

  • Page 127: Lorex Player For Mac: Viewing Backed Up Video On Mac

    Lorex Player for Mac: Viewing Backed up Video on Mac Lorex Player for Mac allows you to view your backed up video files on a Mac computer. To install Lorex Player for Mac: 1. Go to www.lorextechnology.com and search for the model number of your DVR (look at the label underneath your DVR for the model number).

  • Page 128: Lorex Player For Mac Interface

    Lorex Player for Mac: Viewing Backed up Video on Mac 20.3 Lorex Player for Mac Interface 1. Video Playlist. 2. Video Slider. 3. Hide/Show Playlist. 4. Load File. 5. Load Folder. 6. Remove Selected File. 7. Clear Playlist. 8. Looped Playback.

  • Page 129: Replacing The Hard Drive

    Replacing the Hard Drive The system comes with a pre-installed SATA hard drive. You can expand the hard drive with a replacement 3.5" SATA hard drive up to 4TB. NOTE It is recommended to use surveillance or security-certified hard drives, which are designed to be reliable over long periods of time while recording 24/7.
  • Page 130 Replacing the Hard Drive 3. Using a Phillips screwdriver (not included), remove the screws (x4) from the plastic brackets on either side of the hard drive. 4. Carefully slide the hard drive back until it is clear of the SATA connector and lift it out of the DVR.

  • Page 131: Installing The Hard Drive

    Replacing the Hard Drive 5. Using a Phillips screwdriver (not included), remove the screws (x4) holding the plastic brackets on either side of the hard drive. 6. Hold the top panel of the DVR at an angle. Ensure the front panel of the DVR lines up with the bottom panel.
  • Page 132 Replacing the Hard Drive 2. Gently lift the cover away from the rear panel and lift off. Be careful of sharp edges. 3. Attach the two plastic hard drive brackets to either side of the 3.5” hard drive. 4. Place the hard drive in the DVR. Slide the hard drive gently forward to insert the hard drive SATA ports into the DVR SATA connector.

  • Page 133: Formatting The Hard Drive

    Replacing the Hard Drive 5. Secure the hard drive mounting brackets to the DVR housing using the 4 screws. 6. Hold the top panel of the DVR at an angle. Ensure the front panel of the DVR lines up with the bottom panel. Lower the top panel onto the DVR. 7.
  • Page 134 Replacing the Hard Drive 1. Select the HDD tab. 2. Click the checkbox under Select to choose the drive you wish to reformat. 3. Click Format HDD. 4. When the warning window appears, click OK. Wait for the system to format the hard drive.

  • Page 135: Ddns Setup-Access Your Dvr Remotely Over The Internet

    22.2 Step 2 of 4: Create a DDNS Account Lorex offers a free DDNS service for use with your system. A DDNS account allows you to set up a web site address that points back to your local network. This allows you to con- nect to your system remotely.
  • Page 136 DDNS Setup—Access your DVR Remotely over the Internet 2. The My Lorex account login screen opens (if you are already logged in, skip to step 4). Create a new account or log into an existing account. To create a new account, fill in the required fields on the right and click Create Account.
  • Page 137 DDNS Setup—Access your DVR Remotely over the Internet 5. Under Your Address, select an address or click Enter a New Address to create a new address. Fill in your address information and click Create Address. 6. Fill in the warranty registration form with your product and purchase details. Check the sticker underneath your DVR for the Product Model Number and Serial Number.
  • Page 138 DDNS Setup—Access your DVR Remotely over the Internet 7. A page pops up to prompt you to register your product for Lorex DDNS. Click Set Up a New DDNS. 8. Configure the following: 8.1. Product Warranty: Select the product warranty you created in the previous steps.

  • Page 139: Step 3 Of 4: Enable Ddns On The Dvr

    9. Click Save to register your product for DDNS. A confirmation email will be sent to the email address used to register for My Lorex. You will need this information to ena- ble remote access to your system. Record your information below:...

  • Page 140: Step 4 Of 4: Connect To The Dvr's Ddns Address

    To connect using the DVR’s DDNS address on a PC: 1. Install the Lorex Stratus Client on a remote computer. 2. Once installation is finished, double-click the Lorex Stratus Client icon ( ) from the desktop. The DVR login screen appears.
  • Page 141 Under Client Port, enter the DVR’s Client Port (default: 9000). 1. Click Login. To connect using the DVR’s DDNS address on a Mac: 1. Install the Lorex Stratus Client on a remote computer. 2. Open Safari, then click Safari>Quit Safari. This resets Safari to complete the installation.
  • Page 142 DDNS Setup—Access your DVR Remotely over the Internet 4. Configure the following: 4.1. Under Login Type, select IP Login. 4.2. Under IP Address, enter the Domain name/URL Request followed by.lor- exddns.net (e.g. http://www.tomsmith.lorexddns.net). 4.3. Under User Name, enter the DVR’s user name (default: admin). 4.4.

  • Page 143: Troubleshooting

    Troubleshooting When a malfunction occurs, it may not be serious and can be corrected easily. The follow- ing describes the most common problems and solutions. Please refer to the following be- fore calling Lorex Technical Support: Error Possible Causes Solutions •...
  • Page 144 Troubleshooting Error Possible Causes Solutions • There is no picture on moni- • Monitor/TV not detected by • Power off the monitor/TV and tor/TV after connecting it to DVR. DVR. Power on the monitor/ the DVR. TV, and then power on the DVR.

  • Page 145: Lh050 Series System Specifications

    LH050 Series System Specifications System Operating System Linux (embedded) Pentaplex Simultaneous view, record, playback, backup & re- mote monitoring 4 channels Number of Channels Inputs/Ouputs Video IN None (wireless) Video OUT 1 x HDMI, 1 x VGA VGA OUT HDMI Audio IN None Audio OUT...
  • Page 146 Up to 4TB Backup Media USB flash drive & USB external HDD Backup File Format H.264 file (AVI generator included) Connectivity Cloud Connection Lorex Stratus Connectivity Supported Operating Systems Windows™ Mac OSX Remote Software Client Software (PC) & Safari (Mac) Email Notification Text with snapshot Instant Smart Phone &...
  • Page 147 1280x720 Total Per channel As our products are subject to continuous improvement, Lorex Corporation and its subsid- iaries reserve the right to modify product design, specifications, and prices without notice and without incurring any obligation. E&OE #LX400066; r. 1.0/26388/26388; en-US...

  • Page 148: Notices

    Notices This product has been certified and found to comply with the limits regulated by FCC, EMC, and LVD. Therefore, it is designated to provide reasonable protection against inter- ference and will not cause interference with other appliance usage. However, it is impera- tive that the user follows the guidelines in this manual to avoid improper usage, which may result in damage to the product, electrical shock and fire hazard injury.
  • Page 150 Legal disclaimer As our product is subject to continuous improvement, Lorex Corporation & subsidiaries reserve the right to modify product design, specifications & prices without notice and without incurring any obligation.E&OE.

This manual is also suitable for:

Lh041Lh041 seriesLx4471w

Table of Contents
