Evolion
®
Installation and operating instructions
1. Safety
Make sure to study and follow all
instructions. Misusing the Evolion
may cause it to overheat or ignite.
Do not short-circuit the power
■ ■
terminals.
Do not reverse connect the
■ ■
power cables.
Do not disassemble the unit.
■ ■
Do not subject the unit to
■ ■
excessive vibrations or drop the
unit.
Do not immerse the unit.
■ ■
Do not expose the unit to fire or
■ ■
temperature higher than 100°C
(+212°F). It may cause the
cell safety vent to open which
renders the unit inoperable.
Use only in Telecom power
■ ■
systems.
Refer to the Battery Information
■ ■
Sheet (included) for emergency
response procedures.
2. Important recommendations
If smoke is emitted from a unit,
stay clear of the smoke and
evacuate the area until the smoke
dissipates.
Refer to the Evolion
Technical
®
Manual for functional details.
See Figure 1 for operator interface
features.
RJ45 Jacks
LED's
ON/ OFF
SOC / SOH button
(State of Charge / State of Health)
Figure 1 - Evolion
main front access
®
3. Unpacking and inspection
When shipped, the Evolion
®
packaged in accordance with
UN3480 Class 9 Group 2.
Unpack and make sure all items
were received. Table 1 summarizes
the provided items.
If items were not received or if
anything is damaged contact your
local Saft representative.
Table 1 - Provided items in Evolion
(771473-XX)
Part N
o
®
771492-XX
Evolion
771285
Fuse, spare
Power cable for positive
Note 1
terminal (800 mm length)
Power cable for negative
Note 1
terminal (800 mm length)
772518
Communication cable
773455
RJ45 resistor cap
-XX:
refers to the parameter file variant
Note 1: Part N° varies according to heat shrink
color and cable color
If a long storage is planned, check
and note the SOC (State of Charge)
according to Figure 3 and Table 2.
A hole in the packaging allows you to
access the unit without removing it
from the box. Refer to Figure 2.
Figure 2 - Accessing the unit
button
Figure 3 - Checking SOC (State of Charge)
• For SOC, push and hold for 3 s or
less and observe the LED's.
This will help to plan the next
refreshing charge.
Keep Evolion
packaging for continued storage or
is
for transportation.
Table 2 - SOC (State of Charge) LED legend
SOC LED
(steady for 5 s)
Minimum SOC
kit
®
Qty
1
®
1
1
1
1
1
in its original
®
≥75%
April 2014
4. Storage
Store the battery in its original
packaging and in typical warehouse
conditions. The temperature should
be between 15°C to 30°C (59°F to
86°F).
The Evolion
can be stored for up to
®
1 year from the manufacturing date.
Make sure the unit is switched OFF
during storage. When OFF, the unit
is in sleep mode. In sleep mode, no
voltage is present on the terminals.
NOTE: The Evolion
unit will
®
periodically and automatically wake-up
to record its state and to initiate cell
balancing if necessary.
IMPORTANT: If the unit is left ON, it
may over discharge in a short time
and render the unit inoperable. It is
mandatory to check the SOC while in
storage every 6 months. See Figure 3
and Table 2.
If the Evolion
®
is stored at a low SOC for
too long, it may eventually over discharge
and render the unit inoperable.
To conduct a maintenance charge:
• Connect according to Section 6
• Make sure the set-point voltage on
the rectifier is 56.0 V
• Charge for a total time according
to the available charge current
(see Table 3)
Table 3 - Charging time according to
the current
Amps
Charging
Amps
per unit
time
per unit
3
15 h 20 min
12
4
11 h 30 min
15
5
9 h 10 min
18
6
7 h 40 min
20
8
5 h 40 min
25
10
4 h 30 min
CL mode* 11 h 30 min
* current limit mode
charge as
≥50%
≥25%
soon as
possible
Charging
time
3 h 50 min
3 h
2 h 30 min
2 h 10 min
1 h 50 min
<25%
