- Page 1 QuickStart Guide FortiManager 3100G FMG-3100G...
-
Page 2: Before You Begin
Copyright © 2024 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. -
Page 3: Package Contents
FortiManager Device Technical Support To access our Resource Center, Professional Services and Technical Support Services, visit https://www.fortinet.com/support 1x Ethernet Cable 1x Console Cable (DB9 to DB9) Thank you for choosing Fortinet 2x Sliding Rails 6x Rubber Feet 16x Storage Devices... -
Page 4: Setup Options
Data bits: Stop bits: Parity: None Console Cable Flow Control: None Port 1 Console Port Management Computer Management Computer Ethernet Cable Note: For static IP configuration, use 192.168.1.1 with subnet mask Note: For a detailed CLI guide, visit docs.fortinet.com 255.255.255.0... -
Page 5: Sfp Modules
2. Slide the rail towards the front of the device until the inner rail metal clip clicks Cage Socket into the locked position. 3. Repeat steps 1 - 2 for the remaining rail. Lock Locks in place Note: Please see the following video for visual instructions: https://video.fortinet.com/latest/rack-mount-sliding-rail-installation... -
Page 6: Install The Device
C. Install the device B. Attach the outer rails Before installing the devicee ensure the inner rails are properly connected to the 1. Align the front of the outer rail with the front of the rack. 2. Push the mounting pins into the rack post holes. device and the outer rails are level and securely attached to the rack. - Page 7 Front FMG-3100G Storage Slots 1 to 16 (SED HDD) Power Button 4TB per slot, RAID-50, 56TB usable capacity, hot-swappable Power On: Short press to power on/off; long press to force shutdown Storage Status Storage Status Power Off: System is off Red: Storage status error Blue: Storage device location Reset Button...
- Page 8 Rear FMG-3100G NVMe SSD (x2) 1.92TB per slot, 3.84TB total storage SFP28 Activity LED (Ports 3 & 4) SFP28 Speed LED (Ports 3 & 4) Left LED Right LED Green: Link established, no activity Green: 25 Gbps Green: Link established, no activity Red: Failure detected Flashing Green: Data activity...
-
Page 9: Cautions And Warnings
The presence conditions of the restricted substance (BSMI RoHS table) are available at the link below: piles usagées conformément aux réglementations locales. IMPORTANT: Suisse: l’annexe 4.10 de SR814.013 s’appliquent aux batteries. 限用物質含有情況表 (RoHS Table) 請到以下 網址下載： https://www.fortinet.com/bsmi 警告 本電池如果更換不正確會有爆炸的危險 警告： 為避免電磁干擾，本產品不應安裝或使用於住宅環境。... - Page 11 Fortinet.com...
