Ergo Systems Ergosys.net 2000GS Owner's Manual page 20

Step 7
Check the arrow marks on the Feeder base
and the Feeder container lines up together
as shown in Fig 4.
Fig 4
Step 9
Then the bottle is pressed into the base as
shown.
Fig 7
For replacing the bowl refer to Page No.4. (Step 1.2, 1.3 & 1.4)
Connect timer and power outlet and start feeding your loved ones with your clean Feeder.
Step 8
Make sure that the safety pin aligns with the
safety switch receiver as shown in Fig 5.
Make sure that the safety switch pin at
the bottom of the container interlocks
with the safety switch pin receiver hole
on the base. This safety feature ensures
that the feeder can operate only if the
storage container is installed properly.
Step 10
Replace the food container cover.
20
CAUTION
Safety Pin
Safety Pin
Receiver
Fig 5
Fig 8
