ergo systems inc.
Auto Pet Feeder
HOUSEHOLD TYPE
MODEL NO.
2000GS - 083497500017
2000GM - 083497500024
2000GL - 083497500031
Model and serial number may be found
at the rear of the feeder base.
Please record both model and serial
number in a safe place for future use.
Where Purchased
:
Date Purchased
:
:
:
Model No.
:
Serial #
:
______________________
Month ________________
Day __________________
Year __________________
______________________
______________________
Owner's Manual
This Owner's Manual contains
information for all models.
Read and keep this manual for
future reference.
This manual contains important
information on Safety, Assembly,
Operation and Maintenance.
Ergo Systems Inc. Rev# 1.2
Advertisement
Related Manuals for Ergo Systems Ergosys.net 2000GS
Summary of Contents for Ergo Systems Ergosys.net 2000GS
- Page 1 Date Purchased Month ________________ Read and keep this manual for Day __________________ future reference. Year __________________ This manual contains important information on Safety, Assembly, Model No. ______________________ Operation and Maintenance. Serial # ______________________ Ergo Systems Inc. Rev# 1.2...
-
Page 2: Limited Warranty
The extent of Ergo Systems Inc. under this limited warranty is the repair or replacement of the product at the sole discretion of Ergo Systems Inc, In no event shall Ergo Systems Inc. ’ s. liability exceed the purchase price paid by the purchaser. - Page 3 List of parts in the Auto Pet Feeder Box Components 1. Pet Feeder Base 2. Pet Feeder Bowl 3. Food Storage Container 4. Food Storage Container Cover 5. Digital Timer 5:30 AUTO WEEK HOUR CLOCK PROG ON/AUTO/OFF...
- Page 4 Assembly Take out the Autopetfeeder from the box. The Bowl is aligned with the T-slots on the Pet Feeder body. Fig 2 Fig 1 Pull down the Pet Feeder Bowl Pull down the Pet Feeder Bowl in the T-slot. The assembly of Auto Pet Feeder is completed. Fig 3 Final position of Pet Feeder Bowl Fig 5...
-
Page 5: Timer Programming
TIMER PROGRAMMING INDICATES INDICATOR HOUR INDICATES INDICATES WEEK DAY SETTING MINUTES SETTING INDICATES INDICATES AM OR PM SECONDS SETTING INDICATES STANDARD TIME 12:30 INDICATES PROGRAM NUMBER AND “ON” OR “OFF” MODE AU TO OF F INDICATES PROGRAM INDICATES DAY LIGHT MODE “ON”... -
Page 6: Setting The Current Time
2.1 Setting the Current Time 12:00 AU TO Press and hold the CLOCK button. While holding the CLOCK button press the WEEK button to set the day of the week. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 1 8:00 AU TO Press and hold the CLOCK button. -
Page 7: Daylight Saving Time
2.2.1 Day Light Saving Time 8:30 AU TO To set day light saving time, press the HOUR and the MINUTE button simultaneously. This will make the clock to run an hour ahead. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 4 9:30 AU TO This introduces a “... - Page 8 2.3 Understanding the Timer 2.3.1 Number of meal times per day The Autopetfeeder is capable of feeding your pet 8 times per day. You can set the ON time and the OFF time for the feeder 8 times per day. This will give you control over the amount of food you feed your pet and also the time you pet is fed.
- Page 9 8:00 AUTO In AUTO mode the feeder works as per the program schedule. In order for AUTO mode to work properly you must cycle from OFF mode to AUTO WEEK HOUR mode. Do not cycle from ON mode to AUTO mode as the feeder will feed continuously.
- Page 10 2.2.4 Setting the days of Week -- -- AU TO Press PROG button to enter in to the program mode. The display will show 1 which means that we are setting the 1st schedule ON time. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 10 12:00...
- Page 11 12:00 AUTO Pressing WEEK button again will give you the week days option. This display will show Mon-Fri. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 13 12:00 AUTO A scheduled program in this option will work on week days. Pressing WEEK button once again will lead to the weekend option.
- Page 12 12:00 AUTO Press WEEK button again for the alternate day option mon, wed & fri. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 16 12:00 AUTO Press WEEK button once more for the other alternate option day tue, thu & sat. WEEK HOUR CLOCK PROG...
- Page 13 12:00 AUTO Press WEEK button again to go to three days option which is to schedule for next three days of the week such as thu, fri & sat. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 19 2.4 Erasing all schedules -- -- AU TO Press R button to erase all schedules.
- Page 14 2.5.2 12:00 AUTO Press WEEK button once and the display will show Mon-Sun. This is the recommended program for all days of week WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 22 2.5.3 8:00 AUTO Press the HOUR button till the display shows 8. WEEK HOUR CLOCK...
- Page 15 2.5.5 8:00 AUTO Press the ON/AUTO/OFF button till the display shows 00 seconds. The ON time is now set to 8 a.m. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 25 2.5.6 --:-- AUTO Press the PROG button again and the display will show 1OFF which means that we are setting the rst schedule for the OFF time.
- Page 16 2.5.8 8:00 AUTO Press the HOUR button till the display shows 8. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 28 2.5.9 8:01 AUTO Press the MINUTE button until display in the MINUTE shows 8.01. WEEK HOUR CLOCK PROG ON/AUTO/OFF Fig 29 2.5.10 8:01 AUTO...
- Page 17 2.5.11 --:-- AUTO Press the PROG button again. The display shows which means that we are setting the second WEEK HOUR feed. CLOCK PROG ON/AUTO/OFF Repeat programming from no. 2.5.2 to 2.5.10 to complete programming the second feed time. Fig 31 Similarly we can set 8 schedules for all days of the week by pressing the PROG button to go from program 1 to program 8.
- Page 18 2.6.2 Plug the timer into an 110 VAC wall socket. NOTE : Do not plug the cord of the fedder into the power side of the timer. Now the AUTOPET FEEDER is ready to feed your pet as per your schedule. CAUTION GROUNDING INSTRUCTIONS This product is for use on a normal 110-volt AC circuit.
-
Page 19: Maintenance
Maintenance Your Autopetfeeder is easy to dismantle, clean and to assemble. Always disconnect feeder from 110VAC prior to cleaning. Do not under any circumstances wash down this feeder, serious injury could occur if the applicance is connected to 110 VAC. Below steps will make your cleaning process easier. - Page 20 Step 7 Step 8 Check the arrow marks on the Feeder base Make sure that the safety pin aligns with the and the Feeder container lines up together safety switch receiver as shown in Fig 5. as shown in Fig 4. CAUTION Make sure that the safety switch pin at the bottom of the container interlocks...
- Page 21 Ergo Systems Inc., E-Mail Toll-Free Phone. US only support@ergosys.net 1-888-ERGOSYS (1-888-374-6797) Website International Phone http://www.autopetfeeder.com 1-630-543-7686 Warranty Registration http://www.autopetfeeder.com/warranty.asp 1-866-899-5389...
