PAX S80 Quick Reference Manual

NOTE: Transactions that are manually entered (not swiped) will require you to enter the card number, expiration date, customer zip code and credit card CVV (on
back of card) value. The buttons on the right of the screen are F1, F2, F3 and F4.
CREDIT SALE
1. Enter sale amount.
2. Input tip amount (restaurant only)
3. Swipe, key-in, or insert card
4. Enter expiration date*
5. Enter sale amount
• Enter invoice #**
• Enter Clerk ID**
• Enter Table No**
• Number of Guests**
6. Select 1. Card Present or 2. Card not present*
7. Enter Cvv2*
8. Enter numeric portion of Street Address*
9. Enter Zip Code*
10. Terminal communicates with HOST
11. Tear slip and then press any key
DEBIT SALE
1. From CREDIT/SALE Idle prompt, press F3 shortcut key to toggle to
DEBIT
2. Enter sale amount
3. Swipe card
• Enter invoice #**
• Enter Clerk ID**
• Enter Table No**
• Number of Guests**
• Enter Cash Back amount**
4. Enter PIN #
5. Terminal communicates with HOST
6. Tear slip and then press any key
*Prompts for manually entries
**Optional prompts
HT2454_01152015
QUICK REFERENCE GUIDE
PAX S80/S90 RESTAURANT
1. From CREDIT/SALE Idle prompt, press F4 shortcut key to toggle to
RETURN
2. Enter return amount
3. Swipe, key-in, or insert card
4. Enter expiration date*
• Enter invoice #**
• Enter Clerk ID**
• Enter Table No**
• Number of Guests**
5. Tear slip and then press any key
1. From CREDIT/SALE Idle prompt, press F4 shortcut key or use the
UP/DOWN arrow keys to toggle to VOID
Note: You can toggle between various options depending on what type
of transaction you need to void
2. Press Enter to continue
3. Enter Trans # followed by Enter key
Note: If the transaction # is not found, terminal will display "TRANS
NOT FOUND"
4. Transaction is displayed for review. If correct press enter key.
• Enter Clerk ID**
5. Tear slip and then press any key
1. From CREDIT/SALE Idle prompt, press F4 shortcut key or use the
UP/DOWN arrow keys to toggle to AUTH
2. Enter authorization amount
3. Swipe, key-in, or insert card
4. Enter expiration date*
• Enter invoice #**
• Enter Clerk ID**
• Enter Table No**
• Number of Guests**
Customer Service: 800-201-0461
24-Hour Technical Support: 800-632-1888
CREDIT RETURN
VOID
AUTHORIZATION ONLY
PAGE 1
