- Page 1 FF-SE100 / FF-SE200 FRENCH FITNESS SE100/200 RECUMBENT SEATED ELLIPTICAL W/LED/TOUCH CONSOLE (NEW) ASSEMBLY MANUAL...
-
Page 2: Tech Specs
Dimensions: 80"L x 39.8"W x 59.8"H (203cm x 101cm x 152cm) • Main Tube Size: 2.4" x 4.7" (60mm x 120mm) • Main Tube Thickness: 3mm • CONSOL E S FF-SE100 • LED Display • 4 Self-Compiled Programs • 8 Present Programs •... -
Page 3: Table Of Contents
T ABL E OF CONT E NT S IMPORTANT SAFETY INSTRUCTIONS ..............4 ASSEMBLY INSTRUCTIONS ................6 PARTS LIST ......................7 EXPLODED VIEW ....................8 ASSEMBLY STEPS ....................9 CONSOLE DESCRIPTION-LED ................18 CONSOLE DESCRIPTION-TFT ................19 CONSOLE DESCRIPTION ...................20 OPERATING INSTRUCTIONS................21 MAINTENANCE ....................23 SPECIFICATION ....................23... -
Page 4: Important Safety Instructions
I MPORT ANT SAFE T Y I NST RU CT I ONS Save these instructions for future reference. Make sure all users see a physician for a complete physical examination before they begin any fitness program, particularly if they have high blood pressure, high cholesterol or heart disease;... - Page 5 Other Important Safety instructions Keep equipment away from water and moisture. Avoid dropping anything on or spilling anything ● inside the equipment to prevent electric shock or damage to the electronics. Do not operate electrically powered equipment in damp or wet locations. ●...
-
Page 6: Assembly Instructions
ASSE MB L Y I NST RU CT I ONS Always unplug the unit from the electrical outlet immediately DANGER! after using, before cleaning, performing maintenance and putting on or taking offparts. • Read all instructions in this guide before installing. Assemble and operate your equipment on a hard, level suiface in the area •... -
Page 7: Parts List
PART S L I ST Note: some of these parts may come pre-installed. Part No. DESC. Qty/Unit Main Frame Assembly Left Arm Assembly Right Arm Assembly Right Pedal Assembly Back Pad Back Pad Rear Cover Front Handle Cover Rear Handle Cover Bottle Holder Console Assembly Bolt M10x25... -
Page 8: Exploded View
E XPL OD E D VI E W 18 11... -
Page 9: Assembly Steps
ASSE MB L Y ST E PS Step 1 Remove the left and right handrails from the machine first. Remove the packing connecting frame group welding from the machine. Note, be careful of pinching hands and touching the plastic shell. (Two people are required for this installation) Group welding of packaging connecting frames Large left armrest assembly Large Right armrest assembly... - Page 10 ASSE MB L Y ST E PS Step 2 Rotate the upper support bracket group weld to the position shown in the illustration (note, be careful of pinching hands). Pass the communication cable through the upper support bracket. Pre-insert the upper support bracket into the main frame in the position shown in the picture (a person needs to hold it).
- Page 11 ASSE MB L Y ST E PS Step 3 The upper support frame group welding is completely inserted on the main unit and fixed with M10x16 bolts. Hexagon socket head cap screws M10x16-4pcs...
- Page 12 ASSE MB L Y ST E PS Step 4 Insert the right stirrup assembly into the main unit according to the position shown in the picture and bolt it in place. Right pedal assembly Hexagon socket cheese head bolts M6x15...
- Page 13 ASSE MB L Y ST E PS Step 5 Fix the cup holder with bolts as shown in the figure. Assemble the left and right large handrails and fix them with bolts according to the positions shown in the figure. Right large armrest assembly water cup holder M5x12 cross recessed pan head screw...
- Page 14 ASSE MB L Y ST E PS Step 6 1. Attach the front and back of the armrest decorative cover to the main unit as shown in the figure. 2. Fix with self-tapping screws, same for left and right sides. Armrest decorative shell front Armrest decorative shell rear Cross recessed tapping screws...
- Page 15 ASSE MB L Y ST E PS Step 7 First connect the communication line in the electronic watch assembly with the communication line of the main body, as shown in the figure. Assemble and install the electronic meter in the position shown in the figure and secure it with bolts.
- Page 16 ASSE MB L Y ST E PS Step 8 Fasten the back pad with bolts as shown in the figure. Align the back cushion shell and back cushion as shown in the figure and fix them with self-tapping screws. Back pad Back pad shell Cross recessed large flat tapping screws...
- Page 17 ASSE MB L Y ST E PS Finished product...
-
Page 18: Console Description-Led
CONSOL E D E SCRI PT I ON- L E D Display LED display console, show us following info rmation: Time(S): display from ”00:00-99:59” ; Default time for positive timing,Increment with each 1 second. Distance(Km): display from”0-99.9” ; Default distance is positive timing, increment with each 0.1Km Calorie (Koal): display from”0-99.9”... -
Page 19: Console Description-Tft
CONSOL E D E SCRI PT I ON- T F T Display LED display console, show us following info rmation: Time(S): display from ”00:00-99:59” ; Default time for positive timing,Increment with each 1 second. Distance(Km): display from”0-99.9” ; Default distance is positive timing, increment with each 0.1Km Calorie (Koal): display from”0-99.9”... -
Page 20: Console Description
CONSOL E D E SCRI PT I ON Number Name Details Blue(3seconds): Power On Breathing blue: Standby Flashing Blue: Searching bluetooth/ Logging into the system Green: System login succeeded light language Flashing Red(2sec): System login failed Yellow(60seconds): Pause state Blue(1Second):Cool Down Red(1second):Stop Red(2Second): Exit system Distance... -
Page 21: Operating Instructions
OPE RAT I NG I NST RU CT I ONS Quick start Press button, all data starts counting, The bottom line of display bright. display lights and intensity adjustment linkage; press buttons - + to adjust intensity, the data can be switched. Press button, to clear all the data, display remind “ANYKEY TO CONTINUE OR PRESS OK TO QUIT”, press any key to continue use the unit, press... - Page 22 OPE RAT I NG I NST RU CT I ONS Self-Editing program starting up Press Button, display remind ”USER PROGRAM” After the information finished, the first line of display is displayed. The first light flashes, setting with - +, each press 1lvl, or use numeric keypad to setting details, press to next step, when finish last step, press...
-
Page 23: Maintenance
MAI NT E NANCE To reduce the risk of electrical shock,always unplug the equipment from its power source before cleaning it or performing any maintenance tasks. Cleaning console and screen Use mild soap and water to dampen a soft cloth and wipe all exposed surfaces. CAUTION: Do •...
