Summary of Contents for FRENCH FITNESS FF-UB200
- Page 1 FF-UB200 FRENCH FITNESS UB200 COMMERCIAL UPRIGHT BIKE ASSEMBLY MANUAL...
- Page 2 FEAT URES • LED Display • Input Power：50W • Range of resistance: 20 levels • Heart rate: Touch Heart Rate Sensors • Console display: Numerical Value, Time, Distance, Calorie, Speed, Resistance, Heart Rate • Programs：8 preset programs + 4 target programs T ECH SPEC S •...
-
Page 3: Table Of Contents
T A B L E O F C O N T E N T S SAFETY PRECAUTIONS .................. 4 TECHNICAL STANDARD ................. 6 MACHINE DIAGRAM ..................7 INSTALLATION PROCESS ................8 INSTRUMENT OPERATION GUIDE ............... 14 ROUTINE MAINTENANCE ................16 EXPLOSION MAP.................. -
Page 4: Safety Precautions
1 . S A F E T Y P R E C A U T I O N S Safety Tips: This safety manual lists important safety information. Please read it carefully before use. 1. The machine is suitable for commercial fitness clubs, clubhouse fitness, bodybuilding training, sports training, physical education and so on. - Page 5 11. Long hair users should pay attention to the safety of hair during the use of elliptical machines. 12. If you feel any discomfort or abnormal condition during use, stop exercising immediately and consult a doctor. 13. Before each use, please check the transmission parts for fastening. If it is loose, please tighten or replace it in time.
-
Page 6: Technical Standard
2 . T E C H N I C A L S T A N D A R D S Time display range: 0:00 - 99:59 Distance display range: 0.00-99.99Km Heat display range: 0 - 999.9 (Kcal) Heart rate display range: 50 - 256 (times / minute) Resistance display range: 0-20 Speed display range: 0.0 - 99.99 (km / h... -
Page 7: Machine Diagram
3 . T H E W H O L E M A C H I N E D I A G R A M Vertical magnetic control car head (13.3 inch LED screen) Hand welding group Seat bracket Heart rate Cages grip Up and down... -
Page 8: Installation Process
4 . T H E A S S E M B L Y I N S T R U C T I O N S Easy to install as a principle • User Manual All of this section is intended to ensure that the vertical magnetron can be assembled correctly and easily. - Page 9 Step 1 Open the plywood box, assemble support column and main frame, like below picture 1) Put cover on support column 2) Connect communication line, fix support column and main frame by screws, tight screws, combine covers Communication line connection...
- Page 10 Step 2 Assemble screen, connect communication, tight all screws Communication line connection...
- Page 11 Step 3 Assemble handle, connect heart rate line (left and right are same), tight all screws Heart rate line connection...
- Page 12 Step 4 Assemble bottle holder and handle protector, tight all screws...
- Page 13 Step 5 Assemble both pedal and seat 1) tight both pedal with M14 open-ended spanner 2) fix seat...
-
Page 14: Instrument Operation Guide
5 . I N S T R U M E N T O P E R A T I O N G U I D E Vertical magnetic control car LED display operating instructions The vertical bike magnetic control panel adopts the capacitive touch principle, Users only need to click it when they use it, Touch effects are comparable to mobile screens. - Page 15 2. "CALORIES" window: shows the calorie value of the exerciser, positive count 0.0 - 999.9 (KJ）； 3. “PULSE/SPEED” window: display the heart rate and speed of the athlete, and switch the time and distance interval 3S once; 4. "Central dot matrix display area window" This area is the WELCOME display area, program process map and resistance level, etc.
-
Page 16: Routine Maintenance
6 . R O U T I N E M A I N T E N A N C E 1. Clean everyday It is recommended that you clean the equipment before and after each training. To remove dust from the equipment, use a soft cloth to soak the following cleaning agent and then wipe all exposed surfaces. - Page 17 (4) Check whether the equipment is stationary on the floor. All supporting feet of the equipment should firmly touch the floor, and the equipment should not shake or shake when used. If not, please adjust it again. 4. Mobile equipment The equipment is very heavy.
-
Page 18: Explosion Map
7 . I N T E G R A L E X P L O S I O N C H A R T O F I N S T R U M E N T S A N D S P A R E P A R T S L I S T... -
Page 19: Parts List
8 . P A R T S L I S T ITEM SPECIFICATION AND NAME QUANTITY TZ04-2030-0100Frame Welding Group TZ04-2030-0200Pillar Welding Group TZ04-2030-0300Welding group for seat adjustment TZ04-2030-0400Seat Bracket Welding Group TZ04-2030-0700Hand Welding Group TZ04-7039-0800 Tension Wheel Welding Unit Ф16ＸФ9Ｘ1.0t-C1 Shim M10x8t-S2 Nut Ф9ＸФ4.5Ｘ1.0t-C1 Shim M4X10L-A1 Cross disk round head bolt... - Page 20 M6Spring washer Ф10ＸФ5.5Ｘ1.0t-C1 Shim M8 Spring washer TZ06-2030-0601 Left side shell TZ06-2030-0602 Right shell TZ06-2030-0603 Split shell TZ06-2030-0606 Handlebar Shell TZ06-2030-0607 crank disk TZ06-7037-0701 Display front case TZ06-7037-0702 Display back cover TZ06-7037-0703 Small support housing TZ06-2030-0604 Handle disassembly and assembling shells TZ06-2030-0605 Handlebar Shell Outside TZ10-2030-0002 Pedal crank Magnetron...
- Page 21 TZ02-2030-0006 Seat locking sheet metal 81 Plastic parts TZ06-7039-0615 Heart rate handle lower cover Crank cap trademark TZ21-2030-0016 Left side blue label TZ21-2030-0015 Left gray label 2 TZ21-2030-0014 Left gray label 1 TZ10-2030-0013 Central disk 067 Yellow handle TZ21-2030-0017 Right gray label 1 TZ21-2030-0018 Right gray label 2 TZ21-2030-0019 right side blue label Line card...
