FRENCH FITNESS SE420T RECUMBENT
SEATED ELLIPTICAL W/10" TOUCH CONSOLE
OWNER'S AND ASSEMBLY MANUAL
Before using this product, read all instructions in the document
provided with our exercise equipment,
including all assembly guides, user guides, and owner's
manuals, before installation of this device.
Advertisement
Table of Contents
Related Manuals for FRENCH FITNESS SE420T
Summary of Contents for FRENCH FITNESS SE420T
- Page 1 FF-SE420T FRENCH FITNESS SE420T RECUMBENT SEATED ELLIPTICAL W/10" TOUCH CONSOLE OWNER'S AND ASSEMBLY MANUAL Before using this product, read all instructions in the document provided with our exercise equipment, including all assembly guides, user guides, and owner's manuals, before installation of this device.
-
Page 2: Warranty
F E A T U R E S 10.1" LCD Touch Console • With built-in Bluetooth • WIFI supported console • With Heart Rate Sensor on handles on both sides • Multi-Grip Handlebars for arms workout • Step-through open area on both sides of the machine for easy access •... -
Page 3: Table Of Contents
T A B L E O F C O N T E N T S IMPORTANT SAFETY INSTRUCTIONS ........4 OTHER IMPORTANT SAFETY INSTRUCTIONS ..... 5 ASSEMBLY INSTRUCTIONS ........... 6 PARTS LIST ................7 EXPLODED VIEW ..............8 ASSEMBLY STEPS ..............9 CONSOLE DESCRIPTION-LED .......... -
Page 4: Important Safety Instructions
I M P O R T A N T S A F E T Y I N S T R U C T I O N S Save these instructions for future reference. Make sure all users see a physician for a complete physical examination before they begin any fitness program, particularly if they have high blood pressure, high cholesterol or heart disease;... -
Page 5: Other Important Safety Instructions
O T H E R I M P O R T A N T S A F E T Y I N S T R U C T I O N S • Keep equipment away from water and moisture. Avoid dropping anything on or spilling anything inside the equipment to prevent electric shock or damage to the electronics. -
Page 6: Assembly Instructions
A S S E M B L Y I N S T R U C T I O N S Always unplug the unit from the electrical outlet immediately DANGER! after using, before cleaning, performing maintenance and putting on or taking offparts. •... -
Page 7: Parts List
P A R T S L I S T Note: some of these parts may come pre-installed. Part No. DESC. Qty/Unit Main Frame Assembly Left Arm Assembly Right Arm Assembly Right Pedal Assembly Back Pad Back Pad Rear Cover Front Handle Cover Rear Handle Cover Bottle Holder Console Assembly... -
Page 8: Exploded View
E X P L O D E D V I E W 18 11 20 13 11 18... -
Page 9: Assembly Steps
A S S E M B L Y S T E P S Step 1 Remove the left and right handrails from the machine first. Remove the packing connecting frame group welding from the machine. Note, be careful of pinching hands and touching the plastic shell. - Page 10 A S S E M B L Y S T E P S Step 2 Rotate the upper support bracket group weld to the position shown in the illustration (note, be careful of pinching hands). Pass the communication cable through the upper support bracket. Pre-insert the upper support bracket into the main frame in the position shown in the picture (a person needs to hold it).
- Page 11 A S S E M B L Y S T E P S Step 3 The upper support frame group welding is completely inserted on the main unit and fixed with M10x16 bolts. Hexagon socket head cap screws M10x16-4pcs...
- Page 12 A S S E M B L Y S T E P S Step 4 Insert the right stirrup assembly into the main unit according to the position shown in the picture and bolt it in place. Right pedal assembly Hexagon socket cheese head bolts M6x15...
- Page 13 A S S E M B L Y S T E P S Step 5 Fix the cup holder with bolts as shown in the figure. Assemble the left and right large handrails and fix them with bolts according to the positions shown in the figure.
- Page 14 A S S E M B L Y S T E P S Step 6 1. Attach the front and back of the armrest decorative cover to the main unit as shown in the figure. 2. Fix with self-tapping screws, same for left and right sides. Armrest decorative shell front Armrest decorative shell rear Cross recessed tapping screws...
- Page 15 A S S E M B L Y S T E P S Step 7 First connect the communication line in the electronic watch assembly with the communication line of the main body, as shown in the figure. Assemble and install the electronic meter in the position shown in the figure and secure it with bolts.
- Page 16 A S S E M B L Y S T E P S Step 8 Fasten the back pad with bolts as shown in the figure. Align the back cushion shell and back cushion as shown in the figure and fix them with self-tapping screws.
- Page 17 A S S E M B L Y S T E P S Finished product...
-
Page 18: Console Description-Led
C O N S O L E D E S C R I P T I O N - L E D Display LED display console, show us following info rmation: Time(S): display from ”00:00-99:59” ; Default time for positive timing, Increment with each 1 second. Distance(Km): display from”0-99.9”... -
Page 19: Console Description-Tft
C O N S O L E D E S C R I P T I O N - T F T Display LED display console, show us following info rmation: Time(S): display from ”00:00-99:59” ; Default time for positive timing,Increment with each 1 second. Distance(Km): display from”0-99.9”... -
Page 20: Console Description
C O N S O L E D E S C R I P T I O N Number Name Details Blue(3seconds): Power On Breathing blue: Standby Flashing Blue: Searching bluetooth/ Logging into the system Green: System login succeeded light language Flashing Red(2sec): System login failed Yellow(60seconds): Pause state Blue(1Second):Cool Down... -
Page 21: Quick Start
O P E R A T I N G I N S T R U C T I O N S Quick start Press button, all data starts counting, The bottom line of display bright. display lights and intensity adjustment linkage; press buttons - + to adjust intensity, the data can be switched. -
Page 22: Exercise Instructions
E X E R C I S E I N S T R U C T I O N S Self-Editing program starting up • Button, display remind ”US M” fter the information finished, the Press first line of display is displayed. The first light flashes, setting with - +, each press 1lvl, or use numeric keypad to setting details, press to next step, when ，display... -
Page 23: Specification
M A I N T E N A N C E • To reduce the risk of electrical shock, always unplug the equipment from its power source before cleaning it or performing any maintenance tasks. • Cleaning console and screen •...
