User's Manual
IE-780862-NS-EM1
Emulation Board
Target Devices
µ
PD780862 Subseries
Document No. U16810EJ1V0UM00 (1st edition)
Date Published September 2003 N CP(K)
©
Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IE-780862-NS-EM1 and is the answer not in the manual?

Questions and answers

Related Manuals for NEC IE-780862-NS-EM1

Summary of Contents for NEC IE-780862-NS-EM1

  • Page 1 User’s Manual IE-780862-NS-EM1 Emulation Board Target Devices µ PD780862 Subseries Document No. U16810EJ1V0UM00 (1st edition) Date Published September 2003 N CP(K) © Printed in Japan...
  • Page 2 [MEMO] User’s Manual U16810EJ1V0UM...
  • Page 3 NEC Electronics does not assume any liability for infringement of patents, copyrights or other intellectual property rights of third parties by or arising from the use of NEC Electronics products listed in this document or any other liability arising from the use of such products. No license, express, implied or otherwise, is granted under any patents, copyrights or other intellectual property rights of NEC Electronics or others.

  • Page 4: Regional Information

    Regional Information Some information contained in this document may vary from country to country. Before using any NEC Electronics product in your application, pIease contact the NEC Electronics office in your country to obtain a list of authorized representatives and distributors. They will verify: •...
  • Page 5 PD780861, 780862, 78F0862 Target Readers This manual is intended for engineers who will use the IE-780862-NS-EM1 with the IE- 78K0-NS or IE-78K0-NS-A to perform system debugging. Engineers who use this manual are expected to be thoroughly familiar with the target device’s functions and use methods and to be knowledgeable about debugging.
  • Page 6 This refers to the combination of the in-circuit emulator (IE-78K0-NS or IE-78K0-NS-A) and the emulation board (IE-780862-NS-EM1). Emulation board This refers to the IE-780862-NS-EM1 (this product). Conventions Data significance: Higher digits on the left and lower digits on the right...

  • Page 7: Table Of Contents

    External Trigger ............................25 Jumper Setting of IE-78K0-NS ........................26 Jumper Setting of IE-78K0-NS-A....................... 26 Jumper Settings of IE-780862-NS-EM1 ....................27 Switch for Clock Monitor........................... 27 Emulation of POC and LVI Functions ...................... 27 CHAPTER 4 DIFFERENCES BETWEEN TARGET DEVICE AND TARGET INTERFACE CIRCUIT..28 APPENDIX A EMULATION PROBE PIN ASSIGNMENT TABLE............32...

  • Page 8: Chapter 1 General

    This chapter describes the IE-780862-NS-EM1’s system configuration and basic specifications. The IE-780862-NS-EM1 is a development tool for efficient debugging of hardware or software when using one of the following target devices that belong to the 78K/0 Series of 8-bit single-chip microcontrollers.

  • Page 9: System Configuration

    CHAPTER 1 GENERAL 1.1 System Configuration Figure 1-1 illustrates the IE-780862-NS-EM1’s system configuration. For the suitable probe conversion board, emulation probe, and conversion socket/conversion adapter, refer to Table 1-1. Figure 1-1. System Configuration Note 1 Debugger Device file ID78K0-NS (available separately)
  • Page 10 S××××DF780862: PD780862 Subseries The device file can be downloaded from the website of NEC Electronics (http://www.necel.com/micro/) 2. Emulation probes NP-30MC and NP-20GS are products of Naito Densei Machida Mfg. Co., Ltd. For further information, contact Naito Densei Machida Mfg. Co., Ltd. (TEL: +81-45-475-4191) 3.

  • Page 11: Hardware Configuration

    CHAPTER 1 GENERAL 1.2 Hardware Configuration Figures 1-2 and 1-3 show the IE-780862-NS-EM1’s position in the basic hardware configuration. Figure 1-2. Basic Hardware Configuration (When IE-78K0-NS Is Used) Dedicated bus interface IE system IE-78K0-NS IE-780862-NS-EM1 Interface board 78K0 main board...

  • Page 12: Basic Specifications

    CHAPTER 1 GENERAL 1.3 Basic Specifications The basic specifications of the IE-780862-NS-EM1 are listed in Table 1-2. Table 1-2. Basic Specifications Parameter Description µ Target device PD780862 Subseries System clock On-chip low-speed Ring-OSC: 240 kHz On-chip high-speed Ring-OSC: 8.0 MHz...

  • Page 13: Chapter 2 Part Names

    CHAPTER 2 PART NAMES This chapter introduces the parts of the IE-780862-NS-EM1 main unit. The packing box contains the emulation board (IE-780862-NS-EM1), probe conversion board, packing list, user’s manual, and guarantee card. If there are any missing or damaged items, please contact an NEC Electronics sales representative.

  • Page 14: Parts Of Main Unit

    CHAPTER 2 PART NAMES 2.1 Parts of Main Unit (1) IE-780862-NS-EM1 Part Names Figure 2-1. IE-780862-NS-EM1 Part Names Clock monitor switch POC RESET EXTOUT External trigger EXTIN Probe connector USER VDD Main system clock UMCLK (2) Probe conversion boards (two boards) Figure 2-2.

  • Page 15: Chapter 3 Installation

    CHAPTER 3 INSTALLATION This chapter describes methods for connecting the IE-780862-NS-EM1 to the IE-78K0-NS or IE-78K0-NS-A, emulation probe, etc. Mode setting methods are also described. Caution Connecting or removing components to or from the target system, or making switch or other setting changes must be carried out after the power supply to both the IE system and the target system has been switched OFF.

  • Page 16: Connection

    CHAPTER 3 INSTALLATION 3.1 Connection (1) Connection with IE-78K0-NS or IE-78K0-NS-A main unit See the IE-78K0-NS User’s Manual (U13731E) for a description of how to connect the IE-780862-NS-EM1 to the Note IE-78K0-NS Note When using the IE-78K0-NS-A, see the IE-78K0-NS-A User’s Manual (U14889E).

  • Page 17: Clock Settings

    CHAPTER 3 INSTALLATION 3.2 Clock Settings 3.2.1 Overview of clock settings The main system clock to be used during debugging can be selected from (1) to (4) below. (1) Clock that is already mounted on emulation board (2) Clock that is mounted by user (3) Pulse input from target system (4) On-chip Ring-OSC If the target system includes a clock oscillator, select either (1) Clock that is already mounted on emulation...
  • Page 18 (2) Clock that is mounted by user The user can mount any clock supported by the set specifications on the IE-780862-NS-EM1. This feature is effective when debugging at a different frequency than the clock already mounted. Remove the crystal oscillator (UMCLK) that is already mounted on the emulation board, and mount the parts board on which the resonator to be used is mounted or mount the oscillator to be used.
  • Page 19 CHAPTER 3 INSTALLATION (3) Pulse input from target system An external clock on the target system can be used via an emulation probe. Figure 3-5. When Supplying Pulse from Target System IE-78K0-NS or IE-78K0-NS-A Target system Emulation board UMCLK Emulation probe Mounted oscillator (not used) External clock (used)

  • Page 20: Main System Clock Settings

    Clock oscillator or external clock (not used) 3.2.2 Main system clock settings Table 3-1 shows the settings of the IE-780862-NS-EM1 when the main system clocks in (1) to (4) are used. Table 3-1. Main System Clock Settings Frequency of Main System Clock...
  • Page 21 (1) When using clock that is already mounted on emulation board When the IE-780862-NS-EM1 is shipped, a 10.0 MHz crystal oscillator is already mounted in the IE-780862-NS- EM1’s socket (UMCLK). When using the factory-set mode settings, there is no need to make any other hardware settings.

  • Page 22: Clock Out

    The sections enclosed in broken lines indicate parts that are attached to the parts board. <2> Prepare the IE-780862-NS-EM1. <3> Remove the crystal oscillator that is mounted in the IE-780862-NS-EM1’s socket (UMCLK). <4> Connect the parts board (from <1> above) to the socket (UMCLK) from which the crystal oscillator was removed (in <3>...
  • Page 23 Socket Pin No. CLOCK OUT CLOCK OUT <4> Install the IE-780862-NS-EM1 in the IE-78K0-NS or IE-78K0-NS-A. (3) When inputting pulse from target system No hardware settings are required for this situation. When starting the integrated debugger (ID78K0-NS), open the configuration dialog box and select “External” in the area (Clock) for selecting the CPU’s clock source (this selects the user’s clock).

  • Page 24: Mask Option Settings

    CHAPTER 3 INSTALLATION 3.3 Mask Option Settings The following mask options are provided in the IE-780862-NS-EM1. (1) LowspeedRing On-chip low-speed Ring-OSC clock oscillation (2) SystemClock High-speed system clock oscillation selection Open the Mask Option dialog box in the integrated debugger by selecting [Mask Option] on the [Option] menu to set the mask options.

  • Page 25: External Trigger

    CHAPTER 3 INSTALLATION 3.4 External Trigger To set an external trigger, connect the IE-780862-NS-EM1’s check pins EXTOUT and EXTIN as shown below. See the IE-78K0-NS User’s Manual (U13731E) or IE-78K0-NS-A User’s Manual (U14889E) for pin characteristics. For the use methods, see the ID78K Series Ver.2.30 or Later Operation Windows Based User’s Manual (U15185E).

  • Page 26: Jumper Setting Of Ie-78K0-Ns

    CHAPTER 3 INSTALLATION 3.5 Jumper Setting of IE-78K0-NS When using the IE-780862-NS-EM1 combined with the IE-78K0-NS, set the jumpers on the IE-78K0-NS as follows. For the locations of jumpers, refer to the IE-78K0-NS User’s Manual (U13731E). Caution Incorrect jumper setting may damage the IE-780862-NS-EM1.

  • Page 27: Jumper Settings Of Ie-780862-Ns-Em1

    3.9 Emulation of POC and LVI Functions When emulating the POC and LVI using the IE-780862-NS-EM1, supply a voltage of the same potential as the V pin of the emulation device to TP1, because POC and LVI supply voltage detection is performed via input from TP1 on the G-780009 BOARD of the IE-78K0-NS or IE-78K0-NS-A, not from the V pin of the target device.

  • Page 28: Chapter 4 Differences Between Target Device And Target Interface Circuit

    CHAPTER 4 DIFFERENCES BETWEEN TARGET DEVICE AND TARGET INTERFACE CIRCUIT This chapter describes differences between the target device’s signal lines and the signal lines of the target interface circuit of the IE system. The target interface circuit of the IE system realizes emulation via an emulation circuit configured by an emulation CPU, TTL, CMOS-IC, and other components.
  • Page 29 CHAPTER 4 DIFFERENCES BETWEEN TARGET DEVICE AND TARGET INTERFACE CIRCUIT µ (1) Signals input/output from the emulation CPU ( PD7880) The IE system circuit for the following signals is shown in Figure 4-1. • P02 to P00 • P23 to P20 •...
  • Page 30 CHAPTER 4 DIFFERENCES BETWEEN TARGET DEVICE AND TARGET INTERFACE CIRCUIT (3) Other signals The IE system circuits for the following signals are shown in Figures 4-3 and 4-4. • X1, X2, RESET, V , IC Figure 4-3. Equivalent Circuit of Emulation Circuit (3) •...
  • Page 31 CHAPTER 4 DIFFERENCES BETWEEN TARGET DEVICE AND TARGET INTERFACE CIRCUIT Figure 4-4. Equivalent Circuit of Emulation Circuit (4) • Probe side • IE system side (Target system) 3.3 kΩ 1.5 kΩ 10 kΩ Power supply detection µ PC393G OPEN User’s Manual U16810EJ1V0UM...

  • Page 32: Appendix A Emulation Probe Pin Assignment Table

    2. The numbers in the “Emulation probe” column indicate the corresponding pin number on the emulation probe tip. 3. The numbers in the IE-780862-NS-EM1 PROBE Board (20GS) CN1 column refer to the IE-780862- NS-EM1 PROBE Board (20GS) pin to be connected to the NP-20GS.
  • Page 33 2. The numbers in the “Emulation probe” column indicate the corresponding pin number on the emulation probe tip. 3. The numbers in the IE-780862-NS-EM1 PROBE Board (20MC) CN1 column refer to the IE-780862- NS-EM1 PROBE Board (20MC) pin to be connected to the NP-30MC.

  • Page 34: Appendix B Notes On Target System Design

    YQGUIDE Figure B-1. Distance Between In-Circuit Emulator and Conversion Adapter In-circuit emulator IE-78K0-NS or IE-78K0-NS-A Target system Emulation board 150 mm NP-30MC head PWB Emulation probe NP-30MC Conversion adapter YSPACK30BK, NSPACK20BK Conversion board IE-780862-NS-EM1 PROBE Board (20MC) User’s Manual U16810EJ1V0UM...
  • Page 35 APPENDIX B NOTES ON TARGET SYSTEM DESIGN Figure B-2. Connection Conditions of Target System Emulation board Emulation probe NP-30MC NP-30MC head PWB Guide pin YQGUIDE 13 mm Conversion adapter YSPACK30BK, NSPACK20BK 5 mm 15 mm 20 mm 37 mm 31 mm Target system User’s Manual U16810EJ1V0UM...
