Eaton Product Installation Manual
Emergency voice communication system
Version 1, Oct 2023
VoCALL 16 Digital EVCS – 8 Line Digital
to Analogue Exchange DAX8
Introduction
Eaton's VoCALL 16 is a high specification, digital, loop driven, intelligent emergency voice communication system
offering sophisticated functionality along with an intuitive user interface.
VoCALL 16 is designed to ensure the simplicity of future and legacy system expansion in conjunction with the
DAX8 our loop powered Digital to Analogue convertor.
The DAX8 analogue to digital exchange unit is a wall mounted interface designed to be distributed throughout a
site. This loop powered unit enables the connection of analogue outstations to a digital system.
Each DAX8 exchange unit is remotely powered from its host VoCALL 16 panel which can be an MX or NX variant,
standby battery backup is also supplied by the host panel. The DAX8 is wired on the outstation loop and can be
used in a mixed system in combination with our range of soft addressable digital outstations, up to a maximum
of 16 outstations per panel, either connected via the DAX8 or directly onto the digital loop.
The DAX8 in conjunction with our digital MX and NX panels has the capability to replace legacy VoCALL systems
sold previously by Eaton such as the CFVCX8 and VoCALL 9, retaining their existing wiring and outstations,
ensuring the maximum flexibility in takeovers, upgrades, and expansion of EVC systems
Note, the existing wiring must be in good condition and have been installed as specified by Eaton.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VoCALL 16 Digital EVCS and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton VoCALL 16 Digital EVCS

  • Page 1 The DAX8 in conjunction with our digital MX and NX panels has the capability to replace legacy VoCALL systems sold previously by Eaton such as the CFVCX8 and VoCALL 9, retaining their existing wiring and outstations, ensuring the maximum flexibility in takeovers, upgrades, and expansion of EVC systems...
  • Page 2 Corporation’s (“Eaton”) experience and judgment and may not cover all contingencies. If further information is required, an Eaton sales office should be consulted. Sale of the product shown in this literature is subject to the terms and condi- tions outlined in appropriate Eaton selling policies or other contractual agreement between Eaton and the purchaser.
  • Page 3: Table Of Contents

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Content Overview BENEFITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 PRODUCT OVERVIEW .
  • Page 4: Benefits

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Typer A Typer B Jack Plate Master System DAX8 Exchange unit Analogue Outstation Benefits Fault tolerant loop wired design from the digital panel to DAX8 • Simple radial connection of analogue devices •...
  • Page 5: Important Safety Information

    Eaton Fire System Products - DAX8 Installation Manual Version 1 OS 1 OS 2 OS 3 2 core Radial OS 8 MX16 DAX8 Keep field wiring Upgrade panels 4 core loop Keep outstations DAX8 2 core Radial OS 8 OS 3...
  • Page 6: Anti-Static Handling Guidelines

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Each exchange unit requires a 3A spur, returning to a breaker clearly marked EVCS DO NOT TURN OFF. If the units are distributed around a site, it is essential all units are on the same mains phase, as they are classified TEN 230V, powering from different phases can mean a 440V potential can be present in a unit during a major fault incident.
  • Page 7 Eaton Fire System Products - DAX8 Installation Manual Version 1 Step 2 Open M3X8 countersunk black four screws of sheet metal plate and remove M3X8 pan head PCB screw. Step 3 Wall mounting, use proper tool while mounting the enclosure on the wall.
  • Page 8 Eaton Fire System Products - DAX8 Installation Manual Version 1 Step 4 Remove knockouts as required (Do not remove knockouts while the circuit board is still fitted) Once the panel door has been removed, using a suitable screwdriver remove the PCBA and store it safely. this will avoid damage to the PCBA during the mounting and knockout removal process.
  • Page 9 Eaton Fire System Products - DAX8 Installation Manual Version 1 Step 6 Wiring, for wiring refer DAX8 Accessories connection details. Step 7 Assemble the unit, connect the ground cable to the front cover and reconnect the front cover by using hex key.
  • Page 10: Dax8 Accessories Connection Details

    Eaton Fire System Products - DAX8 Installation Manual Version 1 DAX8 Accessories Connection details Do not test wiring an insulation tester (Megger) will any equipement connected, as the 500 Volt test voltage will destroy these devices totally. WARNING You must observe local wiring regulations. Do not run SELV and LV cables in the same enclosure without adequate...
  • Page 11: Relay In Use

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Relay In use PFC OUT This in use relay is normally open and closes when a call is in progress. It is often used as an output to a fire system to disable sounders or sounder groups in the vicinity of the outstations connected to this DAX8.
  • Page 12: Dax8 Exchange Unit Switch Settings

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Connections at the DAX8 Connections at the outstation or EAA - VE - VE 1mm CSA FP200-2 Core Link - VE - VE Take care while connecting power and data wiring.
  • Page 13: System Configuration

    Eaton Fire System Products - DAX8 Installation Manual Version 1 System configuration Powering up the system Power On: Before Power On, ensure all wiring connections are correct and have been checked. Power up the system using mains power supply. Verify below LEDs are on...
  • Page 14: Set System Settings

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Set System settings Verify defaults Go to menu option ‘Install’. Press ‘Accept’ ENGINEER 2 (11-12) 7. Manage Users 8. Display Settings 9. System Time / Date 10. System Service Date 11.
  • Page 15: Operation

    Eaton Fire System Products - DAX8 Installation Manual Version 1 Operation VoCALL 16 allows calls to be made from analogue outstation to panel and vice versa. DAX8 exchange analogue to digital convertor allows the connection of existing analogue outstations to a digital system. A maximum of 8 analogue outstations of any combination can be connected to the DAX8 A call indication is reported to the receiving unit within 1 second of call initiation.
  • Page 16: Dax8 Visual Indications

    Eaton Fire System Products - DAX8 Installation Manual Version 1 DAX8 Visual Indications The DAX8 Exchange has the following indications- LED INDICATIONS COLOR INTERPRETATION Fault Indication Yellow General fault, Supply fault, Panel fault, Line fault Call Indication Power Up Red blinking...
  • Page 17 Eaton EMEA Headquarters Route de la Longeraie 7 1110 Morges, Switzerland Eaton.eu © 2024 Eaton All Rights Reserved Eaton is a registered trademark. Printed in XXX Document No. 25-17892-A All trademarks are property Oct 2023 of their respective owners.
