- Page 1 User Manual CL876 033C4719-EN...
-
Page 2: Table Of Contents
1.2 Wiring Diagram ..............02 consequences of its use. Spedal CL876 shall not be liable for any damage, injury, or legal liability caused by the direct or indirect use of this product. -
Page 3: Packaging & Product
1. Packaging & Product 1.1 Packing List ● Main Unit ● Bracket ● Camera (Optional) ● Wired Remote (Optional) ● Power Cable ● Tool Kit ● TPMS Service Pack (Optional) ※ The packaging content of this product may change without prior notice. -
Page 4: Wiring Diagram
1.2 Wiring Diagram Wired remote Not included in the packaging. Front cam Rear cam Extension Cable ※ ACC Power Supply : A power supply can be identified as being in the ACC state when the motorcycle’ s electrical switch Power is in the OFF position and the voltage is 0V, and when the switch is in the ON position, the voltage is between 11-14.4V. -
Page 5: Installation
2. Installation 2.1 Bracket Installation ① Align the screw holes of the elliptical metal plate on the bracket with the screw holes on the back of the main unit. Tighten the screws. ② Secure the bracket onto the motorcycle handlebar and tighten the screws. -
Page 6: Wired Remote (Optional) Installation
2.2 Wired Remote (Optional) Installation ① Peel off the backing paper of the semi-circular adhesive sticker and stick it above the curve of the A-shaped metal plate. Remove the other side of the protective paper and fix the A-shaped metal plate near the motorcycle handlebar. ②... -
Page 7: Camera (Optional) Installation
2.3 Camera (Optional) Installation 2.4 TF Card (Optional) Installation Open the bottom cover of the main unit and insert the TF card into ① Apply double-sided tape to the desired position (Please clean the surface of the object to be taped before sticking). the TF card slot. -
Page 8: Tire Pressure Sensor (Optional) Installation
2.5 Tire Pressure Sensor (Optional) Installation ① Enter the tire pressure binding interface and select the tire you want to bind. ② Install the tire pressure sensor on the corresponding tire. The installation steps are as follows: a. Remove the tire valve cap. b. -
Page 9: Features And Settings
3. Features and Settings 3.1 Home Screen Zone B Touch function status Android Auto status 12:00 TF card status Bluetooth connection status Apple CarPlay status Apple CarPlay Android Auto Zone C Front tire pressure status Rear tire pressure status Playback Audio Out Setting Zone D... -
Page 10: Apple Carplay
Wi-Fi SmartScreen On > 2.Only iPhone phones are supported. 2.Pair your iPhone to SmartScreen using 3.After successful connection, Bluetooth Bluetooth: Spedal-****** will be disconnected automatically Bluetooth On > 3.When iPhone prompt ”Use CarPlay with ”SmartScreen”? ”, select ”Use CarPlay” Mobile Data... - Page 11 ② Go to the "Bluetooth" menu and under the "OTHER DEVICES" list, ③ Wait for about 20-30 seconds, and your iPhone will display a select the Bluetooth named "Spedal-******". "Bluetooth Pairing Request" window. Select "Pair". Bluetooth < Settings Bluetooth Now discoverable as “X6”.
- Page 12 ④ Your iPhone will then prompt you with a "Use CarPlay with ⑤ Wait for a moment, and you will enter CarPlay mode. 'SmartScreen'?" window. Select "Use CarPlay". ※ Note: ● Please make sure your iPhone supports Apple CarPlay. For more details, please visit: https://www.apple.com/ios/car- play/ ●...
-
Page 13: Android Auto
Android 11 or higher and 5GHz Wi-Fi Assistant, recent apps, default apps 2.Pair your phone to SmartScreen using 2.Please download the latest Android Auto Notifications Bluetooth: Spedal-****** application on your phone Notification history, conversations Battery 32% - About 12 hrs, 4 mins left Storage 24% used - 97.59 GB free... -
Page 14: Connected Devices
② Tap on the "Bluetooth" menu to access the Bluetooth search ④ From the list of Available devices, select the Bluetooth named page. "Spedal-******". ③ Click on "Pair new device". Connected devices Pair new device Device name + Pair new device... - Page 15 ⑤ Wait for about 20 seconds, and your phone will display a "Pair ⑥ Wait for a moment, and you will enter Android Auto mode. with Spedal-******" window. Select "Pair". ※ Note: ● Please make sure your phone is running on Android 11 or above and supports 5GHz Wi-Fi and Google Play services.
-
Page 16: Dvr
3.4 DVR Click on on the main screen to enter the DVR mode. 01:30 12:00 Zone A Video recording duration Take a photo of the current frame 01:30 Start Recording Enter playback mode Stop Recording Record with audio Unlock the current recording Record without audio Lock the current recording Switch between front and rear camera view... -
Page 17: Playback
3.5 Playback Zone B Click on on the main screen to enter the Playback mode. Sort videos from newest to oldest Sort videos from oldest to newest 12:00 View locked videos xxxx-xxxxx.TS View photos xxxx-xxxxx_SOS.TS xxxx-xxxxx.JPG xxxx-xxxxx.TS Video files xxxx-xxxxx_SOS.TS Lock video files 00:00:00/00:00:00 xxxx-xxxxx.JPG... -
Page 18: Audio Output
3.6 Audio Output ④ In the pop-up prompt, click on "Connect" and wait for the pairing process between the main unit and the Bluetooth headset to complete. Click on on the main screen to enter the audio output mode. ⑤ The Bluetooth headset name will display "Connected" indicating a successful connection. -
Page 19: Setting
3.7 Setting Screen saver To set the auto-close time for the screen when there is no Click on on the main screen to enter the setting mode. touch input, you can choose between the following options: Off, 10 seconds, 30 seconds, or 1 minute. Language 12:00 To set the system display language, you can choose from... -
Page 20: Tire Pressure Monitoring Settings
3.8 Tire Pressure Monitoring Settings ● TPMS 1 Display the front tire pressure value. Click on Zone C on the main screen to enter the Tire Pressure Moni- toring Settings mode. ● TPMS 2 Display the rear tire pressure value. 12:00 ●... -
Page 21: Firmware Upgrade
3.9 Firmware Upgrade ③ Power off the device and remove the TF card. ④ Open the computer and visit the Spedal official website's down- 3.9.1 OTA Upgrade load page. Download the latest firmware according to the model. ⑤ Copy the downloaded firmware onto the TF card. - Page 22 3.9.2 Burn TF Card Upgrade ● TF card burning ① Open the computer and visit the Spedal official website's down- load page. Download the latest firmware according to the model. ● Preparation ② Download the TF card burning tool, PhoenixCard, and run the ①...
- Page 23 ● Main unit firmware upgrade ● Check firmware ① Insert the TF card into the main unit and power it on. ① Insert the TF card into the main unit and power it on. ② The main unit will start the upgrade automatically upon powering ②...
- Page 24 For any questions please contact support@spedaltech.com...
