- Page 1 User Manual CL871 061C4B08-EN...
-
Page 2: Table Of Contents
1.2 Wiring Diagram ..............02 consequences of its use. Spedal CL871 shall not be liable for any damage, injury, or legal liability caused by the direct or indirect use of this product. -
Page 3: Packaging & Product
1. Packaging & Product 1.1 Packing List ● Main Unit ● Bracket ● Tool Kit ● TPMS Service Pack(Optional) ● Power Cable ※ The packaging content of this product may change without prior notice. -
Page 4: Wiring Diagram
1.2 Wiring Diagram Power Black wire: connected to the negative pole of the power supply or GND. Yellow wire: connected to the positive pole of the power supply. Red wire: ACC power. ※ ACC Power Supply : A power supply can be identified as being in the ACC state when the motorcycle’... -
Page 5: Installation
2. Installation 2.1 Bracket Installation ① Align the screw holes of the rectangle metal plate on the bracket with the screw holes on the back of the main unit. Tighten the screws. ② Secure the bracket onto the motorcycle handlebar and tighten the screws. -
Page 6: Tire Pressure Sensor (Optional) Installation
2.2 Tire Pressure Sensor (Optional) Installation ① Enter the tire pressure binding interface and select the tire you want to bind. ② Install the tire pressure sensor on the corresponding tire. The installation steps are as follows: a. Remove the tire valve cap. b. -
Page 7: Features And Settings
3. Features and Settings 3.1 Home Screen 2024-11-15 Friday 10:30 CarPlay Android Auto Screen off Settings No Connected No Connected ① Display date, week, and time in sequence ② Enter the Apple CarPlay screen mirroring mode ③ Enter the Android Auto screen mirroring mode ④... -
Page 8: Apple Carplay
3.2 Apple CarPlay ① Go to the "Settings" menu on your iPhone and enable Bluetooth and Wi-Fi. Click on on the main screen to enter the Apple CarPlay mode. Settings CarPlay Connection Help 1.Carplay can be enabled after connecting the Bluetooth of this device. - Page 9 ② Go to the "Bluetooth" menu and under the "OTHER DEVICES" list, ③ Wait for about 20-30 seconds, and your iPhone will display a select the Bluetooth named "BLINK-****". "Bluetooth Pairing Request" window. Select "Pair". Bluetooth < Settings Bluetooth Now discoverable as “X6”. Bluetooth Pairing Request MY DEVICES ******...
- Page 10 ④ Your iPhone will then prompt you with a "Use CarPlay with ⑤ Wait for a moment, and you will enter CarPlay mode. 'SmartScreen'?" window. Select "Use CarPlay". ※ Note: ● Please make sure your iPhone supports Apple CarPlay. For more details, please visit: https://www.apple.com/ios/car- play/ ●...
-
Page 11: Android Auto
3.3 Android Auto ① Go to the "Settings" menu on your phone and enable Bluetooth and Wi-Fi. Click on on the main screen to enter the Android Auto mode. Settings Android Auto Connection Help 1.Android Auto can be enabled after connecting the Bluetooth of this device. -
Page 12: Connected Devices
② Tap on the "Bluetooth" menu to access the Bluetooth search ④ From the list of Available devices, select the Bluetooth named page. "BLINK-******". ③ Click on "Pair new device". Connected devices Pair new device Device name + Pair new device Pixel 5 Available devices Previously connected devices... - Page 13 ⑤ Wait for about 20 seconds, and your phone will display a "Pair ⑥ Wait for a moment, and you will enter Android Auto mode. with BLINK-****" window. Select "Pair". ※ Note: ● Please make sure your phone is running on Android 11 or above and supports 5GHz Wi-Fi and Google Play services.
-
Page 14: Setting
3.4 Setting Click on on the main screen to enter the setting mode. General System Theme About The theme can be set to night, day, and automatic. View the current device model, serial number, and version number. Language Boot Logo To set the system display language, you can choose from the Customizable startup logo. -
Page 15: Tire Pressure Monitoring Settings
3.5 Tire Pressure Monitoring Settings Click on on the main screen to enter the Tire Pressure Monitor- ● Front Wheel ing Settings mode. （You need to enable it in the settings first） Click "Unpired" on the Front Wheel to start pairing the front tire pres- sure sensor. -
Page 16: Firmware Upgrade
3.6 Firmware Upgrade Turn on the device and enter the following menu Menu path: Settings / System / About / OTA upgrade 1. Download installation package 2. Connect your phone to WiFi 1.1 Download Method 1(Scan QR code) WiFi name: blink_wifi_**** Open the browser on your phone, find the "Scan QR Code"... - Page 17 For any questions please contact support@spedaltech.com...
