Spedal L300 Manual

L300 motorcycle intelligent car machine manual
Thanks for your purchase of our products!
In order to protect your rights and interests, please read the instructions carefully before using the company's products, so
that you can use the machine correctly and safely. After reading, please keep it properly for future reference.
Safety Warning
In order to ensure the personal safety of you, your vehicle and others, please be sure to meet the following basic requirements:
Before using this product, please read all relevant instructions carefully, if the damage caused by failure to follow the instruc-
tions, you will not be entitled to the warranty.
In order to ensure driving safety and avoid violating traffic laws and regulations, please do not watch programs and operate
the machine while driving.
To prevent short circuits, please do not place any metal objects (such as coins or metal tools) in the equipment. Please use the
machine according to this manual. Do not open the machine for maintenance by yourself. If you need maintenance, please
contact professional technicians.
Note: Remember to power off before installation, do not rinse directly with high pressure water gun.
Wiring Diagram
BLACK LINE:Ground wire.
e r y
B a t t
YELLOW LINE: Connect to the
constant power supply of the
power box.
RED LINE: Connect to ACC
power (only powered when
the ignition switch is turned
on).
Power Interface
