- Page 1 Smart Toilet Installation&Operation manual Thank you for purchasing our product Please read the Manual before using your product and keep it in a safe place for future reference...
-
Page 2: Table Of Contents
C a t a l o g u e TC���-��� series Functions Attention Female washing Hip washing Packing list Mobile washing Washing Product description Cold and hot washing Water temperature adjustable Air pump pressure boost Medicine wash Precautions before installation Seat temperature adjustment Install the toilet Seating induction... -
Page 3: Attention
Warning At te n t i o n 1. Please read manual carefully and use it correctly. The cautions listed here are important Do not spray: Do not pour water or Do not disassemble: Absolutely do not contents, which must be followed. disassemble, repair or transform the product detergent on the product or power by yourself. - Page 4 Warning Warning Please use tap water or potable well Do not twist or break the inlet Do not hit the ceramics with gravity Do not use at 0℃ or below. pipe. to prevent leakage from damage. Below 0℃, please refer to the instruc- water.
- Page 5 Warning Warning Do not damage the power cord. In case of thunder, disconnect the When the toilet is blocked, the power 1. No damage, no processing, no heating; plug from the socket. must be turned off, in case the sewage 2, do not bend, do not curl, do not pull;...
-
Page 6: Packing List
Packing List Product Descr iption - Exter nal Dimensions Foam shield components Toliet Filter element assembly Cotton-pad 305/400mm Instructions Warranty card (Attached to the manual) Install Cardboard Remote Control Unit：mm Water Valve Seal Sludge * Please replace the valve before installation... -
Page 7: Precautions Before Installation
Precautions before Installation Product Descr iption - Par t Name Confirm Minimum Necessary Water Pressure Minimum essential water pressure: 0.06mpa (1kgf/cm), flow ≥9.5L/min.If the pressure is not met.The product can not working properly.(If there is no hydrostatic test device, please refer to the drawing.) Pipe Open the Angle valve, water for 10 Safety Instructions... -
Page 8: Install The Toilet
Install Toilet Component assembly Installation steps (1) Install the valve in the suitable position (4) According to the ceramic contour of the Foam shield components installation of the wall toilet into the corresponding position Find the foam shield set from the accessory box and unscrew the lid Unscrew the lid Assembly the foam shield into the body as shown... -
Page 9: Install Remote Control
Install remote control Post-installation inspection 1. Open the valve Installation location: The figure shows the recommended installation location for the remote control. The installation location can be selected according to the actual use Open the valve a little bit,observe whether there is at home. -
Page 10: Function Description
Function Description Other function description Washing function Other Functions 1.Female / hip cleaning function 1. Water temperature protection function If the water temperature exceeds 43 ℃ during use，it will automatically switch to continuous ① self-cleaning mode and give out an alarm; ②At this time, the power supply must be reconnected before normal use. -
Page 11: Cleaning And Maintenance
Cleaning and maintenance Function Description-Remote Control Instructions 1. Maintenance of ontology The detachable accessories can be removed before maintenance MASSAGE Note before maintenance: FLUSH BUBLE SHIELD DEODORIZER MEDICATED WASH (1)Make sure the power supply is disconnected. (2) Do not let water enter the product during the maintenance INDICATOR LIGHT STOP NOZZLE POSITION WATER PRESSURE... -
Page 12: Fault Analysis And Treatment
Fault analysis and treatment Fault analysis and treatment Failures Confirmation Confirmation Failures Confirmation Solution Confirm whether cloth covers, Confirm whether the seat ring cushions, etc. are used on the Please remove cloth covers, cushions Reset the seat temperature through temperature is set in low level seat ring sensing area The seat ring and other items... -
Page 13: Technical Parameters
Product Technical Parameters Product Environmental infor mation Items TC105-326 Harmful substances Rated Voltage 220V ~ , 50Hz Part name Rated Power* 1050W Max. Instantaneous Power 1760W PCBA Plastic parts Power Cord Length 1.5m The motor 0.1 ~ 0.75MPa (static pressure); requirements for min. dynamic Water Supply Pressure pressure: 0.06MPa Others... -
Page 14: Warranty Card
Warranty Card Maintenance record To Dear Customers: Thank you for choosing our toilet! If any problem occurs during use, Maintenance record please simply check the problems pursuant to the user's manual. When you cannot solve such problems, contact your local supplier or call the Date Maintenance projects Maintenance department...
