Karat CEDAR K-31147X Quick Start Manual

Two-piece toilet with seat

Advertisement

Quick Links

Features
• Vitreous china
• Elongated bowl
• Includes gentle close seat
• Includes polished chrome trip lever
• Siphonic wash-down flushing system
• 3.75 liter per flush
• 305 mm rough-in for S-trap
• 702 x 374 x 762 mm
Codes/Standards Applicable
Specified model meets or exceeds the following:
• ASME A112.19.2/CSA B45.1
• TIS 792-2554
Technical Information
Fixture:
Configuration
Water per flush
Passageway
Water area
Water depth from rim
Seat post hole centers
Specified Model
Model
Description
K-31147X-S
Cedar two-piece toilet, S-trap with elongated gentle close seat
Dimensions are approximate.
Unit: mm
702
13
184
305
Note: The recommended dimension for installation can be adjusted according to user preferences and layout.
Page 1/2
1363727-X4-A
two-piece, elongated
3.75 liter
51 mm
140 x 117 mm
201 mm
140 mm
140
1/2" Supply
380
200
C L of Outlet
Product Diagram
TWO-PIECE TOILET WITH SEAT
Included Components:
Bowl
Tank
Tank cover
Elongated gentle close seat
Installation Notes
Install this product according to the installation guide.
470
376
282
350
374
762
130
CEDAR
K-31147X
K-17286K
K-20985X-LT
1340773-SP
K-98101X
Color/Finished
WK: Diamond White
Front of bowl
358
158
265
Call Center: 0-2700-9299
kohler.com
