- Page 1 USE AND MAINTENANCE MANUAL Pag. 1 di 16 FHP SERIES BATTERIES USE AND MAINTENANCE MANUAL FHP SERIES BATTERIES Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
- Page 2 USE AND MAINTENANCE MANUAL Pag. 2 di 16 FHP SERIES BATTERIES Please read all instructions in this manual carefully before proceeding with installation. And please keep the manual for reference during operation. Overcharging and short-circuiting the battery is prohibited. Please do not attempt to disassemble the battery if some abnormal phenomena happen.
-
Page 3: Table Of Contents
USE AND MAINTENANCE MANUAL Pag. 3 di 16 FHP SERIES BATTERIES Index 1. BRIEF INTRODUCTION ......................4 2. TECHNICAL FEATURES ......................6 3. HOLDING TEMPERATURE AND VOLTAGE ................. 8 4. INSTALLATION ..........................9 5. OPERATION ..........................10 6. STORAGE ............................13 7. -
Page 4: Brief Introduction
Extremely equalized trickle charge. A single and homogeneous manufacturing procedure ensures a homogeneous holding voltage to extend the life of the FHP series, FAAM HIGH PERFORMANCE accumulator. Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024... - Page 5 USE AND MAINTENANCE MANUAL Pag. 5 di 16 FHP SERIES BATTERIES Fig. 1 Image of a battery from the FHP family Identification F H P × × ××× Capacity in 20 hours (or 10 hours) PERFORMANCE HIGH FAAM Property of FIB S.p.A. - Use reserved for its intended purpose.
-
Page 6: Technical Features
USE AND MAINTENANCE MANUAL Pag. 6 di 16 FHP SERIES BATTERIES 2. Technical features Capacities and influencing factors: Battery capacity The unit of measurement for capacity is ampere hours, abbreviated as Ah. Capacity can be expressed in terms of nominal capacity or actual capacity. Actual capacity is the product of the discharge current times the actual discharge time, the unit is Ah. - Page 7 USE AND MAINTENANCE MANUAL Pag. 7 di 16 FHP SERIES BATTERIES Temperature Temperature affects battery capacity. Fig. 3 is the available capacity curve as a function of the ambient temperature. If the ambient temperature is not 20°C, you need to change the measured capacity to with the actual capacity at 20°C according to the following formula:...
-
Page 8: Holding Temperature And Voltage
PbSO4, reduce the capacity, and also the battery life. At 20°C, if the float voltage is 2.27±0.02V/cell, the standby life of FAAM FHP series batteries is > 10-12 years, in accordance with the Eurobat Guide. -
Page 9: Installation
USE AND MAINTENANCE MANUAL Pag. 9 di 16 FHP SERIES BATTERIES 4. Installation Installation Precautions The customer can adopt flexible installation methods according to the conditions of the installation site. However, detailed installation requirements must be submitted when ordering, so that the best possible connection diagram can be adopted, and the installation diagram can be provided. -
Page 10: Operation
2.23 Equalization charge FAAM FHP Series batteries must be equalized if you are in any of the following conditions: — After the system is installed. — Maintenance every three months if the voltage of at least two batteries is below 2.23V/cell. - Page 11 USE AND MAINTENANCE MANUAL Pag. 11 di 16 FHP SERIES BATTERIES The suggested method for equalization charging is as follows: Charge with 2.35V–2.40V/El for 24 h. Note: The above charging indications are for temperatures between 20 and 30°C. If the temperature is lower, it is advisable to increase the charging time, on the contrary decrease the time if the...
- Page 12 USE AND MAINTENANCE MANUAL Pag. 12 di 16 FHP SERIES BATTERIES Fig. 4: Charging characteristic of a 100% discharge FHP12-100 battery with current limited to 0.1C voltage limited to 10A and 2.35V/Cell (25°C) Charging Charging Voltage Capacity Current (A) Per Cell...
-
Page 13: Storage
During storage, please note that: — The self-discharge rate is related to the ambient temperature. The degree of self-discharge is lower when the ambient temperature is lower. The ambient storage temperature of FAAM FHP series batteries ranges from 0°C to 35°C. -
Page 14: Quarterly Maintenance
7. Maintenance To ensure the expected life, batteries must be properly inspected and maintained. For the maintenance methods of the FAAM FMR series batteries the following is recommended: Monthly maintenance: — Implement the check in the summary sheet every month. - Page 15 USE AND MAINTENANCE MANUAL Pag. 15 di 16 FHP SERIES BATTERIES Triennial maintenance: — Perform a capability test, once every three years and once a year after the "six years" operation. If the battery capacity is less than 80% of the rated capacity, the battery must be replaced.
- Page 16 USE AND MAINTENANCE MANUAL Pag. 16 di 16 FHP SERIES BATTERIES 8. Electrolyte Volume Indications (Ministerial Decree Environment No. 20 of 24.11.2011) In all battery rooms, sufficient absorbent and neutralizing substance must always be kept available to completely extinguish all the electrolyte contained in at least two elements of the battery, for each battery installed.
