- Page 1 USE AND MAINTENANCE MANUAL Pag. 1 of 14 HPS SERIES BATTERIES USE AND MAINTENANCE MANUAL HPS SERIES BATTERIES Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
- Page 2 USE AND MAINTENANCE MANUAL Pag. 2 of 14 HPS SERIES BATTERIES Please read all instructions in this manual carefully before proceeding with installation. Please also keep the manual for reference during the battery life. Overcharging and short-circuiting the battery is prohibited. Please do not attempt to disassemble the battery if abnormal phenomena occur.
-
Page 3: Table Of Contents
USE AND MAINTENANCE MANUAL Pag. 3 of 14 HPS SERIES BATTERIES Index 1. Brief Introduction ............................4 2. Directions ..............................5 3. Temperature ............................... 8 4. Installation ..............................8 5. Operativity ..............................9 6. Storage ............................... 11 7. Maintenance .............................. 12 8. -
Page 4: Brief Introduction
1. Brief Introduction Basic Features FAAM S.p.A. has developed the HIGH-PERFORMANCE SOLAR (HPS) series. These are flooded 2V free-acid stationary elements that cover a capacity range from 320Ah/10 hours up to 1050Ah/10 hours in compliance with IEC 60896-11. These batteries have a wide range of applications: telecommunications, railways, UPS units, emergency systems, use in wind and photovoltaic plants, nuclear power plants, power generation systems, etc. -
Page 5: Directions
USE AND MAINTENANCE MANUAL Pag. 5 of 14 HPS SERIES BATTERIES HPS Series Code Weight N° (kg) Poly 4HPS320 20,0 5HPS400 24,6 6HPS480 29,2 7HPS560 33,8 6HPS630 35,3 7HPS735 40,8 8HPS840 46,4 9HPS945 52,4 10HPS1050 58,0 This table shows the codes, weights, and number of poles of each HPS element 2. - Page 6 USE AND MAINTENANCE MANUAL Pag. 6 of 14 HPS SERIES BATTERIES Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
- Page 7 USE AND MAINTENANCE MANUAL Pag. 7 of 14 HPS SERIES BATTERIES Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
-
Page 8: Temperature
The best operating temperature for FAAM HPS series batteries is 20°C. At a temperature of 20°C, FAAM batteries can be discharged to 100% of their rated capacity. If the ambient temperature is different from the indicated value, you can operate in the following ways: Operate at room temperature, using an air conditioning system, increasing ventilation (natural or forced) or changing the position of the accumulators. -
Page 9: Operativity
Maintenance operations • FAAM HPS series batteries can be used both cyclically and in float mode. Use as maintenance is where the best performance is achieved. Batteries are always in full charge and last longer under these conditions. When using in buffer, adjust the voltage to room temperature... -
Page 10: Equalization Charge
HPS SERIES BATTERIES Equalization charge Batteries tend to lose charge during transport and during long periods of storage. FAAM HPS Series batteries must be subjected to equalization charging if the following conditions are met: - After the system is installed, the batteries need additional charging. -
Page 11: Storage
— The self-discharge rate is related to the ambient temperature. The degree of self-discharge is lower when the ambient temperature is lower. The ambient storage temperature of FAAM HPS series batteries ranges from 0°C to 35°C. The storage location must be clean, ventilated, and dry. -
Page 12: Maintenance
7. Maintenance To ensure the expected life, batteries must be properly inspected and maintained. For the maintenance methods of the FAAM FMR series batteries the following is recommended: Monthly maintenance: — Implement the check in the summary sheet every month. - Page 13 USE AND MAINTENANCE MANUAL Pag. 13 of 14 HPS SERIES BATTERIES Triennial maintenance: — Perform a capability test, once every three years and once a year after the "six years" operation. If the battery capacity is less than 80% of the rated capacity, the battery must be replaced.
-
Page 14: Electrolyte Volume Indications (Ministerial Decree Environment N°20 Of 24.11.2011)
USE AND MAINTENANCE MANUAL Pag. 14 of 14 HPS SERIES BATTERIES 8. Electrolyte volume indications (Ministerial Decree Environment n°20 of 24.11.2011) In all battery rooms, enough absorbing and neutralizing substances must always be kept available to completely extinguish all the electrolyte contained in at least two battery elements, for each battery installed.
