- Page 1 USE AND MAINTENANCE MANUAL Pag. 1 of 18 STA-STAM SERIES BATTERIES USE AND MAINTENANCE MANUAL STA-STAM SERIES BATTERIES Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
- Page 2 USE AND MAINTENANCE MANUAL Pag. 2 of 18 STA-STAM SERIES BATTERIES Please read all instructions in this manual carefully before proceeding with installation. And please keep the manual for your reference during operations. Overcharging the battery for a short time is prohibited and short circuits are avoided. Please do not attempt to disassemble the battery if abnormal phenomena occur.
-
Page 3: Table Of Contents
USE AND MAINTENANCE MANUAL Pag. 3 of 18 STA-STAM SERIES BATTERIES Index 1. Brief Introduction ............................4 2. Specifications .............................. 6 3. Temperature ............................. 12 4. Installation ..............................12 5. Operativity ..............................13 6. Storage ............................... 15 7. Maintenance .............................. 16 8. -
Page 4: Brief Introduction
1. Brief Introduction Basic Features FIB S.p.A has developed the STA series and the series with STAM oversized plates. These are stationary free acid 2V OPzS flooded elements known as open vessels. The two ranges cover a range of capacities ranging from 100Ah/10 hours up to 3500Ah/10 hours in accordance with the CEI IEC 60896-11 standard. - Page 5 USE AND MAINTENANCE MANUAL Pag. 5 of 18 STA-STAM SERIES BATTERIES Fig. 1 Image of an element of the STA-STAM family Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
-
Page 6: Specifications
USE AND MAINTENANCE MANUAL Pag. 6 of 18 STA-STAM SERIES BATTERIES STA Series STAM 2V Code Type Weight N° Code Type Weight N° STAM OPZS (Kg) Poly OPZS (Kg) Poly 2STA55 2OPzS100 13,8 2STAM56 3STA55 3OPzS150 16,3 2OPzS108 13,8 4STA55... - Page 7 USE AND MAINTENANCE MANUAL Pag. 7 of 18 STA-STAM SERIES BATTERIES Factors Affecting Rated Capacity The actual capacity is mainly related to the positive and negative matter and the utilization rate. The utilization rate of the elements is mainly influenced by the depth of discharge, the structure of the battery, and the manufacturing technology.
- Page 8 USE AND MAINTENANCE MANUAL Pag. 8 of 18 STA-STAM SERIES BATTERIES Temperature Temperature affects battery capacity. Figure 3 is the available capacity curve as a function of ambient temperature. If the ambient temperature is not 20°C, you need to change the measured capacity to the actual capacity at 20°C according to the following formula: Ce = CT /(1 + K (T-20)) T = Ambient temperature...
- Page 9 USE AND MAINTENANCE MANUAL Pag. 9 of 18 STA-STAM SERIES BATTERIES Fig 4: No. of cycles as a function of depth of discharge DOD Fig 5: No. of cycles as a function of % of discharge at various operating temperatures Property of FIB S.p.A.
- Page 10 USE AND MAINTENANCE MANUAL Pag. 10 of 18 STA-STAM SERIES BATTERIES Fig 6: Number of years of life at operating temperature Fig 7: Example of a work cap Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 – 18/08/2024...
- Page 11 USE AND MAINTENANCE MANUAL Pag. 11 of 18 STA-STAM SERIES BATTERIES Fig 8: Drawings of the various connection slats between elements: the distance to be respected between the elements in assembly trim is 10mm. Copper connections, plastic coating Property of FIB S.p.A. - Use reserved for its intended purpose. Rev.0 –...
-
Page 12: Temperature
The best operating temperature for FAAM STA-STAM series batteries is 20°C. At a temperature of 20°C, FAAM batteries can be discharged to 100% of their rated capacity. If the ambient temperature is different from the indicated value, you can operate in the following ways: —... -
Page 13: Operativity
+45°C. The best ambient temperature is 20°C Maintenance operation FAAM STA series and STAM series batteries can be used both cyclically and in maintenance. Use as maintenance is where the best performance is achieved. The batteries are always in the condition of maximum charge and in these conditions they last longer. - Page 14 Pag. 14 of 18 STA-STAM SERIES BATTERIES Equalization charge Batteries tend to lose charge during transport as well as during long periods of storage. FAAM STA- STAM series batteries must be subjected to equalization charging if the following conditions are met: - After the system is installed, the batteries need an additional charge.
-
Page 15: Storage
— The rate of self-discharge is correlated with the ambient temperature. The degree of self- discharge is lower when the ambient temperature is lower, otherwise it increases. The ambient storage temperature of FAAM STA-STAM series batteries ranges from 0°C to 35°C. The storage location should be clean, ventilated, and dry. The recommended temperature is between 10°C and 30°C. -
Page 16: Maintenance
STA-STAM SERIES BATTERIES 7. Maintenance To ensure expected life, batteries must be properly inspected and maintained. For the maintenance methods of the FAAM STA-STAM series batteries, the following is recommended: Monthly maintenance: — Implement the check in the summary sheet every month. - Page 17 USE AND MAINTENANCE MANUAL Pag. 17 of 18 STA-STAM SERIES BATTERIES Annual maintenance: — Repeat quarterly maintenance and inspection. — Check whether the connectors are loose or not every year. — Carry out a discharge test every year to verify the exact load, discharging 30-40% of the rated capacity.
-
Page 18: Electrolyte Volume Indications (Ministerial Decree Environment N°20 Of 24.11.2011)
USE AND MAINTENANCE MANUAL Pag. 18 of 18 STA-STAM SERIES BATTERIES 8. Electrolyte Volume Indications (Ministerial Decree Environment n°20 of 24.11.2011) In all battery rooms, sufficient absorbent and neutralizing substance must always be kept available to completely extinguish all the electrolyte contained in at least two elements of the battery, for each battery installed.
