Control Panel

WARNINg!
B E F O R E P E R F O R M I N G
O P E R A T I O N T E S T , R E A D T H I S
MANUAL CAREFULLY AND ACQUIRE
A GOOD KNOWLEDGE OF THE
CONTROL FUNCTIONS.
() ReFRIGeRANT SuCTIoN PReSSuRe
GAuGe
() SToP - RuNNING buTToN – DooR
bloCk
() GReeN INDICAToR oF volTAGe -
RuNNING
(4) ReD AlARm INDICAToR FoR:
- HIGH PReSSuRe
- FAN moToR PRoTeCTIoN

Intended Use

QPNC dryers are designed to dry
compressed air for industrial use.
QPNC air dryers cannot be used in
applications where there is a risk of
fire, explosion or where work is carried
out which releases substances into the
environment which are dangerous with
regard to safety (for example: solvents,
inflammable vapors, alcohol, etc.).
To provide safe, breathable air, a
compressor must be capable of producing
at least Grade D breathing air as
described in Compressed Gas Association
Commodity Specification G7l.-966.
Special filtering, purifying and associated
alarm equipment must be used to convert
compressed air to "breathing Air". other
special precautions must also be taken.
T H E
Quincy Compressor-QPNC Refrigerated Air Dryers
Section II - Description
(1)
(2)
(3)
(4)
WARNINg!
If this unit is used to produce breathing
air, special equipment and precautions
expressed in OSHA 29 CFR 1910.134
for specifications of the necessary
equipment and special precautions
to make "Breathing Air" MUST BE
used or any warranties are VOID and
manufacturer disclaims any liability
whatsoever for loss, personal injury or
damage.
This dryer must be used only for the
purpose for which it was specifically
designed.
The manufacturer cannot be held
responsible for any damage resulting from
improper, incorrect or unreasonable use.
