Install a CSG300 Series Appliance

This article provides instructions about how to unpack a CSG300 series appliance and how to mount a CSG355 or

CSG365 appliance in a 19-inch rack.

Unpack a CSG300 Series Appliance

The CSG300 series appliance is packed in a plastic box, and it is shipped in a cardboard carton, secured with foam

packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only

when you are ready to install it.

To unpack a CSG300 series appliance:

1. Open the top flaps of the cardboard carton.

2. Remove from the box the foam packing material holding the appliance and the accessories in place. See Figure 1.

3. Remove the accessory box and the appliance from the foam packing material.

4. Remove the accessories from the accessories box.

5. Verify the components against the packing list that is included in the box.

https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Planning_and_Installation/Install_a_CSG3...

Figure 1: Unpack a CSG300 Series Appliance

Updated: Sat, 23 Nov 2024 08:34:15 GMT

Need help?

Do you have a question about the CSG300 Series and is the answer not in the manual?

Page 1 Unpack a CSG300 Series Appliance The CSG300 series appliance is packed in a plastic box, and it is shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only when you are ready to install it.
Page 2 Hardware. Packing List for a CSG300 Series Appliance The cardboard carton in which a CSG300 series appliance is shipped contains a packing list. Check the packing list against the parts that you receive in the shipping carton. Packing List for the CSG350 Appliance Table 1 lists the parts shipped with a CSG350 appliance.
Page 3 3. Attach the two mounting ears to each side of the appliance chassis using a minimum of six M4 screws that are shipped with the appliance. Do not overtighten the screws. Figure 2: Attach the Mounting Ears to a CSG300 Series Appliance https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Planning_and_Installation/Install_a_CSG3…...
Page 4 7. Have a second person secure the mounting ears to the front of the rack using the four M6 screws that shipped with the appliance. Insert and then tighten the screws. Do not overtighten the screws. Figure 4: Secure the Mounting Ears to the Rack https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Planning_and_Installation/Install_a_CSG3… Updated: Sat, 23 Nov 2024 08:34:15 GMT Copyright © 2024, Versa Networks, Inc.
