CSG300 Series Hardware Guide
At a Glance
The Versa Cloud Services Gateway (CSG) 300 series appliances deliver highly secure site-to-site data connectivity to
small businesses and to home offices.
These appliances provide the following features:
• Support for different CPUs and memory sizes:
• Management Ethernet ports with dual use and dedicated options:
◦ One RJ45 RS-232 console port
◦ One USB 2.0 management port for plugging in external LTE or WiFi modems
◦ One copper Gigabit Ethernet dual-purpose port for data and management
• MDI and MDIX autoswitchable copper Gigabit Ethernet ports
• PoE source support on four Ethernet ports, with network interface card (NIC) module add-on
• Wireless options:
• CSG350–Two built-in wireless slots
• CSG355 and CSG365–Two LTE slots and one dedicated built-in wireless slot
• External AC power supply
• Fan for cooling
• Desktop mount, or rack-mountable in a 19" rack (CSG355 and CSG365 only)
CSG300 Appliance Models
The CSG300 appliances are available in the following models:
• CSG350—Compact and optimized appliance for deployment in small branches (up to 75 users) that require
advanced application and cloud intelligence with hierarchical QoS and that provide a cost-effective SD-WAN
solution.
• CSG355–Powerful appliance for deployment in both small- and medium-sized branches that require advanced SD-
Security (NGFW and UTM) along with comprehensive advanced application and cloud-intelligent SD-WAN services
on premises.
• CSG365—High-performance, powerful appliance for deployment at medium-sized branch locations that
require advanced application and cloud-intelligent SD-WAN services and advanced SD-Security (NGFW and UTM).
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui...
Updated: Fri, 09 Dec 2022 04:36:47 GMT
Copyright © 2022, Versa Networks, Inc.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSG300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Versa Networks CSG300 Series

Summary of Contents for Versa Networks CSG300 Series

  • Page 1 • CSG365—High-performance, powerful appliance for deployment at medium-sized branch locations that require advanced application and cloud-intelligent SD-WAN services and advanced SD-Security (NGFW and UTM). https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.

  • Page 2: Chassis Views

    The rear panel has the power and reset buttons and various connectors and ports. Figure 1: Front Panel of the CSG350 Appliance Figure 2: Rear Panel of the CSG350 Appliance https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 3 Figure 4: Rear Panel of the CSG355 Appliance CSG300 Series Appliance Specifications A CSG300 series appliance chassis is made of aluminum for optimal heat dissipation. This article lists the chassis and regulatory compliance specifications for the CSG300 series appliance. It also lists certifications and export control classification numbers (ECCNs) for the appliance.

  • Page 4: Chassis Specifications

    5.91" (152 mm) 2.75 lb (1.25 kg) Chassis weight Chassis weight with installation kit: 3.96 lb (1.8 kg) maximum Package Specifications Package height 7" (17.78 cm) https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 5 10% to 85% relative humidity CSG355 and CSG365 Appliance Table 2 lists the specifications for the CSG355 and CSG365 appliance chassis. Table 2: CSG355 and CSG365 Chassis Specifications https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 6 Chassis weight with installation kit: 5.5 lb (2.5 kg) maximum Package Specifications Package height 7" (17.78 cm) Package width 16.7" (42.4 cm) Package depth 12" (30.48 cm) https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 7 20° to 70°C (68° to 158°F) at sea level Humidity 10% to 85% relative humidity CSG300 Series Appliance SKUs CSG300 series SKUs have the following format: model – xxx – yyy model indicates the CSG300 appliance model number. It can be one of the following: • CSG350 •...

  • Page 8: Regulatory Compliance

    • T1/E1—1 T1/E1 NIC port • xDSL—1 VDSL NIC port Regulatory Compliance Table 3 lists the regulatory compliance specifications for a CSG300 series chassis. Table 3: CSG300 Series Regulatory Compliance Specifications Item Specification CB (IEC/EN60950-1 and IEC/EN 62368-1) Safety UL (CSA 22.2 No 62368-1 and UL62368-1) TPM 2.0...
  • Page 9 QuickSec IPsec toolkit used by Versa Analytics, Versa IPsec crypto 5D002 8542310000 G161333 module Director, and Versa Operating System (VOS ) device Hardware-based encryption and decryption 5A002U 8542310001 G156910L1 CSG300 https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.

  • Page 10: Front And Rear Panel Components

    • Blinking red—Controller is unreachable or unresponsive. Rear Panel The rear panel of a CSG300 series appliance has six status LEDs, SIM card slots, and power and reset buttons. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT...
  • Page 11 LEDs The rear panel of a CSG300 series appliance has six LEDs, located in two rows. Table 2 lists the LEDs, their color and states, and the status they indicate. Table 2: Rear Panel LEDs in a CSG300 Series Appliance...

  • Page 12: Sim Card Slots

    SIM Card Slots The rear panel of a CSG300 series appliance has two nano-SIM card slots. If you subscribe to a single wireless service, use the SIM 1 slot to install the LTE device. If you subscribe to dual wireless service, use both the SIM 1 and SIM 2 slots to activate the LTE devices.
  • Page 13 Running, [-] process 5643 versa-dnsd is Running, [-] process 5646 versa-ppmd is Running, [-] process 5793 versa-snmp-xform is Running, [-] process 5800 versa-certd is Running, [-] process 5849 https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.

  • Page 14: Additional Information

    Table 1 describes the NICs and the Versa Operating System (VOS ) software releases in which the NIC is supported. Table 1: CSG355 and CSG365 NIC Support https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 15 • 1-GB copper Gigabit Ethernet port • 1-GB copper Gigabit Ethernet with PoE port The four Ethernet ports on the NIC module are labeled Port 6 through Port 9. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 16 Figure 2: CSG355 RJ-45 Connectors for 1-GB Copper GE Combination Port Figure 3 shows the CSG350 series appliance VNI port mapping. Figure 3: CSG350 RJ-45 Connectors for 1-GB Copper GE Combination Port https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.

  • Page 17: Nic Specifications

    NIC Specifications Table 2 lists the NIC specifications for a CSG300 series appliance. Table 2: CSG300 Series NIC Specifications Item Specification Item Specification Typical power consumption 10 Watts System power input 3.3 VDC @ 3A PoE power adapter input 54 VDC @ 2.78A, 100-240 VAC @ 2A, 50-60 Hz...
  • Page 18 Maximum 3000 m (10000 ft) Noise level 0 dBm Storage Conditions Temperature –20 to 70°C (–4 to 158°F) at sea level Humidity 10 to 85% relative humidity https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 19 LTE Modem Module The CSG300 series LTE modem module is a high-performance Cat-6 LTE Advanced (LTE-A) modem that provides download speeds up to 300 Mbps and upload speeds up to 50 Mbps. The LTE modem supports multiple carriers, and it has been certified by major global carriers.
  • Page 20 Galileo, BeiDou You can order CSG300 series appliances with an optional LTE modem module. The LTE modem modules have either one SIM slot or two SIM slots. For modules with one SIM slot, you insert the SIM card into the SIM1 slot, which is on the back of the appliance.

  • Page 21: Interface Numbering

    Figure 2 shows port-to-VNI mapping for the CSG355 and CSG365 appliances. Note that the CSG355 and CSG365 chassis are identical. Figure 2: CSG355 and CSG365 Port-to-VNI Mapping https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.

  • Page 22: Ac Power Supply

    AC Power Supply By default, CSG300 series appliances ship with one AC power supply unit. If you order the CSG300 series appliance with the power-over-Ethernet (PoE) NIC module, an additional power supply unit ships with the appliance. Table 1 describes the AC power supply specifications for each power supply unit.

  • Page 23: General Safety Guidelines

    When placing a CSG300 series appliance on a desk, ensure that the vents on the side of the unit are never blocked, to allow hot air to flow out of the appliance. Covering the vents prevents heat from dissipating out of the appliance, which will cause the chassis to overheat and then shut down.
  • Page 24 повний текст декларації про відповідність доступний на веб-сайті за такою адресою www.versa-networks.com. IC Wireless Interference Statement for Canada The following IC wireless interference information applies to Canada only: https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Complete_CSG300_Series_Hardware_Gui… Updated: Fri, 09 Dec 2022 04:36:47 GMT Copyright © 2022, Versa Networks, Inc.
  • Page 25 To satisfy RF exposure requirements, a separation distance of 20 cm or more must be maintained between the antenna of CSG300 series device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended.

  • Page 26: Site Preparation Guidelines

    เครื ่ อ งโทรคมนาคมและอุ ป กรณ์ น ี ้ มี ค วามสอดคลอ้ งตามมาตรฐานหรื อ ขอ้ กํ า หนดทางเทคนิ ค ของ กสทช. QR Code Prepare the Site for Installation To prepare your site for installing a CSG300 series appliance, follow the guidelines and requirements listed in this article. Site Preparation Guidelines •...

  • Page 27: Environmental Requirements

    When planning your site for installing a CSG300 series appliance, ensure that the vents on the side of the unit are never blocked. Covering the vents prevents heat from dissipating out of the appliance, which can cause the chassis to overheat and then shut down.
