Table Of Contents

Table of Contents

Quick Links

Download this manual

CSG150 Hardware Guide

At a Glance

Chassis Views

CSG150 Series Appliance Specifications

Chassis Specifications

CSG150 Appliance SKUs

Regulatory Compliance

Certifications

Front and Rear Panel Components

Front Panel

LEDs

Power Button

Reset Button

Rear Panel

Reset the Appliance to the Factory-Default Configuration from the CLI

Additional Information

Interface Numbering

Connect a CSG150 Series Appliance

Step 1: Connect AC Power to a CSG150 Series Appliance

Step 2: Configure a Serial Management Console to Connect to a CSG150 Series Appliance

Step 3: Connect a CSG150 Series Appliance to a Network Management Console

Installation Guidelines

General Safety Guidelines

Federal Communication Commission Interference Statement

Install a CSG150 Series Appliance

Unpack a CSG150 Series Appliance

Packing List for a CSG150 Series Appliance

Packing List for the CSG150 Appliance

https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS...

Updated: Fri, 01 Nov 2024 16:28:57 GMT

Table of Contents

Need help?

Do you have a question about the CSG150 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Versa Networks CSG150 Series

Page 1 Connect a CSG150 Series Appliance Step 1: Connect AC Power to a CSG150 Series Appliance Step 2: Configure a Serial Management Console to Connect to a CSG150 Series Appliance Step 3: Connect a CSG150 Series Appliance to a Network Management Console...
Page 2: Chassis Views
SD-WAN, next-generation security, unified threat management (UTM), and uCPE scenarios. CSG150 series appliances are designed with optimal dimensions and form factor for WAN edge deployments in smaller enterprise branches, kiosks, ATMs, and home offices that require advanced secure SD- WAN along with comprehensive advanced application and cloud-intelligence with hierarchical quality of service (QoS).
Page 3: Chassis Specifications
Figure 2: Rear Panel of a CSG150 Appliance CSG150 Series Appliance Specifications This article lists the chassis and regulatory compliance specifications for the CSG150 series appliance. It also lists certifications and export control classification numbers (ECCNs) for the appliance. Chassis Specifications Table 1 lists the chassis specifications for a CSG150 appliance.
Page 4 Maximum 3000 m (10,000 ft) Noise level Less than 20 dBA Cooling Fanless Mounting Desktop Storage Conditions -5° to 85°C (23° to 185°F) at sea Temperature level https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 5: Regulatory Compliance
CSG150 Appliance SKUs CSG150 appliance SKU is the CSG150 base model. Regulatory Compliance Table 3 lists the regulatory compliance specifications for the CSG150 series appliance. Table 3: CSG150 Series Regulatory Compliance Specifications Item Specification CB (IEC/EN 62368-1:2014 and IEC/EN 62368-1:2018) Safety UL (CSA 22.2 No 62368-1:2014 and CSA 22.2 No UL62368-1:2019)
Page 6 • IEC 62368-1:2018 Canada • UL 62368-1, Third Edition EMC: • ICES-003 Issue 7:2020 (Class A) Safety: United Kingdom • IEC 62368-1: 2014 • BS EN 62368-1:2014+A11:2017 https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 7: Front And Rear Panel Components
At a Glance. Front Panel The front panel of a CSG150 series appliance has four status LEDs, power and reset buttons, and various connectors and ports. LEDs Table 1 lists the LEDs, their colors and states, and the status they indicate.
Page 8 Reset Button The Reset button on the front panel of a CSG150 series appliance resets the appliance. The reset functionality depends on the number of times you press the button within a span of 30 seconds, as described in Table 3. In between each press on the reset button, you must pause for a second to register the key presses.
Page 9: Rear Panel
You can reset the appliance to the factory-default configuration by issuing the request system reset CLI command. Rear Panel The rear panel of a CSG150 series appliance has the power connector. Reset the Appliance to the Factory-Default Configuration from the CLI You can reset the appliance to the factory-default configuration from the CLI.
Page 10: Additional Information
Interface Numbering Figure 1 shows the mapping of the Ethernet ports to virtual network interface (VNI) numbering for the CSG150 appliance. Figure 1: CSG150 Port-to-VNI Mapping https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 11 Step 1: Connect AC Power to a CSG150 Series Appliance Before you begin connecting AC power to a CSG150 series appliance, ensure that you have: • Electrostatic discharge (ESD) wrist strap.
Page 12 CSG150 series appliances are equipped with an RJ45 serial console port. To connect to the console port, use the RJ45-to-USB serial console cable supplied with the appliance: 1. Plug the RJ45 end of the console cable into the console port located on the rear panel of the CSG150 series appliance.
Page 13 2. In the Category navigation pane, click Session, and then in the Connection Type menu, click Serial. 3. In the Category navigation pane, click Connection > Serial. The Options Controlling Local Serial Lines page displays. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 14 4. In the Serial Line To Connect To field, enter the COM port that your device is connected to. The default COM port is COM1. 5. In the Configure the Serial Line section, enter the following information. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 15 In the Speed (Baud) field, enter the digital transmission speed. For CSG150 series appliances, the speed must be 115200. b. In the Data bits field, enter the number of data bits used for each character. The recommended value is 8.
Page 16 7. Click Save. 8. To open the session, click Open. 9. Log in to the appliance CLI with the username "admin" and the password "versa123". https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 17: General Safety Guidelines
RJ-45 connector. Plug the RJ45 connector into the console port on the CSG150 series appliance and plug the other end of the cable into the console server or into a management console.
Page 18: Federal Communication Commission Interference Statement
20 cm between the radiator and your body. Warning: Operation of this equipment in a residential environment could cause radio interference. Warning: Operation of this equipment is for indoor use only. https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_150_Series/Complete_CSG150_Hardware_Guide/CS… Updated: Fri, 01 Nov 2024 16:28:57 GMT Copyright © 2024, Versa Networks, Inc.
Page 19 Unpack a CSG150 Series Appliance The CSG150 series appliance is packed in a plastic box, and it is shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only when you are ready to install it.
