Summary of Contents for Strong G673C Series
- Page 1 G673C Serie HD SMART TV 32’’ / FHD SMART TV 40’’ SRT32HG6733C, SRT40FG6733C Installation instructions www.strong-eu.com...
- Page 2 Supplied by STRONG Austria Represented by STRONG Ges.m.b.H. Teinfaltstraße 8/4.Stock A-1010 Vienna, Austria Email: support_at@strong-eu.com www.strong-eu.com...
-
Page 3: Simplified Eu Declaration Of Conformity
SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, STRONG declares that the devices SRT 32HG6733C, SRT 40FG6733C, are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://eu.strong-eu.com/ downloads/ Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change. -
Page 4: Table Of Contents
TABLE OF CONTENT To obtain the best performance and safety, please read this manual carefully. Please keep this manual for future reference. 1.0 INSTRUCTION 1.1 SAFETY INSTRUCTIONS 1.2 STORAGE 1.3 ACCESSORIES 1.4 EQUIPMENT SET-UP 2.0 INSTALLATION 2.1 PASSWORD SETTING: 2.2 FRONT PANEL 2.3 REAR PANEL 2.4 REMOTE CONTROL 2.5 INSTALLING THE BATTERIES... - Page 5 5.4 TV MENUS 6.0 SMART TV POSSIBILITIES 7.0 SYSTEM SETTINGS 7.1 SETTINGS MAIN MENU 7.2 SYSTEM MENU 8.0 MULTIMEDIA 8.1 REMINDER WHEN USING THE USB STORAGE DEVICES 8.2 MULTIMEDIA PLAYER 8.2.1 PLAY VIDEOS 8.2.2 BROWSE PHOTOS 8.2.3 PLAY MUSIC 8.2.4 BROWSE FILES 9.0 TROUBLESHOOTING 10.0 SPECIFICATIONS...
-
Page 6: Instruction
1.0 INSTRUCTION 1.1 SAFETY INSTRUCTIONS Read all of the instructions before operating the set. Keep these instructions well for later use. „ Only use attachments/accessories specified or provided by the manufacturer (such as the exclusive supply adapter, battery etc.). „ Please refer to the information on the exterior back enclosure for electrical and safety information before installing or operating the apparatus. -
Page 7: Equipment Set-Up
1.4 EQUIPMENT SET-UP Fig. 1 Install the display on a solid horizontal surface such as a table or desk. For ventilation, leave a space of at least 10 cm free all around the set. To prevent any fault and unsafe situations, please do not place any objects on top of the set. This apparatus can be used in tropical and/or moderate climates. -
Page 8: Rear Panel
2.3 REAR PANEL NOTE: The graphics are for representation only. Fig. 3a SRT 32HG6733C DIGITAL ANT2 ANT1 AUDIO OUT (SATELLITE) HDMI2(CEC) 13/18V 400mA USB2.0 HDMI1 500mA) (ARC/CEC) COMMON INTERFACE(CI) 1. DIGITAL AUDIO OUT (optical) Use an optical cable to connect your TV to a compatible digital amplifier or Home theatre set. -
Page 9: Remote Control
input is equipped with the ARC (Audio Return Channel) feature to implement audio connections and for a full Dolby Audio support. 2. CI Insert a Conditional Access Module (CAM). 3. USB 2.0 USB 2.0 port. 4. DIGITAL AUDIO OUT (optical) Use an optical cable to connect your TV to a compatible digital amplifier or Home theatre set. -
Page 10: Colour Buttons
Press to choose an account Press to activate the voice control function*. Press to access the TV settings. 9. Navigate the menu. 10. OK Confirm the selection. 11. Press to go back to previously viewed channel. In menu: Back to previous menu. Enter the home desktop. -
Page 11: Using The Ir Remote Control
„ Do not place the remote control under direct sunlight which will cause deformation of the unit by heat. „ When the remote sensor is under direct sunlight or strong lighting, the remote control will not work. If so, please change the lighting or TV's position, or operate the remote control closer to the remote sensor. - Page 12 With basic TV, you will get: Live TV and extarnal devices (e.g. HDMI) With basic TV, you will get Movies an TV shows from your favorite streaming apps Set up Google TV Personnalized recommendations Set up basic TV Google Assistant: Search and control your TV with your voice Live TV External device (e.g.HDMI) You can easily transfer your Android phone’s Wi-Fi network and Google Account to your TV.
-
Page 13: Channel Installations For Cable
Step 5 Pairing the remote control. Remote & accessories Press and key simultaneously, while poin ng to the TV bo om within the distance of 1 meter at least 3 seconds. Release your finger when the indicator light (red) of the remote flashes. Skip this step if your remote doesn’t have the bu on / Skip Buttons to press simultaneously. - Page 14 Select the operator You can select only Ziggo one operator from the following list : Others Select one operator from the following list, or select Other if you don't have a predefined operator or it is different from those listed. Once done press OK to continue. NOTE: Not all countries have predefined operators.
-
Page 15: Channel Installations For Antenna
3.2 CHANNEL INSTALLATIONS FOR ANTENNA Select the tuner mode Antenna and press OK to continue. Tuner Mode Please select Antenna your tuner mode: Cable Satellite Select the preferred method of channel ordering. Scan direc on Select the channel ordering method. Automa c Automa c Channel Ordering channel ordering is the default method. -
Page 16: Channel Installations For Satellite
3.3 CHANNEL INSTALLATIONS FOR SATELLITE Tuner Mode Please select Antenna your tuner mode: Cable Satellite Select the tuner mode Satellite and press OK to continue. Satellite installa on Do you want Start to start satellite channel installa on? Press OK to start with the satellite channel installation. Antenna type Next More... - Page 17 LNB list Next Astra4A/SES5 5E Eutelsat 7E Off Eutelsat 9E Off Hotbird 13E Off With you can select the satellite (or satellites) to which your dish is addressed. Press OK to access the submenu that allows you to activate or deactivate the selected satellite and to set its various parameters. After all settings have been made, select NEXT to continue.
-
Page 18: Home Screen
4.0 HOME SCREEN The Home screen is the main screen of this model of TV. HOME SCREEN BASIC installation, with the possibility of accessing your account and the internet at a later time. Home Live TV HOME SCREEN full installation: Google TV Home Librairy... -
Page 19: Inputs
4.1 INPUTS TV has such possible inputs or sources: ATV, ANTENNA, CABLE or SATELLITE for respective live TV installed channels preview or HDMI 1, HDMI 2, HDMI 3 and AV to select connection from external devices. To access to this option, select Inputs item on Home screen or press INPUT button on RCU. Select the input sources for the devices which are connected to the TV through the different inputs or ports. - Page 20 Connecting to a wired network Fig. 6a Ethernet on the bo om NOTE: The graphics are for representation only. To connect to a wired network 1. Ensure you have: „ An Ethernet cable long enough to reach your TV „ A router or modem with an available Ethernet port „...
- Page 21 Connecting to a wireless network Fig. 6b NOTE: The graphics are for representation only. To connect to a wireless network: 1. Ensure you have: „ A router broadcasting a 2.4GHz or 5GHz wireless signal. „ A highspeed Internet connection 2. Select your Wi-Fi network from the Available networks list and enter password for connection. 3.
-
Page 22: Live Tv Usage
5.0 LIVE TV USAGE Select Live TV application from Home screen or one of TV sources from input menu to watch live TV channels. Press OK to start this application. This application gives you access to live TV to watch and enjoy your favorite TV and radio programs from TV sources (ATV, Antenna, Cable or several of Satellites) of your choice. -
Page 23: Electronic Program Guide (Epg)
Changing channels Following ways are possible for changing channels: „ Via direct access using the 0~9 buttons. „ Via the or P+/P- buttons. „ Via the channel list using OK and buttons. Use P+/P- or buttons in the list to move through list Page Up or Down. Info Banner While watching TV you can press INFO button to get information about current / next program and event on broadcasting and also some other useful information about it*. -
Page 24: Smart Tv Possibilities
TV options level TV options contains such items: Input, Picture, Screen, Sound, Power, Parental Controls, CI Card, Advanced Options and Settings. TV op ons Inputs Picture Sound Inputs allows you to select the source to be displayed. The available sources are: „... -
Page 25: System Settings
1. Some USB storage devices may not be compatible to operate smoothly with this TV. 2. Back up all the data in the USB storage device in case data is lost due to an unexpected accident. STRONG does not assume any liability for the losses by misuse or malfunction. -
Page 26: Multimedia Player
5. When connecting or disconnecting the USB storage device, make sure the TV is not in USB mode, otherwise the USB storage device or the files stored in it may be damaged. 6. Please use only a USB storage device which is formatted in FAT16, FAT32, NTFS (playback only) file system provided with the Windows operating system. -
Page 27: Play Videos
Your TV will collect all supported files of selected media type and will show them in one list. Use and to select file. Press OK for playback. During playback you could use Multimedia buttons on your RCU or use on-screen commands, available from menu by button. NOTE: By choosing one of the media types, for example Video, the list will display only compatible media files and no other files of other types. -
Page 28: Browse Photos
8.2.2 BROWSE PHOTOS Select Photo from Multimedia type selection and choose the file from which the slideshow has to start the playback. Press experience more content Firenze 1 (4204x2797).jpg 16/64 To get access to control playback during playback press OK button to display the menu or button to display more content. Available options: Rotation to rotate picture on screen... -
Page 29: Browse Files
Before calling a service technician, review following information for possible causes and solutions for the problem you are experiencing. If the TV does not work properly after checking it, please contact your local service line or STRONG dealer. Alternatively, you can send a support mail via our website www.strong-eu.com. - Page 30 Satellite dish is too small, trees or buildings in path. Change to a larger dish or change position of dish. d) Signal is too strong, dish is oversized. Connect a signal attenuator to the LNB input. Ask a local satellite specialist for advice.
-
Page 31: Specifications
Besides that, please be aware that some services which are not pre-installed but can be installed may collect personal data even without providing additional warnings and that STRONG cannot be held liable for a possible breach of data protection by services...
