- Page 1 DISHWASHER INSTRUCTION MANUAL Model: DW-14F2(BS)-MY Read these instructions carefully before using your DISHWASHER, and keep it carefully.
-
Page 2: Safety Instrucions
SAFETY INSTRUCIONS All instructions described should be carefully read and followed. These instructions are precautions to prevent the risks of serious injury or death of the user, and any damages to property. MARKINGS WARNING indicates high possibility of serious injury (*1) or WARNING death of the user. - Page 3 Before cleaning or maintaining the dishwasher, disconnect the power plug first. Disconnect power plug Do not connect or disconnect the power plug by wet hand. No touch This may cause electric shock or fault and cause injuries. by wet hand Do not use damaged power lines, power plug or loose power socket.
- Page 4 Insert the power plug securely to the base and let the cord go downward. If the cord goes upward or if the plug is incompletely inserted, it may cause fire due Insert plug to electric leakage or heat generation. Do not operate by putting easily combustible items such as towels and cloth inside the cabinet of the dishwasher.
- Page 5 When disconnecting the plug from the socket, do not pull the power line by force. Pull out by grasping the power plug. It may cause electric shock or fault and cause No pulling injuries. by force Do not use soap, washing powder or other hand sanitizer. Only dishwashing powder suitable for automatic dishwasher.
- Page 6 Quantity of tableware advised: 162 pcs (Cup x14 + Saucer x14 + Glass x14 + Small serving bowl x1 + Medium serving bowl x1 + Large serving bowl x1 + Loading Dessert dishes x14 + Dinner plate x14 + Soup plate x14 + Oval platter x1 + capacity Soup spoon x14 + Fork x14 + Knife x14 + Teaspoon x14 + Dessert spoon x14 + Serving spoon x 2 + Serving fork x1 + Gravy ladle x1)
- Page 7 Treatments Handle the package of the dishwasher with extreme care. All packages are recyclables. Plastic parts are marked with abbreviation of international standard; Polyethylene, e.g., tableted package material Polystyrene, e.g., packing material Polymethyl, e.g., plastic clip Polymer, e.g., control panel Polypropylene, e.g., inner wall Warning The packing material may be dangerous to children!
-
Page 8: Table Of Contents
Contents Please carefully read the instruction manual before using the dishwasher, and this is helpful for the use and maintenance of the product. Recognize the dishwasher Dishwasher features Control panel Program Setting Washing program Start up Changing the program mid-cycle Put additional dishes in End of washing program Use the dishwasher... - Page 9 Installation Product dimension Power connection Water connection Connection of drain hoses Troubleshooting Before connecting customer service center Error code Specification...
-
Page 10: Recognize The Dishwasher
Recognize the dishwasher Important: Before using the dishwasher for the first time, read following instructions to ensure the best results. Dishwasher features Lower spray arm Salt container Filter Dispenser Cutlery rack Upper spray arm Cup rack Cutlery basket Upper basket Lower basket... -
Page 11: Control Panel
Control panel Power Power on/off Program Select the appropriate washing program and the corresponding indicator will light up. AUTO DAILY Light to heavily soiled daily used items, automatic detection of the amount of soils. INTENSIVE For dishes with oil stains and heavy dirty cooking utensils and dishes. - Page 12 Function Select a function and the corresponding indicator will light up. EXTRA DRYING Use this option when you want to dry your dishes more completely. It can only be used with Intensive, Hygiene, Eco, Glass, 90min POWER WASH To wash very dirty, hard to clean dishes. It can only be used with Intensive, Hygiene, Eco, Glass, 90min.
-
Page 13: Program Setting
Program Setting Washing program Following table shows best cleaning procedures and amount of dishwashing powder required according to the dirty level of the dishes, as well as the Highest Water Dishwashing Time Power Water Program Temperature powder (g) (min) (Kwh) 5/30 150-185 0.9-1.1... -
Page 14: Start Up
Start up 1. The plug shall be firstly plugged into the socket. Power supply shall be of 220-240V AC 50Hz type, with socket of 10 A 220-240V AC. 2. Make sure that the water supply is turned on to full pressure. 3. -
Page 15: Put Additional Dishes In
additional dishes in Additional dishes can be placed in at any time before dishwasher program start. If you want to reload dishes in the process of washing, please follow instructions below: 1. Open the door a little to stop the dishwasher, after the spray arm stop working, you can open the door completely. -
Page 16: Use The Dishwasher
Use the dishwasher Water softener The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The more minerals there are, the harder your water is. -
Page 17: Adding Salt To The Softener
Adding salt to the softener Warning Only use salt specifically designed for dishwashers use! Every other type of salt not specifically designed for dishwasher use, especially table salt, will damage the water softener. In case of damages caused by the use of unsuitable salt the manufacturer does not give any warranty nor is liable for any damages caused. -
Page 18: Rinse Aid And Detergent
Function of the rinse aid and detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. Warning Only use branded rinse aid for dishwasher. -
Page 19: Adding Rinse Aid To The Dispenser
Adding rinse aid to the dispenser Remove the rinse reservoir cap by lifting up the handle . Pour the rinse aid into the dispenser, being careful not to overfill. Close the cap after all. Adjusting the rinse aid reservoir To achieve a better drying performance with limited rinse aid, the dishwasher is designed to adjust the consumption by user. -
Page 20: Adding Detergent To The Dispenser
Adding detergent to the dispenser Sliding it to the right Press down Add detergent into the larger cavity (A) for the main wash cycle . For better cleaning result, especially if you have very dirt items, pour a small amount of detergent onto the door. The additional detergent will activate during the pre-wash phase. -
Page 21: Install Dishwasher Bowl Basket
Install dishwasher bowl basket Suggestion Purchase dishes suitable for dishwasher. Use a suitable mild dishwashing powder. If necessary, consult the manufacturer for more information. For special appliances, try to select a washing program that with a lower temperature. Do not take out the glass dishes immediately after the program ends to prevent damage. Use the dishwashing machine rationally Not for: Limited use:... -
Page 22: Loading The Upper Basket
Loading the upper basket Use the upper rack for small or delicate items such as small plates,cups, saucers, glasses, and dishwasher-safe plastic items. Place items so that the open end faces down for cleaning and drying. Do not stack items on top of each other. Item Number Cups... -
Page 23: Loading The Cutlery Rack
Loading the cutlery rack The cutlery rack is best suited for washing flatware and most cooking or serving utensils. The separators on the cutlery racks help keep flatware separated to avoid damage and improve cleaning. Item Item Number Number Soup spoons Dessert spoons Forks Serving spoons... -
Page 24: Basket Used Tips
Basket used tips Adjusting the upper basket The height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket. We recommend adjust the height of the upper basket before loading dishes. To adjust the height of the upper rack, follow these steps: To raise the upper basket just lift... -
Page 25: Uv Light
Folding back the cup shelves To make room for taller items in the upper basket, raise the cup rack upwards. You can then lean the tall glasses against it. You can also remove it when it is not required for use. Folding back the rack shelves The spikes of the lower basket are used for holding plates and a platter. -
Page 26: Cleaning And Care
Cleaning and care Filter cleaning The filtering system in the base of the wash cabinet retains coarse debris from the washing cycle. The collected coarse debris may cause the filters to clog. Check the condition of the filters regularly and clean them if necessary under running water. Follow the steps below to clean the filters in the wash cabinet. -
Page 27: Spray Arms Cleaning
Spray arms cleaning It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the upper spray arm, To remove the lower spray arm, pull hold the nut in the center still and out the spray arm upward. -
Page 28: Care And Maintenance
Care and maintenance The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. These surfaces are outside the wash cabinet and are not accessed by water from the spray arms. -
Page 29: Installation
Installation Product dimension Height (H) 845mm Width (W) 598mm Depth (D1) 600mm (with the door closed) Depth (D2) 1175mm (with the door opened 90°) -
Page 30: Power Connection
Warning Electric Shock The machine shall be installed after the power is off. If not, electric shock or death can be caused. Please make sure the machine is properly grounded before use. Power connection Warning Electric Shock Do not use an extension cord or power adapter on this machine. In case, do not cut off or remove the grounding connection of power cord. -
Page 31: Connection Of Drain Hoses
Connection of drain hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000mm. -
Page 32: Troubleshooting
Troubleshooting Before connecting customer service center Please check the chart below before connecting customer service center Problem Possible cause Solutions Replace fuse or reset circuit breaker Fuse burn-out or circuit trip. Remove any other appliances that share same circuit with the dishwasher. The machine is Make sure that dishwasher is on and the not working... - Page 33 Problem Possible cause Solutions Noise from Suspend the program and reposition the Dishes are loose. dishwasher dishes. This may be caused by site Beats in water In case of any doubts, please contact installation or cross section pipe Please see “Install dishwasher bowl basket” Dishes are not placed correctly.
-
Page 34: Error Code
Error code When failure occurs, error code will appear to remind you: Error code Code name Possible cause Long water Flow-meters, drain valves, or pump failures intake time shall be repaired by qualified serviceman. Heating pipe or thermistor is at abnormal state, which needs to be unplugged the Abnormal heating power plug from the outlet , and needs to... -
Page 35: Specification
Specification Model DW-14F2(BS)-MY 598 (W) x 845 (H) x 600 (D) Dimension (mm) 220-240V Rated voltage 50 H Rated frequency 1760-2100 W Rated power 10 L Water consumption 0.93 kWh Power consumption Electronic type Control mode IPX1 162 pcs (Cup x14 + Saucer x14 + Glass x14 + Small serving bowl x1...
