OPERATION MANUAL

SERIES

MODEL MTXi60

TAMPING RAMMER

(BOB10 RECHARGEABLE BATTERY)

Revision #0 (11/12/24)

To find the latest revision of this publication or

associated parts manual, visit our website at:

www.multiquip.com

THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Table of Contents

Need help?

Do you have a question about the Mikasa Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MQ Multiquip Mikasa Series

Page 1 OPERATION MANUAL SERIES MODEL MTXi60 TAMPING RAMMER (BOB10 RECHARGEABLE BATTERY) Revision #0 (11/12/24) To find the latest revision of this publication or associated parts manual, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
Page 2: Proposition 65 Warning
PROPOSITION 65 WARNING PAGE 2 — MTXi60 RAMMER • OPERATION MANUAL — REV. #0 (11/12/24)
Page 3 NOTES MTXi60 RAMMER • OPERATION MANUAL — REV. #0 (11/12/24) — PAGE 3...
Page 4: Table Of Contents
TABLE OF CONTENTS MTXi60 Rammer Proposition 65 Warning ........... 2 Safety Information ..........5-7 Specifications ............8-9 Dimensions ............10 General Information ..........11 Components ............12 Transporting And Lifting ......... 13 Inspection ............14-15 Operation ............16-17 Maintenance ............18 Troubleshooting ..........
Page 5: Safety Messages
SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
Page 6: General Safety
SAFETY INFORMATION GENERAL SAFETY „ ALWAYS know the location of the nearest phone or keep a phone on the job site. Also, know the phone numbers of CAUTION the nearest ambulance, doctor and fi re department. This information will be invaluable in the case of an emergency. „...
Page 7: Battery Safety
SAFETY INFORMATION BATTERY SAFETY ENVIRONMENTAL SAFETY DANGER NOTICE „ When installing or removing the rechargeable battery, make „ Dispose of hazardous waste properly. sure that the battery switches are off Examples of potentially hazardous waste are used motor oil, fuel and fuel fi lters. „...
Page 8: Specifications
SPECIFICATIONS Table 1. Rammer Specifications Overall Height 40.9 in. (1040 mm) Overall Width 13.9 in. (352 mm) Over Length 29.4 in. (748 mm) Plate Size (W x L) 10.4 x 13.4 in. (265 x 340 mm) Lubrication Oil Capacity 0.69 qt. (0.65 liter) No.
Page 9 SPECIFICATIONS Table 4. Battery Charger Specifications Manufacturer BATTERY ONE Model BOC13 Type of Current (Input) Rated Voltage 100 - 240 V Rated Current 2.9 - 7.3 A Rated Frequency 50 - 60 Hz Rated Output 0.65 kW Type of Current (Output) Output Current 13.5 A Nominal Output Voltage...
Page 10: Dimensions
DIMENSIONS Table 6. Dimensions 13.9 in. (352 mm) 10.4 in. (265 mm 29.4 in. (748 mm) 40.9 in. (1040 mm) 13.4 in. (340 mm) PAGE 10 — MTXi60 RAMMER • OPERATION MANUAL — REV. #0 (11/12/24)
Page 11: General Information
GENERAL INFORMATION The Multiquip MTXi60 tamping rammer is a walk-behind The motor speed is reduced to the speed required for compactor designed for use in cohesive soils. Its tamping by the reduction ratio of the pinion gear and crank applications include soil compacting for road, embankments gear.
Page 12: Components
COMPONENTS 6. Battery Handle — Used to securely grasp battery when installing or removing. 7. Battery Connections (Contact Strip) — Provides connection to the main unit when battery is properly attached. 8. Rechargeable Battery — Provides power to the motor. 9.
Page 13: Transporting And Lifting
TRANSPORTING AND LIFTING Inspect the lower lifting handle (Figure 2) for cracks or 1. Tilt rammer so that the roller makes contact with the damage. If the lifting handle is damaged in any way, replace edge of the truck tail gate as shown in Figure 3. it immediately.
Page 14: General Inspection
INSPECTION TIGHTENING SCREWS It is extremely important that this section be read carefully before attempting to operate the rammer. DO NOT use 1. Retighten the nuts on the foot of the rammer (see your rammer until this section is thoroughly understood. Figure 6).
Page 15: Battery And Battery Charger
INSPECTION BATTERY AND BATTERY CHARGER BATTERY REMOVAL Refer to the battery and battery charger accompanying NOTICE manuals for information on the following: Make sure the machine is at a complete stop • Charging and Charge Level • Cleaning Refer to Figure 8 for location of parts. •...
Page 16: Operation
OPERATION CAUTION CAUTION Failure to understand the operation of the Tamping Do not use rammer on sloping ground, such as the Rammer could result in severe damage to the unit or side of an embankment as this may make the machine personal injury.
Page 17 OPERATION STOPPING THE RAMMER WARNING DO NOT touch hot parts until they have cooled down enough, to prevent burns. START LEVER SAFETY LEVER Figure 11. Stopping the Rammer 1. Slowly pull the Start Lever back until it stops, and then the safety lever clicks into place with the start lever and holds it in the OFF position.
Page 18: Oil Drain Plug
MAINTENANCE DAILY LONG TERM STORAGE „ STOP the machine motor. „ Visually inspect rammer parts such as the plate, handle, shock absorber, and for deformation, breakage, crack, „ DO NOT move the machine until the motor and main and dirt. body have cooled down enough.
Page 19: Troubleshooting
TROUBLESHOOTING Troubleshooting (Rammer) Symptom Possible Problem Solution Battery is not installed correctly? Reinstall battery. Battery charge is low? Fully charge battery. Motor does not start. Battery malfunction? Replace battery. Wire broken or short circuit? Repair wiring. Drain excess oil. Bring to correct Oil in excess? level.
Page 20: Here's How To Get Help
OPERATION MANUAL HERE’S HOW TO GET HELP HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Inc. (310) 537- 3700 6141 Katella Avenue Suite 200 Cypress, CA 90630 E-MAIL: mq@multiquip.com WEBSITE: www.multiquip.com CANADA UNITED KINGDOM Multiquip...
