MQ Multiquip MVH158GH Operation And Parts Manual

Mikasa series reversible plate compactor (honda gx200ut2sm14; honda gx200ut2scm gasoline engine)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION AND PARTS MANUAL
SERIES
MODEL MVH158GH
REVERSIBLE PLATE COMPACTOR
(HONDA GX200UT2SM14/GX200UT2SCM
GASOLINE ENGINE)
Revision #1 (11/16/17)
www.discount-equipment.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH158GH and is the answer not in the manual?

Questions and answers

Related Manuals for MQ Multiquip MVH158GH

Summary of Contents for MQ Multiquip MVH158GH

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODEL MVH158GH REVERSIBLE PLATE COMPACTOR (HONDA GX200UT2SM14/GX200UT2SCM GASOLINE ENGINE) Revision #1 (11/16/17) www.discount-equipment.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. Locations: Florida (West Palm Beach): 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Check out our website at www.discount-equipment.com Can’t find what you need? Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out the request form.

  • Page 3: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 4: Table Of Contents

    Specifications and part numbers are subject to change Vibrator Assembly ..........38-39 without notice. Base And Engine Assembly ......40-43 Electrical Device Assembly ......44-45 Control Assembly ..........46-49 PAGE 4 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 5: Safety Information

    COULD result in DEATH or SERIOUS INJURY. CAUTION Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE INJURY. NOTICE Addresses practices not related to personal injury. PAGE 6 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 6: Safety Information

     ALWAYS clear the work area of any debris, tools, etc. that would constitute a hazard while the equipment is in operation. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 7...
  • Page 7 MV H-3 06 the engine start diffi cult. and serious damage to the equipment or engine. PAGE 8 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 8  ALWAYS keep battery cables in good working condition. hot engine. Repair or replace all worn cables. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 9...
  • Page 9  Contact your country's Department of Public Works or recycling agency in your area and arrange for proper disposal of any electrical components, waste or oil associated with this equipment. PAGE 10 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 10: Specifications

    Environment by equipment for use outdoors. Products are tested for hand/arm vibration (HAV) level in accordance with European Directives 2002/44/EC and EN500-4 and ISO 5349-1:2001, ISO 5349-2:2001. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 11...

  • Page 11: Dimensions

    DIMENSIONS Figure 1. Dimensions Table 4. Dimensions REF. DES. IN. (MM) 16.93 (430) 27.56 (700) 44.88 (1140) 38.58 (980) 44.29 (1125) 27.16 (690) PAGE 12 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 12: General Information

    The resulting vibrations cause forward motion. The engine the function of all the controls and components. and handle are vibration isolated from the vibrating plate. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 13...

  • Page 13: Components

    COMPONENTS Figure 2. Plate Compactor Components PAGE 14 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 14: Components

    7. Throttle Lever — Controls speed of the plate compactor. Place straight vertically to start, push fully counterclockwise for full throttle and fully clockwise to stop plate compactor. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 15...

  • Page 15: Basic Engine

    Reference the maintenance section in this manual for servicing. PAGE 16 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 16: Inspection

    Table 5. Oil Type Season Temperature Oil Type Summer 25°C or Higher SAE 10W-30 Spring/Fall 25°C~10°C SAE 10W-30/20 Figure 7. V-Belt Location Winter 0°C or Lower SAE 10W-10 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 17...
  • Page 17 3. When the handle bar is raised to the desired height, tighten the wing nut. Grip V-BELT VIBRATOR Wing nut PULLEY Figure 9. V-Belt Tension Figure 11. Handle Height Adjustment PAGE 18 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 18: Startup

    Figure 13. Throttle Lever (Idle Position) Figure 16. Engine ON/OFF Switch (ON Position) 3. Place the choke lever (Figure 14) in the “CLOSED” position if starting a cold engine. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 19...

  • Page 19: Startup

    (Figure 18) as the engine warms up. If the engine has not started, repeat steps 1 through 6. CHOKE LEVER OPEN CLOSE Figure 18. Choke Lever (Open) PAGE 20 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 20: Operation

    REVERSE OPERATION NEUTRAL POSITION THROTTLE FORWARD LEVER DIRECTION IDLE CONTROL LEVER POSITION Figure 21. Direction Control Lever Figure 22. Throttle Lever (Idle) MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 21...

  • Page 21: Operation

    Figure 24. Fuel Valve Lever (OFF) Emergency Shutdown 1. Move the throttle lever quickly to the IDLE position, and place the engine ON/OFF switch in the OFF position. PAGE 22 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 22: Maintenance

    Ensure that the maintenance area is well ventilated. Gasoline engine exhaust contains poisonous carbon monoxide gas that can cause unconsciousness and may result in DEATH. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 23...

  • Page 23: Maintenance

    2. These items should be serviced by your service dealer, unless you have the proper tools and are mechanically proficient. Refer to the HONDA Shop Manual for service procedures. 3. For commercial use, log hours of operation to determine proper maintenance intervals. PAGE 24 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 24: Engine Air Cleaner

    Bolt threads used with this machine are all right handed Material and quality of material is marked on each bolt, and screw. Figure 25. Engine Air Filter (Dual) MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 25...
  • Page 25 (Figure 26). Clean inside of air filter cover with warm, soapy water or nonflammable solvent. Rinse and dry thoroughly. DRAIN BOLT SEALING WASHER Figure 28. Draining Engine Oil PAGE 26 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 26 After air replace the V-belt immediately. bubbles stop coming out, reattach the plug. Tighten securely (Figure 30). MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 27...
  • Page 27 6. When the machine is used after a long storage period, check the level of engine oil before using. MUFFLER 5 MM SCREW SPARK ARRESTOR Figure 33. Spark Arrester Removal PAGE 28 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 28: Troubleshooting (Compactor)

    Piston inside hydraulic pump not Adjust or replace. moving smoothly? Direction Control Lever operating resistance for reverse is high. Vibrator cylinder piston does not move Adjust or replace. smoothly MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 29...

  • Page 29: Troubleshooting (Engine)

    Fuel fi lter/lines clogged? Replace fuel fi lter. Fuel tank cap breather hole clogged? Clean or replace fuel tank cap. Air in fuel line? Bleed fuel line. PAGE 30 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 30 Check cable connections. Charge or replace Will not start, no power with key "ON". (if Battery disconnected or discharged? applicable) battery Ignition switch/wiring defective? Replace ignition switch. Check wiring. MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 31...

  • Page 31: Explanation Of Code In Remarks Column

    “Remarks” Column. assembly/kit that can be purchased, or is not available for sale through Multiquip. PAGE 32 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 32: Suggested Spare Parts

    1♦ ..17620Z4H030 ..CAP, FUEL TANK COMP. following parts lists. 1◊ ..17620Z4H900 ..CAP, FUEL TANK COMP. 1....17672Z4H000 ..FILTER, FUEL NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 33...

  • Page 33: Nameplate And Decals Assembly

    NAMEPLATE AND DECALS ASSY. PAGE 34 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 34 DECAL: CAUTION 920218130 DECAL: E/G RPM 3600 920220490 DECAL: V-BELT RPF-3360 PLATE: SERIAL NO...........1....CONTACT MQ PARTS DEPT. 920211690 DECAL: LEVER OPERATION 920220810 DECAL: CAUTION (LEVER) MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 35...

  • Page 35: Vibrating Plate Assembly

    VIBRATING PLATE ASSY. PAGE 36 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 36 030212300 WASHER, LOCK M12 471354550 COVER, VIBRATOR 050710160 O-RING 014208020 BOLT 8X20............14....REPLACES P/N 001220820 030208200 WASHER, LOCK M8 0401450080 WASHER, FLAT M8 ..........14....REPLACES P/N 031108160 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 37...
  • Page 37 VIBRATOR ASSY. PAGE 38 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 38 014208020 BOLT 8X20............3....REPLACES P/N 001220820 030208200 WASHER, LOCK M8 0401450080 WASHER, FLAT M8 ...........3....REPLACES P/N 031108160 471219680 BELT COVER, LOWER 001520852 SOCKET HEAD BOLT 8X60 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 39...
  • Page 39 BASE AND ENGINE ASSY. PAGE 40 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 40 WASHER, LOCK M12 031112230 WASHER, FLAT M12 471219690 CENTER COVER 001521030 SOCKET HEAD BOLT 10X30 031110160 WASHER, FLAT M10 030210250 WASHER, LOCK M10 020310080 NUT M10 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 41...
  • Page 41 BASE AND ENGINE ASSY. (CONTINUED) PAGE 42 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 42 COIL SPRING ............1....REPLACES P/N 0830000010 58151 WASHER, FLAT M5 ...........1....REPLACES P/N 031105080 2067550101 CLAMP COMPLETE 959407260 CLIP D6 012210015 BOLT 10X15............1....REPLACES P/N 001221015 030210250 WASHER, LOCK M10 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 43...
  • Page 43 ELECTRICAL DEVICE ASSY. 103 104 ENGINE PAGE 44 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 44 STOP SWITCH, ENGINE 468467570 READ CORD 467466980 LEAD WIRE (SW-GROUND) 454010020 CLAMP TC-100 020108060 NUT M8 ..............1....REPLACES P/N 020308060 959021827 SPIRAL TUBE 6D-950L 515450380 WIRE HARNESS MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 45...
  • Page 45 CONTROL ASSY. PAGE 46 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 46 NUT M10 ............1....REPLACES P/N 020410060 456449980 RUBBER PACKING 031110160 WASHER, FLAT M10 458214400 HANDLE GRIP (EXP) 014208020 BOLT 8X20............2....REPLACES P/N 001220820 030208200 WASHER, LOCK M8 471354800 LEVER, TRAVEL (LOOP) MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 47...
  • Page 47 CONTROL ASSY. (CONTINUED) PAGE 48 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 48 BOLT 6X15............1....REPLACES P/N 001220615 030206150 WASHER, LOCK M6 459219610 HAND PUMP H5HB051000 SOCKET HEAD BOLT 5X10 ......1....REPLACES P/N 001520510 463455950 SPACER, THROTTLE 956100076 THROTTLE WIRE 1235-1335G MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 49...

  • Page 49: Cylinder Barrel Assembly

    BPZ0 GX200UT2-SM14 HONDA GX200UT2SM14/SCM ENG. — CYL. BARREL ASSY. CYLINDER BARREL PAGE 50 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 50 WASHER, FLAT 6 MM ........2....REPLACES P/N 9410106800 9425108000 LOCK PIN 8 MM 957010601200 FLANGE BOLT 6X12 35480Z0T003 SWITCH ASSEMBLY, OIL LEVEL NOTICE GX200UT2SM14 ♦ GX200UT2SCM ◊ MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 51...

  • Page 51: Cylinder Head Assembly

    CYLINDER HEAD HONDA GX200UT2SM14/SCM ENG. — CYL. HEAD ASSY. PAGE 52 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 52 STUD BOLT 6X112 90047ZE1000 STUD BOLT 8X32 9430110160 KNOCK PIN 10X16 957010806000 BOLT, FLANGE 8X60 0650140480 SPARK PLUG 9500280000 CLIP, TUBE NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 53...
  • Page 53 HONDA GX200UT2SM14/SCM ENG. — CAMSHAFT ASSY. PAGE 54 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 54: Camshaft Assembly

    RETAINER, EX. VALVE SPRING 13♦ 14781ZE1000 ROTATOR, VALVE 14791ZE1010 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT, 8 MM 90206ZE1000 NUT, PIVOT ADJUSTING NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 55...

  • Page 55: Crankcase Cover Assembly

    GX200UT2-SM14 BQC0 CRANKCASE COVER HONDA GX200UT2SM14/SCM ENG. — CRANKCASE COVER ASSY. PAGE 56 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 56 PACKING, OIL FILLER CAP 91201Z0T801 OIL SEAL 25X41X6 9430108140 KNOCK PIN 8X14 957010803200 FLANGE BOLT 8X32 961006205010 BALL BEARING 6205 ........1....REPLACES P/N 961006205000 15625Z0T800 PACKING, OIL FILLER CAP MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 57...

  • Page 57: Fuel Tank Assembly

    HONDA GX200UT2SM14/SCM ENG. — FUEL TANK ASSY. PAGE 58 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 58 91353671003 O-RING 14 MM ..........1....REPLACES P/N 91353671004 91424Z4M003 TUBE, FUEL 4.5X145 9405006000 FLANGE NUT 6 MM 950024080008 CLAMP, TUBE (D8) NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 59...

  • Page 59: Muffler Assembly

    HONDA GX200UT2SM14/SCM ENG. — MUFFLER ASSY. PAGE 60 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 60 TAPPING SCREW 5X8 90055ZE1000 TAPPING SCREW 4X6 020108060 NUT 8 MM ............2....REPLACES P/N 94001080000S 16♦ 18310Z4V000 MUFFLER COMPLETE 16◊ 18310Z4V010 MUFFLER COMPLETE NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 61...

  • Page 61: Piston Assembly

    HONDA GX200UT2SM14/SCM ENG. — PISTON ASSY. PAGE 62 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 62 PISTON (0.50) 13104ZL0020 PISTON (0.75) 13111Z4M000 PIN, PISTON 13200Z0T800 ROD ASSEMBLY, CONNECTING .....1....INCLUDES ITEM W/@ 90001ZE1000 CONNECTING ROD BOLT 90551ZE1000 CLIP, PISTON PIN 18 MM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 63...

  • Page 63: Crankshaft Assembly

    HONDA GX200UT2SM14/SCM ENG. — CRANKSHAFT ASSY. 41.9 91.9 PAGE 64 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 64 HONDA GX200UT2SM14/SCM ENG. — CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13310ZL0020 CRANKSHAFT COMPLETE 90741883810 KEY 5X5X33 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 65...

  • Page 65: Fan Cover Assembly

    HONDA GX200UT2SM14/SCM ENG. — FAN COVER ASSY. PAGE 66 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 66 90013883000 FLANGE BOLT 6X12 90022888010 FLANGE BOLT 6X20 90601ZH7013 CLIP, HARNESS 957010600800 FLANGE BOLT 6X8 13◊ 81329567020 GROMMET, DRAIN HOLE NOTICE GX200UT2SM14 ♦ GX200UT2SCM ◊ MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 67...

  • Page 67: Recoil Starter Assembly

    HONDA GX200UT2SM14/SCM ENG. — RECOIL STARTER ASSY. GX200UT2SM14 GX200UT2SCM PAGE 68 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 68 32901MA1000 CLIP, CORD 14$# 90003ZH8801 SET SCREW 957010601800 FLANGE BOLT 6X18 17$# 28461Z4M305 KNOB, RECOIL STARTER 18$# 28463Z4M003 KNOB, REINFORCEMENT NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 69...

  • Page 69: Flywheel Assembly

    GX200UT2-SM14 BQJ0 FLYWHEEL HONDA GX200UT2SM14/SCM ENG. — FLYWHEEL ASSY. PAGE 70 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 70 19511ZE1000 COOLING FAN 4♦ 28451ZL0801 PULLEY, STARTER 4◊ 28451Z4V003 PULLEY, STARTER 31100ZE7010 FLYWHEEL COMPLETE (STD.) 90201Z0T800 NUT, SPECIAL 14 MM NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 71...

  • Page 71: Carburetor Assembly

    HONDA GX200UT2SM14/SCM ENG. — CARBURETOR ASSY. GASKET SET NOTICE Gasket set, item 1 included with items 4, 6, 7, 12, 21, 26 and 40. PAGE 72 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 72 JET, MAIN #82 99204ZE20400 JET SET, PILOT #40 ..........1....INCLUDES ITEM W/◗ 16211Z4V000 INSULATOR, CARBURETOR 16959Z5T901 FILTER, CUP 40◊% 16141Z0S003 WASHER, FLAT NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 73...

  • Page 73: Air Cleaner Assembly (Gx200Ut2Sm14)

    HONDA GX200UT2SM14 ENG. — AIR CLEANER ASSY. (STD.) PAGE 74 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 74 ELBOW COMPLETE, AIR CLEANER ....1....INCLUDES ITEMS W/ $ 90325044000 NUT, WING 9405006000 FLANGE, NUT 6 MM 957010602000 FLANGE, BOLT 6X20 17231Z4M010 COVER, AIR CLEANER 90300Z1V000 NUT, AIR CLEANER MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 75...

  • Page 75: Air Cleaner Assembly (Gx200Ut2Scm)

    HONDA GX200UT2SCM ENG. — AIR CLEANER ASSY. (CYCLONE) PAGE 76 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 76 COLLAR B, AIR CLEANER 17410Z0V780 ELBOW COMP., AIR CLEANER ......1....INCLUDES ITEMS W/# 90300Z4M800 NUT, AIR CLEANER 90325044000 NUT, WING 9405006000 FLANGE NUT 6MM 957010602000 FLANGE BOLT 6X20 MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 77...

  • Page 77: Ignition Coil Assembly

    GX200UT2-SM14 IGNITION COIL HONDA GX200UT2SM14/SCM ENG. — IGNITION COIL ASSY. PAGE 78 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 78 2◊ 30700Z0T821 CAP ASSEMBLY, NOISE SUPPRESSOR 8♦ 36101ZE1010 CORD, STOP SWITCH 370 MM 90121952000 FLANGE BOLT 6X25 .........2....REPLACES P/N 957010602500 NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 79...
  • Page 79 HONDA GX200UT2SM14/SCM ENG. — CONTROL ASSY. PAGE 80 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)

  • Page 80: Control Assembly

    SCREW 4X6 ............1....REPLACES P/N 93500040060H 26#% 0202005T125 SCREW 5X16 ............1....REPLACES P/N 93500050160A 27#% 93500050250H SCREW 5X25 9405006000 FLANGE NUT 6 MM NOTICE GX200UT2SM14 ♦ ◊ GX200UT2SCM MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 81...

  • Page 81: Engine Decal Assembly

    HONDA GX200UT2SM14/SCM ENG. — ENGINE DECAL ASSY. LABEL & TOOL PAGE 82 — MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17)
  • Page 82 HONDA GX200UT2SM14/SCM ENG. — ENGINE DECAL ASSY. PART NO. PART NAME QTY. REMARKS 87516Z4H010 MARK, OP-CAUTION (ENGLISH) 87521Z4V000 EMBLEM 87528Z4M000 MARK, CHOKE 87532ZH7000 MARK, THROTTLE INDICATION 87539Z4M000 MARK, EX.CAUTION (ENGLISH) MVH158GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (11/16/17) — PAGE 83...

  • Page 83: Terms And Conditions Of Sale - Parts
