FOUNTAINS.COM 5042F3 Setting Up

SETTING UP THE 5042F3, 5043F3, 5044F3
1) Place the largest stone piece on your prepared, level setting. 2)
Set the pump inside its bowl and run its power cord down through the
hole in the floor and out through the slot provided, as shown.
Open the slit in the rubber stopper with the smaller hole, place it
around the pump power cord, and press it tightly into place in the
bowl's bottom hole to make the fountain watertight.
2) Thread the barbed adapter into the top of the pump and
then press one end of the water tube onto the adapter's barb.
Place the flow restrictor around the tube about 6" above the pump,
tightening it just enough to keep it in place.
Set the middle bowl/pedestal unit within the bottom unit –
3)
pushing the tube up through the middle as you do. Open the slit in
the stopper with the larger hole and close it around the tube near
the bottom of the middle unit's bowl. Press it snugly into the hole
inside the bowl.
4) Shimless Leveling: This fountain is designed to need no
shims to achieve level installation. Simply twist or otherwise
nudge the middle piece on the lower piece's connecting arched
platform until it is straight. You can check it now with a level and
minimize any fine adjustments later once it is filled with water.
5) Slide the exposed water tube up inside the top finial piece as you
set the top piece in the middle bowl. The level of the top piece can be
adjusted just like the middle piece.
6) Fill the bottom and middle bowls with water. Read the pump
and light instructions. Then plug in the pump and light to run your
fountain. If the pump does not start immediately it may have an airlock
inside the impeller chamber. Simply unplug and plug it in several times
and it should clear
.
Make sure to place your
fountain on a firm area
which will not settle.
Note: Always follow
local electrical codes and
use a 110V to 120V
GFCI protected outlet.
