STUDIODUE CLEVER SPOT RGBW User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Clever
Clever
spot
spot
RGBW - MONOCHROMATIC
User manual
Manuale d'uso
RDM

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLEVER SPOT RGBW and is the answer not in the manual?

Questions and answers

Related Manuals for STUDIODUE CLEVER SPOT RGBW

Summary of Contents for STUDIODUE CLEVER SPOT RGBW

  • Page 1 Clever Clever spot spot RGBW - MONOCHROMATIC User manual Manuale d’uso...
  • Page 2 this page is intentionally left blank / questa pagina è stata lasciata intenzionalmente bianca...
  • Page 3 Setup and configuration (touch control panel) / Configurazione e settaggio (pannello di controllo touch) Page 14 DMX Channels list / Lista canali DMX Page 17 Physical / Dimensioni Page 18 CE standards / Certificazioni CE Page 19 Warranty / Garanzia CLEVER SPOT RGBW CLEVER SPOT MONOCHROMATIC rel.1_10/23 - Studio Due...
  • Page 4 ........................ENG SAFETY INFORMATION (service personnel) IMPORTANT ! READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT. INSTRUCTION TO PREVENT INJURY OR DAMAGE DUE TO ELECTRIC SHOCK, FIRE, MECHANICAL HAZARDS, DANGEROUS MATTERS. • PROTECTION AGAINST DANGEROUS MATTERS At the end of its life, must be collected separately. It shouldn’t be thrown as urban waste and neither released in the environment. It must be collected from the nearest special waste collection point or consigned to your dealer that provides the service.
  • Page 5 • Standard fixture colour finishing is grey RAL 9006 (standard) Optional: Black RAL 9005 - White RAL 9010 - Any RAL. • Art. 220810 CLEVER SPOT RGBW • Art. 220820 CLEVER SPOT M RDM (monochromatic) • Art. 220800 CLEVER SPOT PLUG-IN M (monochromatic) To obtain the best performances and for a correct functioning of this unit for the years to come, we suggest you to read carefully this manual before connecting or putting the fixture into use.
  • Page 6 CLEVER SPOT RGBW (art.220810) ........................ENG / ITA Studio Due Trade S.r.l. Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) Small wash LED spot with 7 RGBW full color LEDs. Remote configura�on by IT14078001006 TECHNICAL FEATURES / CARATTERISTICHE TECNICHE DRS Setup device.
  • Page 7 ........................ENG / ITA CLEVER SPOT M RDM (it. 220820) TECHNICAL FEATURES / CARATTERISTICHE TECNICHE Studio Due Trade S.r.l. Small wash LED spot with 4 High Power Monochroma�c LEDs. Remote Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) IT14078001006 configuration by DRSW Setup device.
  • Page 8 Studio Due Trade S.r.l. Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) IT14078001006 ........................ENG / ITA TECHNICAL FEATURES / CARATTERISTICHE TECNICHE Studio Due Trade S.r.l. CLEVER SPOT PLUG-IN M (art.220800) Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) IT14078001006 warm neutral cool Small wash LED spot with 4 High Power Monochroma�c LEDs.
  • Page 9 ........................ENG / ITA CONNECTION TO THE MAIN POWER / CONNESSIONE ALLA RETE ELETTRICA This equipment must be earthed. Class I equipment. The power supply cord includes a protective earthing conductor as part of the cord. IMPORTANT: to ensure the protection rating of the fixture, in case of replacement of the conductor cable, refer to the CONDUCTOR SIZE TABLE Questo apparecchio necessita di messa a terra.
  • Page 10 ........................ENG / ITA 120 Ohm CONNECTION TO THE DMX SIGNAL / CONNESSIONE AL SEGNALE DMX DMX output DMX output DMX input DMX input Termination resistor Terminale di linea DMX TERMINAL LINE The wrong connection of the terminal line or its non-connection are probably the most frequent reasons of the lower DMX SHIELD GROUND/RETURN/OV signal.
  • Page 11 ........................ENG / ITA EXAMPLE OF CONNECTION DMX CONTROLLER - FIXTURES / ESEMPIO DI COLLEGAMENTO CENTRALINA - FARI Example 1/ Esempio 1 DMX out Last fixture/ Ultimo apparecchio fixture / fixture / apparecchio fixture / fixture / apparecchio apparecchio apparecchio Termination resistor/ Terminale di linea Example 2 / Esempio 2...

  • Page 12: Main Power

    ........................ENG SETUP AND CONFIGURATION BY DRS - DMX REMOTE SETUP The DRS it’s a new concept of professional LED Lighting fixtures suitable for outdoor permanent installations. The LED Lighting fixtures can be driven via DMX through a specific electronic device, the DRS DMX Remote Setup, that grant the possibility to set up the scenarios and the games remotely.
  • Page 13 ........................ENG SETUP AND CONFIGURATION BY DRS - DMX REMOTE SETUP dimmable version only / solo versione dimmerabile To make the set-up of the various fixture parameter, proceed as follow: •Disconnect the fixture to set-up from the other DMX/RDM devices •...
  • Page 14 ........................ENG / ITA DRS MENU’ LIST / ELENCO MENU DRS Switching on the fixture you can see the model and the software version. For example: All’accensione, viene visualizzato il modello di apparecchio e la versione software. Per esempio: --> MEGAW... --> 1_00 - than it’s shown the fist menu / poi viene visualizzato il primo menu Address (Addr) Set the DMX channel address / Imposta il canale DMX...
  • Page 15 Smooth Dimming (SMth) Set the interpolation type for the smooth dimming function Imposta il tipo di interpolazione per la funzione smooth dimming. (OFF, Sd1, Sd2, Sd3) > Select the value oFF .. LoW .. MId .. hIGh with the UP/DOWN buttons. Press ENTER. >...
  • Page 16 DMX Channels list 5Ch / Lista dei canali DMX 5Ch 8 BIT FUNCTION GREEN BLUE WHITE DIMMER DMX Channels list 4Ch / Lista dei canali DMX 4Ch 8 BIT FUNCTION GREEN BLUE WHITE rel. 1_10/23 - Studio Due...
  • Page 17 ........................ENG / ITA DMX CHANNELS MONOCHROMATIC / CANALI DMX MONOCROMATICO - (*) DMX line for Dimmable version. (setting 3ch or 1ch) -------------------------------------------------------------------------------------------------------------- - (*) linea DMX versione Dimmerabile. (settaggio 3ch o 1ch) 8 BIT FUNCTION DIMMER RAINBOW - FLASH 0,4Hz / 25Hz FLASH 0,4Hz / 25Hz OPEN STROBE...
  • Page 18 The firm: dichiara sotto la propria responsabilità che il prodotto: declare under our sole responsability that the product: Art. 220810 CLEVER SPOT RGBW Art. 220820 CLEVER SPOT M RDM (monochromatic) Art. 220800 CLEVER SPOT PLUG-IN M (monochromatic) è conforme alle norme:...

  • Page 19: Warranty Card

    WARRANTY / GARANZIA Warranty CARD Company name: ..........................Mr./Mrs./Miss: ..........................Address: ............................Tel. or E-mail : ..........................Dealer: ..................... SALE CONDITIONS 1) Price quoted are not inclusive of lamp and package. Package charge is 2% on the net price for all the items. These prices should be subject to possible variations for eventual rises of production costs or duties.
  • Page 20 Head Office: STUDIO DUE s.r.l. (I) Str. Poggino, 100 - 01100 Viterbo (Italy) tel. +39.0761.352520 fax +39.0761.352653 info@studiodue.com STUDIO DUE (UK) 3 Encon Court Owl Close Moulton Park Industrial Estate Northampton England UK - NN3 6 HZ tel. +44.1933.650.820 info@studiodue.co.uk www.studiodue.com...
