ELGO-PLUS SPRINGER-ECO Manual page 3

Multifunctional mini digger

Advertisement

2.1.
General description
The machine is designed for earthworks carried out in normal daylight conditions. If the machine is
to be used for other purposes or have to work in a potentially hazardous environment, then follow
the special safety regulations, and the machine itself should be equipped according to the working
conditions. For further information, please contact the manufacturer.
A
Inverter
B
Hetronic Receiver (Radio control)
C
Hydraulic distributor
D
Electric motor
E
Hydraulic pump
F
Batteries
G
Batteries charger
H
Mini digger's arm
I
Boom
J
Bucket – changable equipment
K
Support
L
Caterpillar landing gear
M
Revolving bodywork
N
Electric cabinet
PIC. 2.1. General construction
