ATHC & ATWC MANUAL
Toll Free: (855) 855-0399
ATHC-9-ES / ATHC-18-ES
info@atosausa.com
ATWC-12 / ATWC-24
www.atosausa.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATHC and is the answer not in the manual?

Questions and answers

Summary of Contents for Atosa ATHC

  • Page 1 ATHC & ATWC MANUAL Toll Free: (855) 855-0399 ATHC-9-ES / ATHC-18-ES info@atosausa.com ATWC-12 / ATWC-24 www.atosausa.com...
  • Page 2: Table Of Contents

    ATHC-18ES ................14 ATHC-9ES ................. 15 ATWC-24 ................... 16 ATWC-12 ................... 17 Electrical Box (ATHC-9ES & ATHC-18ES) ........ 18 Electrical Box (ATWC-12 & ATWC-24) ........19 Wiring Diagram (ATHC-9-ES & ATHC-18-ES) ......20 Wiring Diagram (ATWC-12 & ATWC-24) ........21...
  • Page 3: Safety Precautions

    ATHC & ATWC Safety Precautions Warning • Read these safety instructions thoroughly before connecting this product to the main power supply. • Before turning it on, make sure the voltage of your electricity supply is the same as what is indicated on the rating label. This product is designed to operate at 120V AC, 60Hz (1 phase).
  • Page 4: Installation

    • Put the cabinet in the right position and lock the brakes of the caster before connecting the power cord. • For ATHC, cabinets rated at 120V 1900W must be plugged into a 20-amp 125VAC receptacle (5-15R); For ATWC, Cabinets rated at 120V 1580W must be plugged into a 15-amp 125VAC receptacle (5-20R).
  • Page 5: Door Reversal

    ATHC & ATWC Door Reversal The connection between the cabinet and door frame is the door hinge set. The one on the cabinet is the female hinge and the one on the door frame is the male hinge. Male Hinge...
  • Page 6 ATHC & ATWC Door Reversal (Cont’d) Following are the steps for switching the door opening direction: 1. Remove the pins connected to the male hinge and female hinge. When removing the pin, use the plier to take the gasket around the pin’s washer out then push from the bottom and take them out from the top.
  • Page 7 ATHC & ATWC Door Reversal (Cont’d) 2. Remove the two screws from the male hinge. Remove the cover on the door handle then take the screws out. 3. Install the removed male hinges and door handle back on the opposite side.
  • Page 8 ATHC & ATWC Door Reversal (Cont’d) 4. Remove the female hinges and the magnet on the cabinet. 5. Install the removed female hinges, magnet, and door handle back on the opposite side. Reattach the door. 6. Secure with the pins and gasket in the same way as take them out. The door opening...
  • Page 9: Operating Instructions

    ATHC & ATWC Operating Instructions Control Panel Power Switch Indicator Light Thermostat Cycle Temperature Display Power-Up Refer to the data plate located near the power cord for the electrical specifications of the cabinet. With the POWER switch OFF, plug into a grounded receptacle.
  • Page 10: Operations

    2. Set TEMPERATURE control to 10. 3. Pre-heat cabinet until desired temperature is reached (typical heat-up time from 72°F (22°C) ambient to 160°F (71°C) is approximately 15 minutes for ATHC-9ES/18ES and ATWC12/24. 4. Re-set TEMPERATURE controls and adjust as necessary to reach the desired temperature (setting 8-9 typical for 167°F (75°C) to 195°F(90°C)).
  • Page 11: Cleaning

    ATHC & ATWC Cleaning • DO NOT wash the cabinet with high-pressure water or a water jet. • DO NOT spray or pour water into the electrical box. Excess water may cause the heated control drawer module to short circuit or cease working.
  • Page 12: Troubleshooting

    ATHC & ATWC Troubleshooting WARNING: ALWAYS unplug the cabinet from the electrical outlet for safety purposes, minimizing the risk of electrical shocks. Problem Possible Cause Solution The outlet does not have power. Check that the outlet has power. Check that the power switch is in the ON Power switch is not in the ON position.
  • Page 13 ATHC & ATWC Troubleshooting (Cont’d) Problem Possible Cause Solution The cabinet may still be in pre-heat or Wait patiently for several minutes and check recovering from a door being opened. again. Turn temperature control knob to a higher Temperature set too low.
  • Page 14: Athc-18Es

    ATHC & ATWC ATHC-18ES Item Description Item Description Electrical Box Door Hinge Set Door Frame Sink-Front Door Handle No-Brake Caster Food Pan Bracket Brake Caster Cabinet...
  • Page 15: Athc-9Es

    ATHC & ATWC ATHC-9ES Item Description Item Description Electrical Box Door Hinge Set Door Frame Sink-Front Door Handle No-Brake Caster Food Pan Bracket Brake Caster Cabinet...
  • Page 16: Atwc-24

    ATHC & ATWC ATWC-24 Item Description Item Description Module Cabinet Door Frame Sink-Front Door Handle No-Brake Caster Pc Board Brake Caster Door Hinge...
  • Page 17: Atwc-12

    ATHC & ATWC ATWC-12 Item Description Item Description Module Cabinet Door Frame Sink-Front Door Handle No-Brake Caster Pc Board Brake Caster Door Hinge...
  • Page 18: Electrical Box (Athc-9Es & Athc-18Es)

    ATHC & ATWC Electrical Box (ATHC-9ES & ATHC-18ES) Item Description Item Description Bottom Cover Slide Module Chassis Track Bottom Cover Air Discharge Cover Control Panel Intake Cover Digital Thermometer Power Cord Amber Light Strain Relief Bushing Thermostat Knob Power Cord Bracket...
  • Page 19: Electrical Box (Atwc-12 & Atwc-24)

    ATHC & ATWC Electrical Box (ATHC-9ES & ATHC-18ES) Item Description Item Description Control Panel Power Cord Bracket Power Switch Electrical Support Thermostat Heating Element, 120v 1550w Amber Light Thermal Cut-Out Digital Thermometer Rear Electric Heating Tube Box Control Panel, Pc...
  • Page 20: Wiring Diagram (Athc-9-Es & Athc-18-Es)

    ATHC & ATWC Wiring Diagram (ATHC-9-ES & ATHC-18-ES)
  • Page 21: Wiring Diagram (Atwc-12 & Atwc-24)

    ATHC & ATWC Wiring Diagram (ATWC-12 & ATWC-24)
  • Page 22 ATHC & ATWC Conforms to UL STD.197 Conforms to NSF STD.4 4003935 NOTE: Energy Star is for ATHC ONLY.
  • Page 23 THANK YOU FOR YOUR PURCHASE OF AN ATOSA PRODUCT YOUR SINGLE SOURCE DIVERSIFIED GLOBAL SOLUTION...
  • Page 24 Toll Free: (855) 855-0399 info@atosausa.com www.atosausa.com...

This manual is also suitable for:

AtwcAthc-9-esAthc-18-esAtwc-12Atwc-24
