Summary of Contents for BassBoss SSP218-MK3
- Page 1 User Manual Double 18” SSP218-MK3 Powered Subwoofer...
-
Page 2: Table Of Contents
Warning Warranty Setup Procedure Safety Information Operation and Controls Important Notes Indicator LEDs FCC Compliance Notice How to Use the Presets Pre-Installed Onboard Manufacturer Presets Este manual está disponible en español en nuestro sitio web en bassboss.com/support SSP218-MK3 User Manual... -
Page 3: Overview
The SSP218-MK3 maintains its performance over the long term and is virtually impossible to destroy thanks to the combination of extremely robust and very high power handling, long excursion drivers, a carefully optimized port and cabinet design and several effective yet transparent protection systems that are part of the integrated signal processing. -
Page 4: Quick Start Guide
Connect the signal cable via the Connect the XLR-M connector to XLR-F input. additional bass or mids. Connect power to the speaker and verify that the “Ready” LED is on. SSP218-MK3 User Manual... -
Page 5: Combining Speakers
Combining Speakers BASSBOSS systems are easy to set up quickly. The best possible results are achieved consistently because of the integrated nature of the designs. All BASSBOSS loudspeakers are complete, integrated systems, featuring the cabinet, transducer, amplifier and a comprehensive suite of processing. Setup is particularly easy because the products integrate with each other. -
Page 6: Setup Procedure
The internal processing can accomplish everything an external processor could accomplish without degrading the sound quality and without putting components at risk. Before considering using an outboard processor, contact BASSBOSS customer service with your use-case scenario for assistance in setting up the internal processing to achieve your goals. -
Page 7: Operation And Controls
BASSBOSS powered speakers. The amplifier will simply amplify the clipped signal, which can do the same damage as clipping an Presets help you fine-tune the balance between the amplifier. -
Page 8: Indicator Leds
The Protect LED also is engaged when the system has been muted via the software. Comm Link Indicates communication is active on the LAN connection(s). Indicator LEDs, Right Side, Bottom to top Presets 1-8 The illuminated LED indicates the corresponding preset is loaded. SSP218-MK3 User Manual... -
Page 9: How To Use The Presets
It’s recommended that you try several, if not all, combinations when first setting up to determine which combination works best in each environment. You will likely choose different combinations for wood floors, concrete floors and outdoors. Experiment with different combinations to dial in your preferred combination in different environments. bassboss.com 9... - Page 10 In order to achieve the flattest and smoothest frequency response, you should match the levels of your BASSBOSS subs and tops, and the low-pass filter frequency selected on the Subwoofer(s) should be closely matched to the high-pass filter frequency selected on the Top(s).
-
Page 11: Power Distribution
Connect no more than one 5000W or two 2500W subwoofer amplifiers to a single 20A circuit. If you need to share circuits don’t exceed two BASSBOSS single-driver subwoofers or one double-driver subwoofer along with one or two top speakers on the same circuit. -
Page 12: Cardioid Mode
Cardioid mode can help eliminate those cancellations before they happen, leading to better sound quality and impact for the audience. Front Facing Preset 1 to 7 Area of Audience Rear Facing Reduced Area Cardioid Bass Level Preset 8 Front Facing Preset 1 to 7 SSP218-MK3 User Manual... -
Page 13: Specifications
Operating voltage range 100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply) Current consumption, 120V 9A (nominal); 240V 4.5A (nominal) nominal Signal input connector XLR-F Signal Output Connector XLR-M (Direct pass-through, unprocessed) EtherCON RJ45 (x2) with 2-port Ethernet switch LAN connectors bassboss.com 13... - Page 14 7 handles. Transports up to 4 cabinets. Heavy-duty padded nylon transport covers for 1or 2 cabinets Covers Hardware M10 Shoulder Eye Bolts, M10 Side-Pull anchors Our proactive philosophy causes specifications to be subject to change whenever improvements are made. 30” W 24” D SSP218-MK3 User Manual...
-
Page 15: Warranty
BASSBOSS personnel. Service will be performed upon the return of the failed unit, together with its original sales receipt or other proof of purchase, to BASSBOSS or an Authorized Service Facility. Purchaser is responsible for all costs of shipping and handling. Cosmetic damage is specifically excluded from this warranty. -
Page 16: Safety Information
The audio system must comply with current local standards and regulations regarding electrical systems. For installation purposes, BASSBOSS strongly recommends that this product be installed by a qualified, professional installer who can ensure correct installation and certify that it is installed in compliance with the regulations in force. -
Page 17: Important Notes
Manufacturer True Lee Loudspeakers | BASSBOSS 2028 E Ben White Blvd. #240-8220 Austin TX 78741 We declare, under our sole responsibility, that to the best of our knowledge to which this declaration relates, our products are in conformity with the applicable requirements. - Page 18 Double 18” SSP218-MK3 Powered Subwoofer Need more assistance? We’re here to help. help.bassboss.com...
