Summary of Contents for BassBoss SSP218
- Page 1 SSP218 Dual 18” Powered Subwoofer...
-
Page 2: Table Of Contents
SSP218 Dual 18” Powered Subwoofer Table of contents Description Specifications Setup Instructions Operation and Controls Cardioid Switch Photos Troubleshooting Flash Sequence Codes Safety Information Warranty FCC Compliance Notice Extended Deep Bass Super-High Continuous Output Exceptional Sound Quality Unbeatable Reliability bassboss.com... - Page 3 R&B music emphasize bass and put tremendous demands on low frequency loudspeakers. The SSP218 delivers the energy and power of modern music and it is built to take the stress of doing so continuously, to the extremes, without fail.
- Page 4 *Peak output is calculated using “industry standard” techniques. These calculation methods create theoretical specifications that are inflated over what can actually be achieved. BASSBOSS real world output specifications are provided as “Maximum Sustained Output” ratings, which reflect actual measured, continuous output levels.
-
Page 5: Setup Instructions
The total power draw of one SSP218 amplifier module is 15A. Only one SSP218 should be connected to a 20A circuit. The typical power draw of one SSP218 amplifier module is 5A. With heavy demand, the current draw can peak at 20A for brief periods but under NEMA code, a 20A breaker should sustain a peak draw of 40A for several seconds without tripping. -
Page 6: Operation And Controls
3dB. The greatest level reduction occurs on axis with a line drawn from the center of the NORMAL cabinet’s baffle, through the center of the CARDIOID cabinet’s baffle. Reduced << CARDIOID (-3dB) Audience Level NORMAL >> Audience Area Audience Three-dimensional representation of cardioid output pattern. bassboss.com... - Page 7 bassboss.com...
-
Page 8: Troubleshooting
FAULT FROM GATE PCB WHILE AMP WAS WORKING: Amp shuts down. Service Required. FAULT FROM PFC: (240V option only) Amp shuts down. Service Required. (May reset with power cycle if false triggered.) GFI MALFUNCTION: Amp shuts down. Service Required. FAULT FROM GATE PCB: Amp shuts down. Service Required. bassboss.com... -
Page 9: Safety Information
Contact your dealer or BASSBOSS support if the product is not functioning properly. BASSBOSS strongly recommends this product be installed by a qualified, professional installer who can ensure correct installation and certify that it is installed in compliance with the regulations in force. - Page 10 BASSBOSS personnel. This warranty does not cover labor other than that authorized and performed by BASSBOSS personnel. Service will be performed upon the return of the failed unit, together with its original sales receipt or other proof of purchase, to BASSBOSS or an Authorized Service Facility.
-
Page 11: Fcc Compliance Notice
BASSBOSS to perform said services. Please contact BASSBOSS or your local BASSBOSS dealer before attempting any repairs and before shipping parts in for service. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. For more information concerning BASSBOSS service and warranty policies please contact us at (855) 822-7770 toll-free. - Page 12 SSP218 Dual 18” Powered Subwoofer Need more assistance? Support is available via phone or email. family@bassboss.com 855-822-7770 toll free www.bassboss.com...
