Fortec Star ASUS J6412T-IM-A Manual

Thin mini itx, intel j6412 soc onboard processors, 2*so dimm. 1* pcie x1, hdmi, lvds, dual lan, m.2 slot
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
ASUS IoT
J6412T-IM-A
Thin mini ITX, Intel® J6412 SoC onboard Processors, 2*SO DIMM.
1* PCIe x1, HDMI, LVDS, Dual LAN, M.2 slot
The information contained in this document has been carefully researched and is, to the best of our
knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or
consequential, resulting from the use of the information provided herein. Our products are not intended for
use in systems in which failures of product could result in personal injury. All trademarks mentioned herein
are property of their respective owners. All specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASUS J6412T-IM-A and is the answer not in the manual?

Questions and answers

Related Manuals for Fortec Star ASUS J6412T-IM-A

Summary of Contents for Fortec Star ASUS J6412T-IM-A

  • Page 1 Manual ASUS IoT J6412T-IM-A Thin mini ITX, Intel® J6412 SoC onboard Processors, 2*SO DIMM. 1* PCIe x1, HDMI, LVDS, Dual LAN, M.2 slot The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate.
  • Page 2 J6412T-IM-A...
  • Page 3 E23549 Revised Edition V6 April 2024 Copyright © 2024 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC.

  • Page 4: Table Of Contents

    Contents Chapter 1 Product overview Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Central Processing Unit (CPU) ........... 2-4 System memory ................2-5 Jumpers ..................
  • Page 5 3.3.11 NVMe Configuration ............3-8 3.3.12 Onboard Device Configuration ........3-9 3.3.13 APM Configuration ............3-10 3.3.14 Watchdog Timer ............3-10 3.3.15 EZ-Flash ............... 3-11 3.3.16 LVDS Configuration ............3-11 Hardware Monitor menu ............3-12 Security menu ................3-12 Boot menu .................. 3-14 Exit menu ..................

  • Page 6: Chapter 1 Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x ASUS J6412T-IM-A Motherboard 1 x SATA 6.0 Gb/s cable 1 x SATA power cable 2 x ASUS I/O Shield NOTE: If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 7: Specifications

    1.3 Specifications Built-in Intel J6412 SoC onboard Processor ® 2 x DDR4, max.32GB, DDR4 3200/3000/2800/2666/2400/2133 Memory MHz Non-ECC, Unbuffered Memory Integrated graphics processor - Intel HD Graphics support ® - Supports HDMI™ 1.4b output with a maximum resolution of 3840 x 2160 @ 30Hz - Supports DisplayPort ++1.2 output with a maximum resolution of 4096 x 2160 @ 60Hz - Supports DisplayPort ++1.2 output with a maximum...
  • Page 8 2 x USB 2.0 headers support additional 4 USB 2.0 ports 1 x 8-bit GPIO header 1 x COM Debug header 1 x 4-pin ATX 12V power connector 1 x SATA power connector 1 x SATA port 1 x PS/2 port 1 x Speaker header Internal Connectors...
  • Page 9 J6412T-IM-A...

  • Page 10: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component.

  • Page 11: Motherboard Layout

    Motherboard layout NOTE: Place four screws into the holes indicated by circles to secure the motherboard to the chassis. CAUTION! Do not overtighten the screws! Doing so can damage the motherboard. 17.0cm(6.7in) BKLTEN_SEL DC_PWR LCD_BLKT_PANEL LVDS_EDP ATX12V 2280 Super 8111H (BOTTOM) Intel ®...
  • Page 12 Connectors/Jumpers/Slots Page ATX power connector (4-pin ATX12V) 2-11 Built-in Intel Celeron Quad-core Processor J6412 ® ® SPI_TPM header (14-1 pin SPI_TPM) 2-22 DDR4 SO-DIMM slots LVDS/EDP header (40-pin LVDS_EDP) 2-16 LVDS Panel Backlight Enable Signal Selection (BKLTEN_SEL) LVDS Backlight Panel header (5-pin LCD_BLKT_PANEL) 2-15 Chassis Fan header (4-pin CHA_FAN) 2-11...

  • Page 13: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) The motherboard comes with an onboard Intel processor J6412. ® Intel ® J6412 SoC J6412T-IM-A...

  • Page 14: System Memory

    System memory This motherboard comes with two Double Data Rate 4 Low Voltage (DDR4L) Small Outline Dual Inline Memory Module (SO-DIMM) sockets. The figure illustrates the location of the DDR4L DIMM socket: Sockets Channel Channel A DIMM_A1 Channel B DIMM_B1 IMPORTANT! •...

  • Page 15: Jumpers

    Jumpers Clear RTC RAM (2-pin CLRTC) This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. CLRTC1 PIN 1 Connector type HEADER 1x2p, 2.54mm pitch, S/T To erase the RTC RAM: Turn OFF the computer and unplug the power cord.
  • Page 16 AT/ATX mode selection jumper (3-pin AT_ATX_SEL) AT_ATX_SEL ATX MODE AT MODE (Default) Pins 1-2 (Default) ATX mode AT mode HEADER 1x3p, 2.54mm pitch, S/T Connector type COM Ring/+5V/+12V selection jumpers (6-pin COM1_SEL, COM2_SEL) COM1_SEL COM2_SEL (Default) Setting Pins Ring (Default) Chapter 2: Motherboard information...
  • Page 17 Chassis intrusion header (4-1 pin_CHASSIS) This header is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a low-level signal to this connector when a chassis component is installed.
  • Page 18 LVDS Panel Backlight Enable Signal Selection (BKLTEN_SEL) BKLTEN_SEL LCD_ENABKLT_S LCD_ENABKLT_S# (Default) Pins 12V (Default) Connector type HEADER 1x3p, 2.54mm pitch, S/T Internal Stereo Speaker header (2-pin STEREO_OUT_L, STEREO_ OUT_R) The internal mono speaker header allows connection to an internal, low- power speaker for basic system sound capability.

  • Page 19: Connectors

    Connectors 2.6.1 Rear panel connectors DC power connector. Insert the power adapter into this port. CAUTION! To avoid potential damage or system instability, do not connect both the DC power connector and the ATX power connector simultaneously. DisplayPort port. This port connects a device with DisplayPort connector. HDMI™...

  • Page 20: Internal Connectors

    2.6.2 Internal connectors ATX power connector (4-pin ATX12V) Correctly orient the ATX power supply plug into this connector and push down firmly until the connector completely fits. ATX12V DC_PWR DC_PWR PIN 1 CAUTION! To avoid potential damage or system instability, do not connect both the DC power connector and the ATX power connector simultaneously.
  • Page 21 PS/2 Keyboard/mouse header (8-pin KBMS_CON) This header is for an IBM PS/2-compatible keyboard or mouse. PIN 1 KBMS_CON USB 2.0 headers (10-pin USB_12, USB_34) These headers are for USB 2.0 ports. Connect the USB cables to these headers. These USB headers comply with USB 2.0 specification that supports up to 480 Mbps connection speed.
  • Page 22 CAUTION! Never connect a 1394 cable to the USB headers. Doing so will damage the motherboard. NOTE: The USB cables are purchased separately. SATA power connector (4-pin SATA_PWR) This connector is for the SATA power cable. The power cable plug is designed to fit this connector in only one orientation.
  • Page 23 Speaker header (4-pin SPEAKER) The 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. SPEAKER PIN 1 Connector type HEADER 1x4p, 2.54mm pitch, S/T System Panel header (10-1 pin F_PANEL) This header supports several chassis-mounted functions.
  • Page 24 • System power LED (2-pin +PWR_LED) This 2-pin header is for the system power LED. Connect the chassis power LED cable to this header. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. •...
  • Page 25 10. COM Debug header This header allows connection to a COM Debug card. COM_DEBUG PIN 1 Connector type HEADER 2x3p, K3, 2.54mm pitch NOTE: The COM Debug card is purchased separately. 11. MPCIe slot (MPCIE) This slot allows you to install a full length mini-PCIe card, providing you with expandability and connectivity solutions for an optimal system performance.
  • Page 26 12. LVDS/EDP header (40-pin LVDS_EDP) This header is for an internal LVDS or embedded DisplayPort connection. PIN 1 PIN 39 LVDS_EDP PIN 2 PIN 40 Chapter 2: Motherboard information 2-17...
  • Page 27 13. M.2 socket 3 (M.2_SOCKET3) This socket allows you to install an M.2 SSD module. M.2(SOCKET3) NOTES: • The M.2 SSD module is purchased separately. • This slot support M Key and 2242/2260/2280 storage devices. • We recommend using a PH1 screwdriver with a torque of 2.0+/-0.2 kgf·cm when tightening the screw.
  • Page 28 15. General Purpose Input/output header (GPIO_CON) This header is for a general purpose input/output module which allows you to customize the digital signal input/output. GPIO_CON PIN 1 WAFER HD 2x5p, 2.0mm pitch, S/T Connector type 16. RTC Battery header (2-pin BATT_CON) This header is for the lithium CMOS battery.
  • Page 29 17. Front Panel Audio header (10-1 pin AAFP) This header is for a chassis-mounted front panel audio I/O module that supports HD Audio standard. Connect one end of the front panel audio I/O module cable to this header. AAFP PIN 1 Connector type HEADER 2x5p, K8, 2.54mm pitch IMPORTANT!
  • Page 30 19. NANO SIM Card slot This slot connects to a NANO SIM card. NANO_SIM 20. COM Port headers (10-pin COM1~COM6) These headers are for serial (COM) ports. Connect the serial port cables to these headers, then install the module to a slot opening at the back of the system chassis.
  • Page 31 21. SPI TPM header (14-1 pin TPM) This header supports a Trusted Platform Module (TPM) system with a Serial Peripheral Interface (SPI), allowing you to securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 32 23. PCIe 3.0/2.0 x1 slot (PCIEX1) This slot supports a PCIe 3.0/2.0 x1 graphics card that complies with the PCI Express specification. PCIEX1 PIN A1-A18 PIN B1-B18 Chapter 2: Motherboard information 2-23...
  • Page 33 J6412T-IM-A 2-24...

  • Page 34: Chapter 3 Bios Setup

    Chapter 3 BIOS setup Chapter 3 BIOS setup Scan the QR code to view the BIOS update guide. BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program.

  • Page 35: Bios Menu Screen

    3.1.1 BIOS menu screen Menu bar The menu bar on top of the screen has the following main items: For changing the basic system configuration Main For changing the advanced system settings Advanced Hardware For displaying the system temperature and changing the Monitor fan settings For configuring the system security settings...

  • Page 36: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.3.1 PCH-FW Configuration TPM Device Selection This item allows you to select the TPM device.

  • Page 37: Graphics Configuration

    C states [Disabled] Disables the CPU C states. [Enabled] Enables the CPU C states. Enhanced C-states [Disabled] Disables enhanced C1E state. [Enabled] Enables enhanced C1E state. Power Limit 1 Override [Disabled] Disables power limit 1 override. [Enabled] Enables power limit 1 override. The following item appears only when you set the previous item to [Enabled].

  • Page 38: Super Io Configuration

    L1 Substates This item allows you to select the PCI Express L1 Substate settings. Configuration options: [Disabled] [L1.1] [L1.2] [L1.1 & L1.2] PCIe Speed Configures the speed of PCIEX16_2 slot. Configuration options: [Auto] [Gen1] [Gen2] [Gen3] Detect Timeout This item allows you to set the number of milliseconds to wait before assuming there is no device and potentially disabling the port.

  • Page 39: Serial Console Redirection

    3.3.7 Serial Console Redirection COM1~COM6 Console Redirection Configuration options: Allows you enable or disable the console redirection feature. [Disabled] [Enabled] The following item appears only when you set the previous item to [Enabled]. Console Redirection Settings These items become configurable only when you enable the Console Redirection item.

  • Page 40: Sata Configuration

    Stop Bits Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning.) The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. Configuration options: [1] [2] Flow Control Flow control can prevent data loss from buffer overflow.

  • Page 41: Network Stack Configuration

    3.3.9 Network Stack Configuration Network Stack This item allows user to disable or enable the UEFI network stack. Configuration options: [Disabled] [Enabled] The following items appear only when you set the previous item to [Enabled]. Ipv4 PXE Support This item allows user to disable or enable the Ipv4 PXE Boot support. Configuration options: [Disabled] [Enabled] Ipv6 PXE Support This item allows user to disable or enable the Ipv6 PXE Boot support.

  • Page 42: Onboard Device Configuration

    3.3.12 Onboard Device Configuration HD Audio [Disabled] Disables the HD Audio Device. [Enabled] Enables the HD Audio Device. Realtek LAN 1 Controller [Disabled] DisablesRealtek LAN 1 Controller. [Enabled] Enables Realtek LAN 1 Controller. Realtek LAN 2 Controller [Disabled] Disables Realtek LAN 2 Controller. [Enabled] Enables Realtek LAN 2 Controller.

  • Page 43: Apm Configuration

    3.3.13 APM Configuration ErP Ready Allows you to switch off some power at S5 to get the system ready for ErP requirement. When set to [Enabled], all other PME options will be switched off. Configuration options: [Disabled] [Enabled] Restore AC Power Loss [S5 State] The system goes into off state after an AC power loss.

  • Page 44: Ez-Flash

    3.3.15 EZ-Flash Enter Ez-Flash mode This item allows you to run EzFlash utility. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. 3.3.16 LVDS Configuration The items in this menu show the LVDS-related information that the BIOS automatically detects.

  • Page 45: Hardware Monitor Menu

    Hardware Monitor menu The items in this menu provide you an overview of system status including temperature, fan speed and voltage, and allow you to configure the smart fan. Smart Fan Mode Allows you to select the smart fan mode. Configuration options: [Disabled] [Normal] [Manual Mode] The following item appears only when you set Smart Fan Mode to [Manual Mode].

  • Page 46: User Password

    To clear the administrator password, follow the same steps as in changing an administrator password, but press <Enter> when prompted to create/confirm the password. User Password If you have set a user password, you must enter the user password for accessing the system.

  • Page 47: Boot Menu

    Boot menu The Boot menu items allow you to change the system boot options. Boot Configuration CHASSIS INTRUDE Allows you to enable or disable the chassis intrusion detection function. Configuration options: [Disabled] [Enabled] Setup Prompt Timeout Allows you to set the number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.

  • Page 48: Save Changes & Reset

    Save Changes & Reset This option allows you to exit the Setup program after saving changes. Discard Changes & Reset This option allows you to exit the Setup program without saving changes. Save Changes This option allows you to save changes to any of the setup options you have made so far.
  • Page 49 J6412T-IM-A 3-16...

  • Page 50: Appendix

    Appendix Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 51 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 52 Declaration of compliance for product environmental regulation ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements.

  • Page 53: Asus Recycling/Takeback Services

    ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.

  • Page 54: Service And Support

    Service and Support Visit our multi-language website at https://www.asus.com/support/ Manufacturer ASUSTek COMPUTER INC. Address, City 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112 Authorized ASUS COMPUTER GmbH Representative in Europe Address Harkortstrasse 21-23, 40880 Ratingen Country Germany Authorized ASUSTEK (UK) LIMITED Representative in United Kingdom...
  • Page 55 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Augsburger Str. 2b 82110 Germering Phone: +49 89 894450-0 E-Mail: info@fortecag.de Internet: www.fortecag.de Fortec Group Members Austria FORTEC Integrated GmbH Office Vienna...
