iBASE
MB995
ATX Motherboard for
8th Gen Intel® Xeon® E / Core™ i7/i5/i3 Prozessor w/ Intel® C246/ Q370 PCH
The information contained in this document has been carefully researched and is, to the best of our
knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or
consequential, resulting from the use of the information provided herein. Our products are not intended for
use in systems in which failures of product could result in personal injury. All trademarks mentioned herein
are property of their respective owners. All specifications are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for Fortec Star iBASE MB995
Summary of Contents for Fortec Star iBASE MB995
- Page 1 Manual iBASE MB995 ATX Motherboard for 8th Gen Intel® Xeon® E / Core™ i7/i5/i3 Prozessor w/ Intel® C246/ Q370 PCH The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
- Page 2 MB995 Core™ i7/i5/i3 ® Gen. Intel ® / Xeon ATX Motherboard User’s Manual Version 1.0 (July 2018)
- Page 3 Copyright © 2018 IBASE Technology, Inc. All rights reserved. No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
-
Page 4: Compliance
Compliance In a domestic environment, this product may cause radio interference in which case users may be required to take adequate measures. This product has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Important Safety Information
Important Safety Information Carefully read the precautions before using the board. Environmental conditions: • Use this product in environments with ambient temperatures between 0˚C and 60˚C. • Do not leave this product in an environment where the storage temperature may be below -20° C or above 80° C. To prevent from damages, the product must be used in a controlled environment. -
Page 6: Warranty Policy
Warranty Policy • IBASE standard products: 24-month (2-year) warranty from the date of shipment. If the date of shipment cannot be ascertained, the product serial numbers can be used to determine the approximate shipping date. • -party parts: 12-month (1-year) warranty from delivery for the 3 -party parts that are not manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices, power adapter, panel and touchscreen. -
Page 7: Table Of Contents
Table of Contents Compliance ..................iii Important Safety Information ............iv Warranty Policy ................v Technical Support & Services ............v Chapter 1 General Information ..........1 Introduction ..................2 Features ....................2 Packing List ..................3 Optional Accessories ................3 Specifications .................. - Page 8 2.5.10 ATX Power Connector (J23) ..........26 2.5.11 ATX 12V Power Connector (ATX_12V_2X1) .......27 2.5.12 CPU Fan Power Connector (CPU_FAN1) ......28 2.5.13 System Fan Power Connector (SYS_FAN1, SYS_FAN2) ..29 Chapter 3 Drivers Installation ..........31 Introduction ..................32 ® Intel Chipset Software Installation Utility ...........32 HD Graphics Driver Installation ............33 HD Audio Driver Installation ...............35 LAN Driver Installation ...............36...
- Page 9 I/O Port Address Map ................ 62 Interrupt Request Lines (IRQ) ............65 Watchdog Timer Configuration ............67 On-Board Connector Types ............... 71 MB995 User’s Manual viii...
-
Page 10: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Block Diagram • Board Overview • Board Dimensions... -
Page 11: Introduction
Introduction ® MB995 is an ATX motherboard based on the Intel Gen. Processor that features four DDR memory sockets and supports up to 64 GB and high- performance graphics processing to create media-rich content and brilliant HD entertainment with DVI-D, HDMI (2.0a) and DisplayPort display interface. -
Page 12: Packing List
General Information Packing List Your MB995 package should include the items listed below. If any of the items below is missing, contact the distributor or dealer from whom you purchased the product. • MB995 Motherboard • I/O shield • SATA cable (SATA-3F) •... -
Page 13: Specifications
Specifications Product Name MB995VF-C246 MB995VF Form Factor ATX motherboard System • Windows 10 (64-bit) Operating • Linux Fedora (64-bit) & Ubuntu (64-bit) System • Windows Server ® ® Socket LGA1151 for 8 Gen. Intel Xeon E / Core i7/i5/i3 HC/QC/DC processors ®... - Page 14 General Information Product Name MB995VF-C246 MB995VF EuP/ErP Compliance RoHS Dimensions 305 x 244 mm (12" x 9.61") Certification CE (EN55032:2012), FCC Class B, LVD I/O Ports • 1 x HDMI 2.0a (4096 x 2160 at 60 Hz) • Display 1 x DisplayPort 1.2 (4096 x 2160 at 60 Hz) •...
-
Page 15: Block Diagram
Block Diagram MB995 User’s Manual... -
Page 16: Overview
General Information Overview Top View I/O View Name Name COM1 Port Audio Line-In COM2 Port Audio Line-Out DVI-D Port Microphone-In 7 USB 3.1 Ports DisplayPort GbE LAN Ports HDMI Port MB995 User’s Manual... - Page 17 Bottom View ＊The photos above are for reference only. Some minor components may differ. MB995 User’s Manual...
-
Page 18: Dimensions
General Information Dimensions MB995 User’s Manual... - Page 19 This page is intentionally left blank. MB995 User’s Manual...
-
Page 20: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration This section provides information on jumper settings and connectors on the board in order to set up a workable system. The topics covered are: • Essential installations before you begin: CPU and the memory • Jumper and connector locations •... -
Page 21: Installations
Installations 2.1.1 Installing the Memory To install the modules, locate the memory slot on the board and perform the following steps: Press the ejector tabs of the memory slot down and outwards with your fingertips. Hold the meomry module and align the key of the module with that on the memory slot. -
Page 22: Setting The Jumpers
Hardware Configuration Setting the Jumpers Set up and configure this board by using jumpers for various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your use. 2.2.1 How to Set Jumpers Jumpers are short-length conductors consisting of several metal pins with a non-conductive base mounted on the circuit board. -
Page 23: Jumper & Connector Locations On Mb995
Jumper & Connector Locations on MB995 MB995 User’s Manual... -
Page 24: Jumpers Quick Reference
Hardware Configuration Jumpers Quick Reference Function Jumper Name Page Clearing CMOS Data PCIe (x16) Bifurcation Selection JP2, JP3 Factory Use Only JP4, JP5 2.4.1 Clearing CMOS Data (JP6) Function Pin closed Illustration Normal (default) Clear CMOS MB995 User’s Manual... -
Page 25: Pcie (X16) Bifurcation Selection (Jp2 & Jp3)
2.4.2 PCIe (x16) Bifurcation Selection (JP2 & JP3) Function Pin closed Illustration JP2: Open 1 x PCIe (x16) (default) JP3: Open JP2: Open 2 x PCIe (x8) JP3: Close JP2: Close RSVD JP3: Open JP2: Close 1 x PCIe (x8) 2 x PCIe (x4) JP3: Close MB995 User’s Manual... -
Page 26: Connectors Quick Reference
Hardware Configuration Connectors Quick Reference Function Connector Name Page COM1 & COM2 RS-232/422/485 Ports Front Panel Audio Connector Digital I/O Connector COM3, COM4, COM5, COM6 RS-232 J8 (COM3), J7 (COM4), Ports J5 (COM5), J3 (COM6) PS/2 Keyboard & Mouse Ports USB 2.0 Ports USB 3.1 Connectors Front Panel Settings Connector... -
Page 27: Com1 & Com2 Rs-232/422/485 Ports (Cn3)
2.5.1 COM1 & COM2 RS-232/422/485 Ports (CN3) COM1: COM2: Signal Name Signal Name DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal RI, Ring indicator ready Ground Signal Name... -
Page 28: Front Panel Audio Connector (J1)
Hardware Configuration 2.5.2 Front Panel Audio Connector (J1) Signal Name Signal Name MIC IN_L Ground MIC IN_R LINE_R Ground Sense LINE_L Ground MB995 User’s Manual... -
Page 29: Digital I/O Connector (J2)
2.5.3 Digital I/O Connector (J2) (4-In, 4-Out) Signal Name Signal Name Ground OUT3 OUT1 OUT2 OUT0 MB995 User’s Manual... -
Page 30: Com3, Com4, Com5, Com6 Rs-232 Ports (J8, J7, J5, J3)
Hardware Configuration 2.5.4 COM3, COM4, COM5, COM6 RS-232 Ports (J8, J7, J5, J3) J8: COM3 J7: COM4 J5: COM5 J3: COM6 Signal Name Signal Name DCD, Data carrier detect RXD, Receive data DTR, Data terminal TXD, Transmit data ready Ground DSR, Data set ready RTS, Request to send CTS, Clear to send... -
Page 31: Ps/2 Keyboard & Mouse Ports (J10)
2.5.5 PS/2 Keyboard & Mouse Ports (J10) Signal Name Signal Name KBDA KBCL Ground Ground 2.5.6 USB 2.0 Ports (J15) Signal Name Signal Name Ground Ground MB995 User’s Manual... -
Page 32: Usb 3.1 Ports (J16)
Hardware Configuration 2.5.7 USB 3.1 Ports (J16) Signal Name Signal Name P2_U2_D+ P1_SSRX- P2_U2_D- P1_SSRX+ Ground Ground P2_SSTX+ P1_SSTX- P2_SSTX- P1_SSTX+ Ground Ground P2_SSRX+ P1_U2_D- P2_SSRX- P1_U2_D+ MB995 User’s Manual... -
Page 33: Front Panel Settings Connector (J18)
2.5.8 Front Panel Settings Connector (J18) Signal Name Signal Name Power LED+ Ground Power LED- Ground SPK (VCC) Ground Ground Power BTN Power BTN Reset BTN Reset BTN HDD LED+ HDD LED- J18 is utilized for system indicators to provide light indication of the computer activities and switches to change the computer status. -
Page 34: S3 Status Connector (J22)
Hardware Configuration • Reset Switch (Pins 17 and 18) The reset switch allows you to reset the system without turning the main power switch off and then on again. Orientation is not required when making a connection to this header. •... -
Page 35: Atx Power Connector (J23)
2.5.10 ATX Power Connector (J23) Signal Name Signal Name 3.3V 3.3V 3.3V -12V Ground Ground PS-ON Ground Ground Ground Ground Ground Power good 5VSB +12V +12V 3.3V Ground MB995 User’s Manual... -
Page 36: Atx 12V Power Connector (Atx_12V_2X1)
Hardware Configuration 2.5.11 ATX 12V Power Connector (ATX_12V_2X1) Signal Name Signal Name Ground +12V Ground +12V Ground +12V Ground +12V MB995 User’s Manual... -
Page 37: Cpu Fan Power Connector (Cpu_Fan1)
2.5.12 CPU Fan Power Connector (CPU_FAN1) Signal Name Signal Name Ground Rotation detection +12V Control MB995 User’s Manual... -
Page 38: System Fan Power Connector (Sys_Fan1, Sys_Fan2)
Hardware Configuration 2.5.13 System Fan Power Connector (SYS_FAN1, SYS_FAN2) SYS_FAN2 SYS_FAN1 Signal Name Signal Name Ground Rotation detection +12V Control MB995 User’s Manual... - Page 39 This page is intentionally left blank. MB995 User’s Manual...
-
Page 40: Chapter 3 Drivers Installation
Chapter 3 Drivers Installation This chapter introduces installation of the following drivers: • ® Intel Chipset Software Installation Utility • HD Graphics Driver • HD Audio Driver • LAN Driver • ® Intel Management Engine Drivers Installation... -
Page 41: Introduction
Introduction This section describes the installation procedures for software and drivers. The software and drivers are included with the motherboard. If you find anything missing, please contact the distributor where you made the purchase. The contents of this section include the following: ®... -
Page 42: Hd Graphics Driver Installation
Driver Installation ® When the Welcome screen to the Intel Chipset Device Software appears, click Next to continue. Accept the software license agreement and proceed with the installation process. On the Readme File Information screen, click Install for installation. The driver has been completely installed. Restart the computer for changes to take effect. - Page 43 When the Welcome screen appears, click Next to continue. Accept the license agreement and click Next. On the Readme File Information screen, click Next until the installation starts. The driver has been completely installed. Restart the computer for changes to take effect. MB995 User’s Manual...
-
Page 44: Hd Audio Driver Installation
Driver Installation HD Audio Driver Installation Click Intel on the left pane and then Intel(R) Coffeelake Chipset Drivers on the right pane. Click Realtek High Definition Audio Driver. On the Welcome screen of the InstallShield Wizard, click Next. Click Next until the installation starts. The driver has been completely installed. -
Page 45: Lan Driver Installation
LAN Driver Installation Click Intel on the left pane and then Intel(R) Coffeelake Chipset Drivers on the right pane. Click Intel(R) PRO LAN Network Drivers.. When the Welcome screen appears, click Next. MB995 User’s Manual... -
Page 46: Intel ® Management Engine Drivers Installation
Driver Installation Accept the license agreement and click Next. On the Setup Options screen, click the checkbox to select the desired driver(s) for installation. Then click Next to continue. The wizard is ready for installation. Click Install. As the installation is complete, restart the computer for changes to take effect. - Page 47 Click Intel(R) ME 12.x Drivers. When the Welcome screen appears, click Next. Accept the license agreement, choose a destination folder and click Next until the installation starts. As the driver has been sccessfully installed, restart the computer for changes to take effect. MB995 User’s Manual...
-
Page 48: Chapter 4 Bios Setup
Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Boot Settings •... -
Page 49: Introduction
4.1 Introduction The BIOS (Basic Input/Output System) installed in the ROM of your ® computer system supports Intel processors. The BIOS provides critical low-level support for standard devices such as disk drives, serial ports and parallel ports. It also provides password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system. -
Page 50: 4.3 Main Settings
BIOS Setup 4.3 Main Settings BIOS Setting Description System Date Sets the date. Use theTab to switch between the data elements. Default Ranges: Year: 2005-2099 Months: 1-12 Days: dependent on month System Time Set the time. Use Tab to switch between the Time elements. -
Page 51: 4.4 Advanced Settings
4.4 Advanced Settings This section allows you to configure, improve your system and allows you to set up some system features according to your preference. BIOS Setting Description Connectivity Configure Connectivity related options Configuration CPU Configuration Displays CPU configuration parameters Power &... -
Page 52: Connectivity Configuration
BIOS Setup 4.4.1 Connectivity Configuration BIOS Setting Description CNVi Mode This option configures Connectivity. [Auto Detection] means that if discrete solution is discovered it will be enabled by default. Otherwise, integrated solution (CNVi) will be enabled; [Disable Integrated] disables Integrated Solution. MfUart1 type This is a test option which allows configuration of UART type for WiFi side band... -
Page 53: Cpu Configuration
4.4.2 CPU Configuration BIOS Setting Description Intel (VMX) When enabled, a VMM can utilize the Virtualization additional hardware capabilities provided by Technology Vanderpool Technology. Active Processor Number of cores to enable in each processor Cores package. Options: All, 1, 2, 3 Enables / Disables AES (Advanced Encryption Standard). -
Page 54: Power & Performance
BIOS Setup 4.4.3 Power & Performance BIOS Setting Description CPU – Power CPU – Power Management Control Options Management Control Intel SpeedStep Allows more than two frequency ranges to be supported Intel Speed Shift This can be Enabled or Disabled. Technology 4.4.4 PCH-FW Configuration... -
Page 55: Trusted Computing
4.4.5 Trusted Computing BIOS Setting Description Security Device Enables / Disables BIOS support for security Support device. OS will not show security device. TCG EFI protocol and INTIA interface will not be available. SHA-1 PCR Bank Enable or Disable SHA-1 PCR Bank SHA256 PCR Bank Enable or Disable SHA256 PCR Bank Pending operation... -
Page 56: Acpi Settings
BIOS Setup 4.4.6 ACPI Settings BIOS Setting Description Enable Hibernation Enables / Disables the system ability to hibernate (OS/S4 Sleep State). This option may be not effective with some OS. ACPI Sleep State Selects an ACPI sleep state where the system will enter when the Suspend button is pressed. -
Page 57: Ismart Controller
4.4.7 iSmart Controller BIOS Setting Description Power-On after Enables / Disables the system to be turned on Power Failure automatically after a power failure. Temperature Generate the reset signal when system hands Guardian up on POST. Schedule Slots Sets up the hour / minute / day for the power- on schedule for the system. -
Page 58: F81966 Super Io Configuration
BIOS Setup 4.4.8 F81966 Super IO Configuration BIOS Setting Description Serial Port Sets parameters of Serial Ports. Configuration Enables / Disables the serial port and select an optimal setting for the Super IO device. MB995 User’s Manual... -
Page 59: Hardware Monitor
4.4.9 Hardware Monitor BIOS Setting Description Enables / Disables the CPU smart fan feature. CPU Smart Fan Control Options: Disabled / 50 °C / 60 °C / 70 °C / 80 °C Enables / Disables the system smart fan feature. System Smart Fan Control Options: Disabled / 50 °C / 60 °C / 70 °C / 80 °C... -
Page 60: Usb Configuration
BIOS Setup 4.4.11 USB Configuration BIOS Setting Description Legacy USB Support Enables Legacy USB support. • Auto disables legacy support if there is no USB device connected. • Disable keeps USB devices available only for EFI applications. XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. - Page 61 BIOS Setting Description Device power-up The maximum time the device will take before delay it properly reports itself to the Host Controller. Auto uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor.
-
Page 62: Network Stack Configuration
BIOS Setup 4.4.12 Network Stack Configuration BIOS Setting Description Network Stack Enable/Disable UEFI Network Stack. 4.4.13 CSM Configuration BIOS Setting Description CSM Support Enables / Disables CSM support. Network Controls the execution of UEFI and Legacy PXE OpROM. Options: Do not launch / Legacy 4.4.14 NVMe Configuration BIOS Setting... -
Page 63: 4.5 Chipset Settings
4.5 Chipset Settings BIOS Setting Description System Agent (SA) System Agent (SA) parameters Configuration PCH-IO PCH parameters Configuration 4.5.1 System Agent (SA) Configuration BIOS Setting Description Graphics Configures the graphics settings. Configuration VT-d Checks if VT-d function on MCH is supported. MB995 User’s Manual... - Page 64 BIOS Setup 4.5.1.1. Graphics Configuration BIOS Setting Description Grapics Turbo IMON Graphics turbo IMON current values supported Current (14-31) Skip Scanning of If enabled, it will not scan for external Gfx Card External Gfx Card on PEG and PCH PCIE ports. Primary Display The default setting is Auto.
-
Page 65: Pch-Io Configuration
4.5.2 PCH-IO Configuration BIOS Setting Description SATA and RST Configures SATA devices. Configuration PCH LAN Controller Enables / Disables the onboard NIC. Enables / Disables the integrated LAN to wake Wake on LAN Enable up the system. MB995 User’s Manual... -
Page 66: 4.6 Security Settings
BIOS Setup 4.6 Security Settings BIOS Setting Description Administrator Sets an administrator password for the setup Password utility. User Password Sets a user password. Secure Boot Secure Boot feature is Active if Secure Boot is Enabled. Platform Key(PK) is enrolled and the System is in User mode. -
Page 67: 4.7 Boot Settings
4.7 Boot Settings BIOS Setting Description Setup Prompt Number of seconds to wait for setup activation Timeout key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock Selects the keyboard NumLock state. State Quiet Boot Enables / Disables Quiet Boot option. Boot mode select Selects a Boot mode, Legacy / UEFI. -
Page 68: 4.8 Save & Exit Settings
BIOS Setup 4.8 Save & Exit Settings BIOS Setting Description Save Changes and Exits system setup after saving the changes. Exit Discard Changes Exits system setup without saving any and Exit changes. Save Changes and Resets the system after saving the changes. Reset Discard Changes Resets system setup without saving any... - Page 69 This page is intentionally left blank. MB995 User’s Manual...
-
Page 70: Appendix
Appendix This section provides the mapping addresses of peripheral devices, the sample code of watchdog timer configuration, and types of on-board connectors. -
Page 71: I/O Port Address Map
I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A10-0x00000A1F... - Page 72 Appendix Address Device Description 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00001854-0x00001857 Motherboard resources 0x000003F8-0x000003FF...
- Page 73 Address Device Description 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard 0x0000EFA0-0x0000EFBF Intel(R) SMBus - A323 MB995 User’s Manual...
-
Page 74: Interrupt Request Lines (Irq)
Appendix Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ 8 System CMOS/real time clock IRQ 4294967292 Intel(R) PCI Express Root Port #11 - A332 IRQ 4294967288 Intel(R) USB 3.1 eXtensible Host Controller... - Page 75 Level Function IRQ 4294967279 Intel(R) Management Engine Interface IRQ 4294967289 Intel(R) UHD Graphics 630 IRQ 11 Intel(R) Thermal Subsystem - A379 IRQ 11 Intel(R) SMBus - A323 IRQ 0 System timer IRQ 1 Standard PS/2 Keyboard IRQ 4294967290 Intel(R) Ethernet Connection (7) I219-LM IRQ 12 Microsoft PS/2 Mouse IRQ 14...
-
Page 76: Watchdog Timer Configuration
Appendix Watchdog Timer Configuration The Watchdog Timer (WDT) is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. - Page 77 bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) EnableWDT(bTime); } else DisableWDT(); } return 0; //--------------------------------------------------------------------------- void EnableWDT(int interval) unsigned char bBuf; bBuf = Get_F81966_Reg(0x2B); bBuf &= (~0x20); Set_F81966_Reg(0x2B, bBuf); //Enable WDTO Set_F81966_LD(0x07); //switch to logic device 7 Set_F81966_Reg(0x30, 0x01);...
- Page 78 Appendix // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. //--------------------------------------------------------------------------- #include "F81966.H" #include <dos.h> //--------------------------------------------------------------------------- unsigned int F81966_BASE; void Unlock_F81966 (void); void Lock_F81966 (void); //--------------------------------------------------------------------------- unsigned int Init_F81966(void) unsigned int result;...
- Page 79 void Set_F81966_Reg( unsigned char REG, unsigned char DATA) Unlock_F81966(); outportb(F81966_INDEX_PORT, REG); outportb(F81966_DATA_PORT, DATA); Lock_F81966(); //--------------------------------------------------------------------------- unsigned char Get_F81966_Reg(unsigned char REG) unsigned char Result; Unlock_F81966(); outportb(F81966_INDEX_PORT, REG); Result = inportb(F81966_DATA_PORT); Lock_F81966(); return Result; //--------------------------------------------------------------------------- //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE.
-
Page 80: On-Board Connector Types
Appendix On-Board Connector Types Connector Compatible Mating Function Onboard Type Name Type for Reference COM1 & COM2 YIMTEX D-SUB 9-pin 232/422/485 40909AANSABR Ports Front Panel E-call Dupont Audio 0126-01-2821009 2.54 mm 2*5-pin Connector Digital I/O E-call Dupont Connector 0196-01-200-100 2.0 mm 2*5-pin J8 (COM3), COM3, COM4, J7 (COM4),... - Page 81 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, Great Britain and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Lechwiesenstr. 9 86899 Landsberg am Lech Phone: +49 8191 91172-0 E-Mail: sales@fortecag.de Internet: www.fortecag.de Fortec Group Members FORTEC Elektronik AG...
