Fortec Star ASUS H610I-IM-A Manual

Mini-itx, lga1700 socket for the 14/ 13/ 12th gen cpu, h610 chipset, 2*so-dimm, 1*pcie x16, 1*dp, 2*hdmi, 1*lvds, 2*m.2 slot.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
ASUS IoT
H610I-IM-A
Mini-ITX, LGA1700 socket for the 14/ 13/ 12th Gen CPU, H610 chipset, 2*SO-DIMM, 1*PCIe
x16, 1*DP, 2*HDMI, 1*LVDS, 2*M.2 slot.
The information contained in this document has been carefully researched and is, to the best of our
knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or
consequential, resulting from the use of the information provided herein. Our products are not intended for
use in systems in which failures of product could result in personal injury. All trademarks mentioned herein
are property of their respective owners. All specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASUS H610I-IM-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fortec Star ASUS H610I-IM-A

Summary of Contents for Fortec Star ASUS H610I-IM-A

  • Page 1 Manual ASUS IoT H610I-IM-A Mini-ITX, LGA1700 socket for the 14/ 13/ 12th Gen CPU, H610 chipset, 2*SO-DIMM, 1*PCIe x16, 1*DP, 2*HDMI, 1*LVDS, 2*M.2 slot. The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate.
  • Page 2 H610I-IM-A...
  • Page 3 E23519 Revised Edition V5 April 2024 Copyright © 2024 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC.

  • Page 4: Table Of Contents

    Contents Chapter 1 Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Central Processing Unit (CPU) ........... 2-4 2.3.1 Installing the CPU ............2-5 2.3.2 CPU heatsink and fan assembly installation ....
  • Page 5 3.3.13 NVMe Configuration ............3-10 3.3.14 Onboard Devices Configuration ........3-10 3.3.15 APM Configuration ............3-11 3.3.16 EZ-Flash ............... 3-12 3.3.17 IO Expander Configuration ........... 3-12 3.3.18 Watchdog Timer ............3-12 Hardware Monitor menu ............3-12 Security menu ................3-13 Boot menu ..................

  • Page 6: Chapter 1 Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x ASUS H610I-IM-A Industrial Motherboard 1 x SATA 6.0 Gb/s cable 2 x M.2 screw packages 1 x ASUS I/O Shield NOTE: If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 7: Specifications

    1.3 Specifications LGA1700 socket for Intel Gen. Core™ i9/ i7/ i5/ i3, ® Pentium , and Celeron Processors ® ® Supports up to 65W Chipset Intel H610 Chipset ® 2 x SO-DIMM, max.64GB, DDR4 3200/2933/2666/2400 MHz Memory SDRAM Integrated graphics processor - Intel HD Graphics support ®...

  • Page 8: Chapter 1: General Information

    1 x CPU Fan header (PWM mode) 1 x Chassis Fan header (PWM mode) 1 x Chassis Intrusion header 1 x Front Panel Audio header (AAFP) 1 x System Panel header 1 x Clear CMOS header 1 x Speaker header Internal I/O connectors 1 x COM Debug header...
  • Page 9 H610I-IM-A...

  • Page 10: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component.

  • Page 11: Motherboard Layout

    Motherboard layout NOTE: Place nine screws into the holes indicated by circles to secure the motherboard to the chassis. CAUTION! Do not overtighten the screws! Doing so can damage the motherboard. 10 11 17.0cm(6.7in) AT_ATX_SEL GPIO_CON LCD_BLKT_PANEL SPEAKER CHASSIS CPU_FAN F_PANEL EATX12V COM3...
  • Page 12 Connectors/Jumpers/Slots Page COM RING/+5V/+12V selection jumper (COM1/2_SEL) 2-12 LCD Panel monitor switch header (2-pin PANEL_SW) 2-25 LVDS Backlight Panel header (5-pin LCD_BLKT_PANEL) 2-26 ATX Power connector (24-pin ATXPWR, 2 x 4-pin EATX12V) 2-16 Intel LGA1700 CPU socket ® Chassis Intrusion header (4-1 pin CHASSIS) 2-21 AT/ATX mode selection jumper (3-pin AT_ATX_SEL) 2-12...

  • Page 13: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) The motherboard comes with a surface mount LGA1700 socket designed for the Intel Gen. Core™ i9 / Core™ i7 / Core™ i5 / Core™ i3, Pentium ® ® and Celeron Processors. ® LGA1700 IMPORTANT: Unplug all power cables before installing the CPU. CAUTION! •...

  • Page 14: Installing The Cpu

    2.3.1 Installing the CPU • Ensure that you install the correct CPU designed for LGA1700 socket only. DO NOT install a CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket. • ASUS will not cover damages resulting from incorrect CPU installation/ removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.
  • Page 15 H610I-IM-A...

  • Page 16: Cpu Heatsink And Fan Assembly Installation

    2.3.2 CPU heatsink and fan assembly installation CAUTION! Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 17 • We recommend using a LGA1700 compatible cooling system on an Intel 600 series ® motherboard. • Push-pin type LGA1200 compatible cooling systems cannot be installed to this motherboard. LGA1700 To uninstall the CPU heatsink and fan assembly H610I-IM-A...

  • Page 18: System Memory

    System memory This motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) sockets. The figure below illustrates the location of the DDR4 DIMM sockets: Channel Sockets Channel A DIMM_A1 Channel B DIMM_B1 IMPORTANT! • You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration.

  • Page 19: Recommended Memory Configuration

    Recommended memory configuration DIMM_A1* DIMM_B1* DIMM_A1* DIMM_B1* Installing a DIMM To remove a DIMM H610I-IM-A 2-10...

  • Page 20: Jumpers

    Jumpers Clear RTC RAM (2-pin CLRTC) This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. CLRTC PIN 1 Connector type HEADER 1x2p, 2.54mm pitch, S/T To erase the RTC RAM: Turn OFF the computer and unplug the power cord.
  • Page 21 COM Ring/+5V/+12V selection jumper (6-pin COM1/2_SEL) COM2_SEL COM1_SEL +12V (Default) Setting Pins +12V Ring (Default) AT/ATX mode selection jumper (3-pin AT_ATX_SEL) AT_ATX_SEL ATX mode AT mode (Default) Pins 1-2 (Default) ATX mode AT mode Connector type HEADER 1x3p, 2.54mm pitch, S/T H610I-IM-A 2-12...
  • Page 22 LVDS Panel Backlight Enable Signal Selection jumper (BKLTEN_SEL) BKLTEN_SEL High Active Low Active (Default) BKLTEN_SEL Pins HIGH active LOW active Connector type HEADER 1x3p, 2.54mm pitch, S/T LVDS Panel VCC Power Selection jumper (6-pin VCC_PWR_SEL) VCC_PWR_SEL (Default) Setting Pins 3V (Default) Connector type HEADER 1 x 3p, 2.54mm pitch, S/T Chapter 2: Motherboard information...

  • Page 23: Connectors

    Connectors 2.6.1 Rear panel connectors COM ports (COM, RS232/RS422/RS485). These ports connect modems, or other devices that conform with serial specification. DisplayPort. This port is for a DisplayPort-compatible device. LAN (RJ-45) ports. These ports allow Gigabit connection to a Local Area Network (LAN) through a network hub.
  • Page 24 Audio 2, 4, 5.1 or 7.1-channel configuration Headset Port 4-channel 5.1-channel 7.1-channel 2-channel Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center Lime (Front panel) Side Speaker Out To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output.

  • Page 25: Internal Connectors

    2.6.2 Internal connectors ATX Power connectors (24-pin ATXPWR, 2 x 4-pin EATX12V) Correctly orient the ATX power supply plugs into these connectors and push down firmly until the connectors completely fit. EATX12V EATXPWR +3 Volts +12 Volts +5 Volts +12 Volts +5 Volts PIN 1 +5V Standby...
  • Page 26 CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN) Connect the fan cables to the fan headers on the motherboard, ensuring that the black wire of each cable matches the ground pin of the header. CPU_FAN CHA_FAN CHA FAN PWM CHA FAN IN PIN 1 CHA FAN PWR...
  • Page 27 USB 2.0 headers (10-1 pin USB56, USB78) These headers are for USB 2.0 ports. Connect a USB cable to the header. The USB headers comply with USB 2.0 specification that supports up to 480 Mbps connection speed. USB_78 PIN 10 USB_P7+ USB_P8+ USB_P7-...
  • Page 28 M.2 slot (SOCKET 3) This slot allows you to install an M.2 SSD module. M.2(SOCKET3) Connector type NGFF KEY-M 67P, 8.5H NOTES: • The M.2 SSD module is purchased separately. • This slot support M Key and 2242/2260/2280 storage devices. •...
  • Page 29 System Panel header (10-1 pin F_PANEL) This header supports several chassis-mounted functions. +PWR_LED- PWR_BTN PIN 2 F_PANEL PIN 1 PIN 9 +HDD_LED- RESET Connector type HEADER 2x5p, K10, 2.54mm pitch • System power LED (2-pin +PWR_LED) This 2-pin header is for the system power LED. Connect the chassis power LED cable to this header.
  • Page 30 Speaker header (4-pin SPEAKER) The 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. SPEAKER PIN 1 Connector type HEADER 1x4p, 2.54mm pitch, S/T Chassis Intrusion header (4-1 pin_CHASSIS) This header is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector.
  • Page 31 10. SATA 6.0Gb/s ports (7-pin SATA6G_1-4) These ports connect to SATA 6.0 Gb/s hard disk drives or an optical drive via SATA 6.0 Gb/s signal cables. SATA6G_3 SATA6G_2 SATA6G_1 RSATA_RXP RSATA_RXN RSATA_TXN RSATA_TXP Connector type SATA CON 7P S/T 11. General Purpose Input/Output header (GPIO_CON) This header is for a general purpose input/output module which allows you to customize the digital signal input/output.
  • Page 32 12. COM Port headers (10-pin COM3 - COM6) These headers are for serial (COM) ports. Connect the serial port cables to these headers, then install the module to a slot opening at the back of the system chassis. COM3 COM4 A B C COM5 COM6...
  • Page 33 14. Front Panel Audio header (10-1 pin AAFP) This header is for a chassis-mounted front panel audio I/O module that supports HD Audio standard. Connect one end of the front panel audio I/O module cable to this header. PIN 2 PIN 10 AAFP PIN 1...
  • Page 34 15. COM Debug header (5-1 pin COM_DEBUG) This header allows connection to a COM Debug card. COM_DEBUG PIN 6 PIN 5 PIN 2 PIN 1 Connector type HEADER 2x3p, K3, 2.54 mm pitch, S/T NOTE: The COM Debug Card is purchased separately. 16.
  • Page 35 17. LVDS Backlight Panel header (5-pin LCD_BLKT_PANEL) This header is for the LCD panel brightness controls. LCD_BLKT_PANEL LVDS Signal eDP Signal PIN1 PIN1 Connector type WAFER 6p, 2.0mm pitch 18. LVDS/EDP header (40-pin LVDS_EDP) This header is for an internal LVDS or embedded DisplayPort connection. LVDS_EDP LVDS Signal EDP Signal...
  • Page 36 19. PCIe 4.0 x16 slot (PCIEX16(G4)) This slot supports a PCIe 4.0 x16 graphics card that complies with the PCI Express specification. PCIEX16(G4) Chapter 2: Motherboard information 2-27...

  • Page 37: Chapter 3 Bios Setup

    Chapter 3 BIOS setup Chapter 3 BIOS setup Scan the QR code to view the BIOS update guide. BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program.

  • Page 38: Bios Menu Screen

    3.1.1 BIOS menu screen Menu bar The menu bar on top of the screen has the following main items: Main For changing the basic system configuration Advanced For changing the advanced system settings Hardware For displaying the system temperature and changing the Monitor fan settings Security...

  • Page 39: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.3.1 LVDS Configuration The items in this menu show the LVDS-related information that the BIOS automatically detects.

  • Page 40: Pch-Fw Configuration

    Mode Select Allows you to select the mode. Configuration options: [JEIDA] [VESA 6bit] [VESA 8bit] [VESA 10bit] 3.3.2 PCH-FW Configuration TPM Device Selection This item allows you to select the TPM device. Configuration options: [dTPM] [PTT] 3.3.3 Trusted Computing Security Device Support This item allows you to enable or disable BIOS support for security devices.

  • Page 41: Graphics Configuration

    Intel(R) SpeedStep(tm) This item allows your system to support more than two frequency ranges. Configuration options: [Disabled] [Enabled] Intel(R) Speed Shift Technology This item allows you to enable or disable Intel(R) Speed Shift Technology support. When enabled, CPPC v2 interface allows hardware controlled P-state.

  • Page 42: Power Management

    RC6 (Render Standby) Allows you to enable or disable render standby support. Configuration options: [Disabled] [Enabled] 3.3.6 Power Management Enable ACPI Auto Configuration Allow you to enable/disable the ACPI Auto configuration. Configuration options: [Disabled] [Enabled] Enable Hibernation Allow you to enable or disable S4 hibernation. Configuration options: [Disabled] [Enabled] ACPI Sleep State Allow you to select the ACPI sleep state.

  • Page 43: Super Io Configuration

    3.3.8 Super IO Configuration NCT6126D Super IO Configuration Serial Port 1 Configuration Serial Port Allows you to enable or disable the serial port (COM).Configuration options: [Disabled] [Enabled] The following items appear only when you set Serial Port to [Enabled]. COM1 Control Allows you to select the COM1 mode. Configuration options: [RS232] [RS422] [RS485] Serial Port 2 Configuration Serial Port...

  • Page 44: Serial Console Redirection

    3.3.9 Serial Console Redirection COM1~COM6 Console Redirection Configuration options: Allows you enable or disable the console redirection feature. [Enabled] [Disabled] Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings.

  • Page 45: Sata Configuration

    data flow. Once the buffers are empty, a “start” signal can be sent to re-start the flow. Hardware flow control uses two wires to send start/stop signals. Configuration options: [None] [Hardware RTS/CTS] VT-UTF8 Combo Key Support Allows you to enable or disable VT-UTF8 Combination Key Support for ANSI/ VT100 terminals.

  • Page 46: Network Stack Configuration

    3.3.11 Network Stack Configuration Network Stack This item allows user to disable or enable the UEFI network stack. Configuration options: [Disabled] [Enabled] The following two items appear only when you set the previous item to [Enabled]. Ipv4 PXE Support This item allows user to disable or enable the Ipv4 PXE Boot support. Configuration options: [Disabled] [Enabled] Ipv6 PXE Support This item allows user to disable or enable the Ipv6 PXE Boot support.

  • Page 47: Apm Configuration

    LAN2 I210 [Enabled] Enables the Intel LAN2 controller. [Disabled] Disables the controller. M.2 WiFi Allow you to enable or disable M.2 WiFi function. Configuration options: [Enabled] [Disabled] M.2 BT Allow you to enable or disable M.2 BT function. Configuration options: [Enabled] [Disabled] 3.3.15 APM Configuration...

  • Page 48: Ez-Flash

    3.3.16 EZ-Flash Enter Ez-Flash mode This item allows you to run EzFlash utility. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. 3.3.17 IO Expander Configuration IO Expander GPIO 0(~7) Direction...

  • Page 49: Security Menu

    Smart Fan Function System Fan Setting Chassis Fan Temperature 1(~4) Allows you to set the value of temperature1(~4). Chassis Fan FD/RPM 1(~4) Allows you to set the value of Fan Duty/PRM 1(~4) when temperature is T1(~4). CPU Fan Setting CPU Fan Temperature 1(~4) Allows you to set the value of temperature1(~4).

  • Page 50: Boot Menu

    To set a user password: Select the User Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change a user password: Select the User Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>.

  • Page 51: Exit Menu

    Boot up NumLock State [On] Set the power-on state of the NumLock to [On]. [Off] Set the power-on state of the NumLock to [Off]. Quiet Boot Allows you to enable or disable the Quiet Boot option. Configuration options: [Disabled] [Enabled] Fast Boot [Enabled] Select to accelerate the boot speed.

  • Page 52: Restore Defaults

    Restore Defaults Restore/load default values for all the setup options. Save as User Defaults This option allows you to save the changes you have made so far as user defaults. Restore User Defaults Restore the user defaults with all the setup options. H610I-IM-A 3-16...

  • Page 53: Appendix

    Appendix Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 54 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 55: Asus Recycling/Takeback Services

    REACH Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling.
  • Page 56 Română ASUSTeK Computer Inc. declară că acest dispozitiv se conformează English ASUSTeK Computer Inc. hereby declares that this device is in cerinţelor esenţiale şi altor prevederi relevante ale directivelor conexe. Textul compliance with the essential requirements and other relevant provisions of complet al declaraţiei de conformitate a Uniunii Europene se găseşte la: related Directives.

  • Page 57: Service And Support

    Service and Support Visit our multi-language website at https://www.asus.com/support/ Appendix...
  • Page 58 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Augsburger Str. 2b 82110 Germering Phone: +49 89 894450-0 E-Mail: info@fortecag.de Internet: www.fortecag.de Fortec Group Members Austria FORTEC Integrated GmbH Office Vienna...
