OPERATION AND MAINTENANCE MANUAL
FLUSH MOUNTED CLOCK ZA5
Product code:
301-17-CX
Distributed by: Innovation Wireless Ltd - 08000 248 091 - info@innovation-
wireless.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZA5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RGB Technology ZA5

  • Page 1 OPERATION AND MAINTENANCE MANUAL FLUSH MOUNTED CLOCK ZA5 Product code: 301-17-CX Distributed by: Innovation Wireless Ltd - 08000 248 091 - info@innovation- wireless.co.uk...
  • Page 2: Table Of Contents

    Manufacturer ............................3 Specifications ............................3 Transport and storage ........................... 3 Device construction ..........................3 List of cables .............................. 3 ZA5 clocks construction ..........................4 ZA5 device dimensions ..........................4 Device installation ..........................5 ZA5 application ............................5 ZA5 configuration ............................5 5.2.1...
  • Page 3: Manufacturer

    Device construction ZA5 in the flush-mounted variant has a housing made of stainless steel. The LED module is protected from the front with a glued glass, thanks to which - after proper installation - the device is characterized by IP 66 protection level.
  • Page 4: Za5 Clocks Construction

    ZA5 clocks construction The figure shows the ZA5 device construction Fig. 1 – LAN connector (only for variants with LAN option); – place where the cables are led out; – device front; – glass det. A det. B det. C det.
  • Page 5: Device Installation

    It is forbidden to make any additional mounting points or any holes in the device assembly components. ZA5 application The ZA5 device is designed to display time, date and optionally temperature. In addition, the clock allows you to change the operating mode to a stopwatch, timer or count-up-and-down mode. Correct configuration is necessary for the device to function properly.
  • Page 6: Device Configuration Through The Built-In Website - Web Panel

    The structure of the main menu is as follows: Menu Function description position Manual settings of the time and date Configuration of the presented parameters Configuration of the date and time format Configuration of the time synchronization and the Master Mode Configuration of the display brightness Configuration of the alarms Configuration of the ECO mode...
  • Page 7: Control Module

    Control module The control module (Fig. 4) enables the operation of peripheral devices and, thanks to the supercapacitor, ensures correct time counting in the absence of external power supply. – relay connector; – GPS connector; – temperature probe connector; – PoE output; –...
  • Page 8: Device Accuracy

    Thanks to this solution, all clocks indicate the same time and type of information, e.g. they display the temperature at the same time. Different models of clocks produced by RGB Technology can cooperate with each other. Fig. 5 10.3 GPS module...
  • Page 9: Temperature Probe

    Fig. 6 10.4 Temperature probe Optionally, the device can be equipped with a temperature probe (Fig. 7), which allows you to measure and display the temperature in degrees Celsius or Fahrenheit. The following signal cable length variants are available: 0.5m, 2m, 5m, 15m and 50m.
  • Page 10: Wireless Ir Remote Control

    The remote control is connected to the device with a 4x0.25mm cable, 5.2m long, terminated with a 4-pin plug. The colors of the remote control cable cores and its connection to the clock control module are shown in the table below: Table 1 Description of the flush-mounted...
