WE-EF XLO229 LED Installation And Maintenance Instructions Manual

Wall luminaires surface mounted

Download this manual

WE-EF LEUCHTEN

Installation and Maintenance

Instructions

Wall Luminaires Surface Mounted

XLO229 LED

Surge Protection

This product features built-in surge protection circuitry in compliance

with applicable standards.

For comprehensive protection of a luminaire installation against lightning

and electrical surges, it is essential to cover mains supply and data input

lines at the distribution board level, by using respective primary (Type 1)

and secondary (Type 2) surge arrestors in compliance with EN61643-11/

IEC61643-1.

Warning

Ensure that all required surge protection measures are in place and

activated prior to luminaire installation. Also, disconnect luminaires

before operating high-power devices such as, for example, electrical

arc welders.

Need help?

Do you have a question about the XLO229 LED and is the answer not in the manual?

Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Wall Luminaires Surface Mounted XLO229 LED Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards. For comprehensive protection of a luminaire installation against lightning and electrical surges, it is essential to cover mains supply and data input...
Page 2 Wall Luminaire Surface Mounted XLO229 ø 300...
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried Warning: Do not open luminaire while mains supply is switched on.
Page 4: Installation Procedure
Installation Installation Procedure The product must be installed and maintained 2) Remove cover A from luminaire body B by turn it with latest building/construction and/or electrical counter clockwise. regulations and relevant legislation. 3) Check that rating shown on luminaire label conforms with mains electrical supply.
Page 5 Individual connection Through wiring Fig. I...
