Durofix provides you with products at an affordable price, and we would like you to be
fully satisfied with this product and our technical support. If any help or advice is
needed, please kindly contact us.
This tool is intended for trained adult use only.
This oil pulse tool is designed to remove and install threaded fasteners.
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
The safety instructions provided in this manual are not intended to cover all possible
conditions and practices that may occur when operating, maintaining and cleaning
power tools.
Always use common sense and pay particular attention to all the DANGER,
WARNING, CAUTION and NOTE statements of this manual.
DANGER
WARNING
CAUTION
NOTE
1English1
THANKS FOR CHOOSING THIS PRODUCT
INTENDED USE
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTE provides additional information that is useful for proper
use and maintenance of this tool. If a NOTE is indicated make
sure it is fully understood.
English
-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RZ2013-D-WR30 and is the answer not in the manual?

Questions and answers

Summary of Contents for DUROFIX RZ2013-D-WR30

  • Page 1 1English1 THANKS FOR CHOOSING THIS PRODUCT Durofix provides you with products at an affordable price, and we would like you to be fully satisfied with this product and our technical support. If any help or advice is needed, please kindly contact us.
  • Page 2: Warning Label Identification

    1English1 WARNING LABEL IDENTIFICATION Read Manuals Before Operating Product. Wear Eye Protection. Wear Hearing Protection. Wear Dust Mask. Power tools can vibrate in use. Keep body stance balanced and firm. Do not overreach when operating this tool. Recycling Do not drop the battery and charger into trashcan. IMPORTANT SAFETY RULES DANGER When using power tools, always prevent exposure and breathing of harmful dust and particles.
  • Page 3: General Safety Rules

    1English1 GENERAL SAFETY RULES Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
  • Page 4: Personal Safety

    1English1 PERSONAL SAFETY WARNING Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. Use personal protective equipment.
  • Page 5 1English1 Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations. Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control.
  • Page 6: Specific Safety Rules And Symbols

    1English1 SPECIFIC SAFETY RULES AND SYMBOLS CAUTION Hold the power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring or its own cord. Fasteners contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock. Be aware that this tool is always in an operating condition, because it does not have to be plugged into an electrical outlet.
  • Page 7: Functional Description

    1English1 FUNCTIONAL DESCRIPTION 1. 3/8” Anvil Aluminium Gearbox Housing 3. Built-in LED light Forward / Reverse Lever 5. Trigger LED Lamp Shut off (green)/ Error (red) 7. Power indicator Battery Pack Release Button 9. Battery Pack 10. Hook English...
  • Page 8: Specifications

    1English1 SPECIFICATIONS Model Number Unit RZ2013- RZ2013-3- RZ2013-3- D-WR30 WR40 WR50 V d.c. Voltage Anvil / Drive 3/8” 3/8” ft-lbs 7.4~22.1 11.1~29.5 22.1~36.9 Max. Tightening Torque 10~30 15~40 30~50 1,500-6.000 No Load Speed Capacity (Nominal bolt size) M8-M12 3.62 3.57 3.83 Tool Weight (with battery 2.0Ah)
  • Page 9 1English1 CAUTION Always set switch (5) to off position when installing and removing socket. When the lithium battery pack cannot generate enough power for tasks that were previously easy to perform, it means the lithium battery pack should be charged. In this case, do not continue to use it and follow the charging instructions.
  • Page 10 1English1 ASSEMBLY INSTALLING OR REMOVING BATTERY PACK TO REMOVE BATTERY PACK: Depress the battery pack release button and pull the battery pack out of tool. TO INSTALL BATTERY PACK: Push the battery pack onto tool until it locks in place. INSTALLING SOCKETS Always follow the procedure below to install a socket.
  • Page 11: Operation

    1English1 OPERATION NOTE Always check the direction of the rotation before use. Adjust the torque appropriately according to the size of the bolt to be tightened. When tightening smaller bolt, reduce the torque or use a tool with a lower torque setting to prevent the bolt from breaking or stripping.
  • Page 12 1English1 ELECTRONIC CONTROL SWITCH (EC SWITCH) The EC switch provides safety feature to the user for socket and bolt entry and tentative fastening. Half press the trigger; the driver will run in slow speed for socket and bolt entry firstly. Full press the trigger, the driver will change to fast speed for regular fastening.
  • Page 13 1English1 FORWARD / REVERSE LEVER A forward/reverse lever determines the direction of the tool. To select forward rotation, RELEASE THE EC SWITCH (Fig.2), and push the forward/reverse lever (Fig.2), toward left side of the tool. To select reverse, push the forward/reverse lever, toward right side of the tool.
  • Page 14 1English1 TORQUE ADJUSTMENT IN FORWARD ROTATION (CW) ONLY Release the trigger, then push the forward/reverse leaver to centre. Use an Allen key (4.0mm) to release the nut counter-clockwise. (FIG.3) FIG. 3 Adjust the relief valve with Allen key (2.0mm) as the following FIG.4 to increase the oil pressure or decrease the oil pressure.
  • Page 15 1English1 Use a torque wrench to measure the actual torque output of the tool. Based on the measured torque value, repeat Step 1 to select the loosening or tightening torque. FIG. 5 Finally use an Allen key (4.0mm) to tighten the nut clockwise. (FIG.6) FIG.
  • Page 16 1English1 NOTE Please use the provided hex wrench to disassemble and adjust. The oil filling screw and relief valve are different to prevent accidental loosening. Do not loosen the oil filling screw. This screw is for maintenance purposes only. Loosening it may cause oil leakage and damage the tool.
  • Page 17 1English1 TROUBLESHOOTING Check the following before you ask for repair Situation LED Indicator Troubleshooting Tools Gets Hot RED Steady Rest the Tool to Room Green Blinking Temperature Battery Pack Temperature is RED Blinking Rest the Battery Pack to Too High Room Temperature or Change Battery Pack.
  • Page 18 1English1 CONNECTIVITY Wireless Data Communication The Device stores up to 1000 joints fastening data internally. To retrieve joint rundown data, connect Device to DR001 / DR002 / DONGLE to see real time data or download stored data. Connect to RD002 / Dongle/ DR001 Long press the switch for 3 seconds to switch functions.
  • Page 19 1English1 Connecting port 鎖緊鈕 Clip Port definition 1: 24V 2: Fasten OK 導線孔 3: Tool protection Wire connect hole 4: Fasten NG 8: 0V I/O receiver specification Input voltage + 24VDC ± 20% Maximum input current 40mA (input voltage 24VDC) Communication system Bluetooth 4.2 Frequency band...
  • Page 20 1English1 LED light signal Power : Blue Communication : Green (OK), Red (Tool Protection) Tightening : Green(OK), Red(Not OK) ID setting port Com. Power Tightening Power switch Connecting port 24VDC jack Wire terminal block NOTE Device and IO Receiver is 1-to-1 pairing ONLY. Check Group/Device ID setting on Device &...
  • Page 21: Maintenance

    1English1 MAINTENANCE WARNING Remove the battery pack from this tool before cleaning solutions. DANGER A battery pulse tool is a precision tool. Disassembly, assembly, adjustment require exclusive JIGS plus testers, and trained techniques. Incorrect disassembly, reassembly or adjustment can cause not only insufficient power but also accidents. Ask for these services from an authorized service centre.
  • Page 22: Protecting The Environment

    1English1 ACCESSORIES Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may become hazardous when used on another tool. Recommended accessories for use with your tool are available at extra cost from your local service centre.

This manual is also suitable for:

Rz2013-3-wr40Rz2013-3-wr50
