- Page 1 ELIPSE SERIES USER MANUAL ON LINE UPS EL-6K(S)/EL-10K(S)/EL-15KS/EL-20KS Uninterruptible Power Supply 614-06377-00...
- Page 2 Please comply with all warnings and operating instructions in this manual and on the unit strictly. Save this manual properly. Do not operate this unit before reading through all safety information and operating instructions carefully.
-
Page 3: Table Of Contents
Brief introduction 1.1 System and model description ------------------------------------------------------------------- 1 1.2 Description of commonly used symbols ------------------------------------------------------- 2 1.3 Appearance ------------------------------------------------------------------------------------------- 3 1.4 Product specification and performance -------------------------------------------------------- 4 General specification Electric performance Operating environment Installation 2.1 Unpacking & Inspection ---------------------------------------------------------------------------- 6 2.2 Input and output power cords and protective earth installation --------------------------- 6 2.3 Operating procedure for connecting the long backup time model UPS with the external battery ------------------------------------------------------------------------------------- 11... -
Page 4: Brief Introduction
Brief introduction 1.1 System and model description This Online Series is an uninterruptible power supply incorporating double-conversion technology. It provides perfect protection specifically for computer equipment, Communication Systems to computerized instruments. Its true online double-conversion design eliminates all mains power disturbances. A rectifier converts the alternating current from the utility power to direct current. -
Page 5: Description Of Commonly Used Symbols
1.2 Description of commonly used symbols The following symbols will be used in this manual and may appear during the course of your practical applications. Therefore, all users should be familiar with them and understand their meanings. Recyclable Do not dispose with ordinary trash... -
Page 6: Appearance
1.3 Appearance Rs232 Rs232 Intelligent Intelligent slot slot Parallel port Parallel port External battery External battery Input breaker Input breaker Maintenance Maintenance Rj45 Rj45 Switch Switch TB cover TB cover Terminal blocks Terminal blocks BACK VIEW of 6K(S) BACK VIEW of 10K(S) Rs232 Intelligent slot... -
Page 7: Product Specification And Performance
1.4 Product specification and performance General specification Input acceptable Voltage Battery Frequ range ency Input Power rating Model Voltage (Hz) Voltage Current Voltage (176-276)VA 6kVA/4.2kW 220VAC 31A max. 240VDC (176-276)VA 6kVA/4.2kW 220VAC 31A max. 240VDC (176-276)VA 10kVA/7kW 220VAC 50A max. 240VDC (176-276)VA 10kVA/7kW... -
Page 8: Electric Performance
Electrical performance Input Model Voltage Frequency Power Factor 6K(S)/10K(S) Single-phase 56Hz-64Hz >0.98 (Full load) Three-phase Three-phase 56Hz-64Hz >0.95 (full load) 10KS/15KS/ 20KS Output Voltage Power Current Frequency tolerance Distortion Overload capacity regulation factor crest ratio 105% 130% load ¢ Synchronized 56~64Hz transfers to bypass THD<4% mode after 10... -
Page 9: Unpacking & Inspection
2.1 Unpacking and inspection Unpack the packaging and check the package contents. The shipping package contains: A UPS A User Manual A Communication Cable A Battery Cable (for 6KS/10KS only) Inspect the appearance of the UPS to see if there is any damage during transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any damage or lacking of some parts. - Page 10 Open the terminal block cover located on the rear panel of the UPS, please refer to the appearance diagram) For 6K(S) UPS, it is recommended to select the UL1015 10AWG(6mm ) wire or other insulated wire which complies with AWG Standard for the UPS input and output wirings.
- Page 11 To connect the load with the UPS, please turn off all the loads first, then perform the connection and finally turn on the loads one by one. No matter the UPS is connected to the utility power or not, the output of the UPS may have electricity. The parts inside the unit may still have hazardous voltage after turning off the UPS.
- Page 12 In pu t G ro un d O u tpu t Gro un d In pu t N eu tral Ou tpu t Ne utr al 2 In pu t L in e W i re A Ou tpu t Lin e 2 In pu t L in e W i re B Ou tpu t Ne utral 1 In pu t L in e W i re C...
- Page 13 ou tp ut Ne utr a l ou tp ut Li ne JP 1 To In pu t L in e To In pu t N eu tr al Connection Details of Output Terminals Important Note: If the UPS is used in Single Mode, JP1 and JP2 must be connected by 10AWG (6mm ).
-
Page 14: Operating Procedure For Connecting The Long Backup Time Model Ups With The External Battery
Connect Output Line 1 and Output Neutral 1 for 120V / 3KVA Load or connect by 10AWG (6mm ). Output Line 2 and Output Neutral 2 for 120V / 3KVA Load. Important Note: If the UPS is used in Single Mode, JP1 and JP2 must be connected by 10AWG (6mm ). - Page 15 Set the battery pack breaker in "OFF” position and connect the 20 pieces of batteries in series. You must connect the external battery cable to the battery first, if you connect the cable to the UPS first, you may encounter the hazardous of electric shock. The positive pole of the battery is connected to the 10KS/3 phase 10KS in parallel with blue and brown wires;...
-
Page 16: Parallel Operation
2.4 Parallel operation Brief introduction of the redundancy N+X is currently the most reliable power supply structure. N represents the minimum UPS number that the total load needs; X represents the redundant UPS number, i.e. the fault UPS number that the system can handle simultaneously. The bigger the X is, the higher reliability of the power system is. - Page 17 To perform the general operation, follow the stand-alone operating requirement; Startup: The units transfer to INV mode simultaneously as they start up sequentially in utility power mode; Shutdown: the units shut down sequentially in INV mode. When the last one completes the shutdown action, each unit will shut down the inverter simultaneously and transfer to bypass mode.
-
Page 18: Operation And Operating Mode
3. Operation and operating mode 3.1 Operation 1. Turn on the UPS with utility power supplied (in Line mode/AC mode) After you make sure that the power supply connection is correct, set the bypass breaker and the input breaker in the “ON” position first. At this time the fan rotates and the UPS supplies power to the load via the bypass. - Page 19 2) When being powered off, the UPS will perform self-diagnosis, the Load/Battery level LEDs will be turned on and then off one after another in ascending order, then the INV LED will be turned off and Bypass LED will be turned on. The UPS is working in Bypass mode.
-
Page 20: Operating Mode
3.2 Operating mode 1. Utility power mode The display panel in utility power mode is shown in the following diagram. The utility power LED and the INV LED are turned on. The load level LEDs will be turn on in accordance with the load capacity connected. - Page 21 2. Battery mode The display panel in battery mode is shown in the following diagram Fig.3-2. The battery LED and the INV LED are turned on. The displayed number of the battery level LEDs will be turned on in accordance with the battery capacity. Note that the load level LEDs in utility power mode will indicate the level of the battery capacity in battery mode.
- Page 22 The utility power LED flashes, it shows that the voltage or frequency of the utility power has exceeded the normal range of the UPS. Fig 3-3 UPS bypass mode diagram 2) Other indications on the display panel are the same in utility mode. 3) The UPS does not have the backup function when it is in bypass mode.
- Page 23 Load level Load level backup time of 6kVA backup time of 10kVA 6. Communication Port Intelligent slot This series is equipped with an intelligent slot for Webpower (optional accessory) or other optional card to achieve remote management of the UPS through internet / intranet.
- Page 24 RS232 interface 1) The following are the descriptions and pin assignment of RS232 DB-9 port: Baud rate: 2400bps Data bit: 8 bit Ending bit: 1bit Parity bit: None DB-9 pin assignment: Pin number Function description input output Ground RS232 Interface Optional AS400 interface This optional AS400 card provides dry contact closure signal “OPEN”...
-
Page 25: Battery Maintenance
4. Battery maintenance This series UPS only requires minimal maintenance. The battery used for --22-- standard models are value regulated sealed lead-acid maintenance free battery. These models require minimal repairs. The only requirement is to charge the UPS regularly in order to maximize the expected life of the battery. When being connected to the utility power, whether the UPS is turned on or not, the UPS keeps charging the batteries and also offers the protective function of overcharging and over-discharging. -
Page 26: Notes For Battery Disposal And Battery Replacement
5. Notes for battery disposal and battery replacement 1) Before disposing of batteries, remove conductive jewelry such as necklace, wrist watches and rings. 2) If it is necessary to replace any connection cables, please purchase the original materials from the authorized distributors or service centers, so as to avoid overheat or spark resulting in fire due to insufficient capacity. -
Page 27: Trouble Shooting
6. Trouble shooting Problem Possible cause Solution The #1 Fault LED and the #6 The UPS shutdown Make sure the UPS is not overloaded; the air LED are turned on, the due to internal vents are not blocked and the ambient buzzer beeps continuously overheat temperature is not too high. -
Page 28: Appendix 1 Display Panel
Appendix 1 Display panel When you contact the service center, please provide the following information: ¨ ¨ Model No. and the serial No. of the UPS; The date when the problem arose; ¨ Complete description of the problem, including the LED display, alarm warning, and power condition and load capacity. -
Page 29: Appendix 2 The Corresponding Form Of The Led Display
Appendix 2 The corresponding form of the LED display LED display Alarm Operating state warning 0~35% none © © © Load capacity 36%~55% none © © © © Load capacity Utility 56%~75% none Power © © © © © Load capacity Mode 76%~95% none... - Page 30 Utility power abnormal © Overloaded in battery Beep twice mode, every sec. © © © © Early-warning Overloaded in battery Continuously mode, beep © © Cut off the output Continuously Over temperature © © beep Continuously Inv abnormal © © beep Continuously Output short circuited...
