VAC-Pump
Part
305.5200
Vacuum-Pump, electric, 19 gallon tank,
with dolly cart and HEPA filtration.
NOTE: Designed for liquid pickup only. Not to be picked up are a) dry, damp or hazardous
dust and, b) flammable, explosive, or corrosive liquids.
23031 Arroyo Vista ● Rancho Santa Margarita, CA 92688
949.858.7400 ● 949.858.9141 fax ● 800.337.2648 toll free
www.descomfg.com ● info@descomfg.com
Vacuum, Electric, 19 Gallon, Vac-Pump, (305.5200), Aug2022, Manual.PDF
August 2022
Vacuum with Integrated Pump
Vacuum/Pump Configuration
Description
DESCO Mfg. Co., Inc.
with HEPA Filtration
Accessories Furnished
Pickup hose (13'), discharge hose
(50'), curved wand, extension
tubes and floor nozzle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 305.5200 and is the answer not in the manual?

Questions and answers

Related Manuals for Desco 305.5200

Summary of Contents for Desco 305.5200

  • Page 1 DESCO Mfg. Co., Inc. 23031 Arroyo Vista ● Rancho Santa Margarita, CA 92688 949.858.7400 ● 949.858.9141 fax ● 800.337.2648 toll free www.descomfg.com ● info@descomfg.com Vacuum, Electric, 19 Gallon, Vac-Pump, (305.5200), Aug2022, Manual.PDF August 2022...

  • Page 2: Table Of Contents

    Contents 1.0 DESCRIPTION ..........................1 1.1 P ........................... 1 URPOSE 1.2 O ....................... 1 PERATING LEMENTS 1.3 A ......................2 CCESSORIES URNISHED 1.4 C & A ....................2 ONSUMABLES CCESSORIES 1.5 T ....................... 2 ECHNICAL PECIFICATIONS 2.0 SAFETY ............................3 2.1 R ....................

  • Page 3: Description

    DESCO Innovative Solutions 1.0 Description Purpose The VAC-PUMP is a vacuum with integrated pump designed for liquid water pickup only. Not to be picked up are a) dry, damp or hazardous dust, b) heavy sediment, sludge, mud or, b) flammable, explosive, or corrosive liquids...

  • Page 4: Accessories Furnished

    DESCO Innovative Solutions Accessories Furnished Desc Desc Squeegee blades Curved wand Floor tool Pickup hose Extension tubes Discharge hose Consumables & Accessories Part Description 305.1095 HEPA Filter 305.15365 Hose, pickup, 13’ (ribbed) 305.7567 Hose, discharge, 50’ 305.15352 Replacement squeegee blades for floor tool (2/set)

  • Page 5: Safety

    DESCO Innovative Solutions 2.0 Safety PLEASE READ AND FOLLOW ALL WARNINGS Read Operating Instructions Always become familiar with all the instructions and warnings before operating any machine or power tool. Hazardous Material and Safety Safety is your primary concern when working with or near hazardous material (HAZMAT).
  • Page 6 DESCO Innovative Solutions  Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center.  Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.

  • Page 7: Pre-Operation

    DESCO Innovative Solutions 3.0 Pre-Operation Assemble the Machine (first time use only)  Un pack – Remove machine from shipping box and remove packing material.  Remove accessories – Look inside tank for additional accessories and packing material. Remove accessories and discard packing material.

  • Page 8: Grounding Instructions

    DESCO Innovative Solutions Grounding Instructions This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug.

  • Page 9: Operating Instructions

    DESCO Innovative Solutions 4.0 Operating Instructions 4.1 Connections 4.1.1 Connect Input Suction Hose  Insert the suction hose into the suction port on front of tank. 4.1.2 Connect Output Discharge Hose  Locate discharge hose (A).  Locate discharge port (B) on back of tank.

  • Page 10: Connect Sump Pump Power

    DESCO Innovative Solutions 4.1.3 Connect Sump Pump Power  Locate pump power plug at end of cord exiting rear of tank.  Locate pump power receptacle on control panel. Remove cover.  Insert power plug into power receptacle as shown.

  • Page 11: Function Switch

    DESCO Innovative Solutions Function Switch Machine operation is controlled with the function selection switch. The automatic mode (B) is recommended for most situations. Symbol Description Pump Only Mode – No suction. Only the sump pump runs.  A touch position (resets automatically). If it is pressed once, the submerged pump works for 30 seconds.

  • Page 12: Applications And Techniques

    DESCO Innovative Solutions 5.0 Applications and Techniques Effective water removal is achieved by following a few guidelines in combination with your own practical experience in special fields. Here are some basic tips:  Always read, understand and follow all safety and use instructions before using this device.

  • Page 13: Maintenance, Cleaning And Storage

    DESCO Innovative Solutions 6.0 Maintenance, Cleaning and Storage Service Access Dis-assembly The unit breaks down into the following four (4) major components for service, cleaning and maintenance. 6.1.1 Remove Power Head – Release latches on both sides. Lift power head from vacuum body.
  • Page 14 DESCO Innovative Solutions 6.1.3 Remove Tank from Cart – With power head and intake suction port removed: 1) Release tank base latch (A), 2) Release tank pivot lock (B) on both sides and, 3) Lift tank from dolly cart using handles (C).

  • Page 15: Cleaning

    DESCO Innovative Solutions 6.2 Cleaning Periodic cleaning is required to keep the device in good working order.  Clean before storing – always clean before placing into storage. Note: Before storing, cleaned components should be set aside to air dry completely before reassembling.

  • Page 16: Hepa Filter Inspection And Replacement

    DESCO Innovative Solutions HEPA Filter Inspection and Replacement  Remove power head from vacuum body.  Place power head upside down on table or suitable work surface. 6.3.1 Remove filter retainer (1) – A) turn filter retainer counterclockwise to unlock and, B) lift to remove filter retainer.

  • Page 17: Floor Tool Blade Replacement

    DESCO Innovative Solutions Floor Tool Blade Replacement  Place floor tool (A) upside down on table or suitable work surface.  Adjust height to maximum using adjusting knob (B).  Remove end cap (C) by removing Phillips head screw (D).

  • Page 18: Troubleshooting

    DESCO Innovative Solutions 7.0 Troubleshooting Malfunction Probable Cause Solution Motor does not start No power – Main power Check main power breaker and breaker or fuse blown reset as required. GFCI tripped – Ground Fault Reset GFCI by pressing top button Circuit Interrupter tripped.
