Vacuum, Electric, 15-30-55 Gallon Dominator II, Mar2015.PDF
March 2015
Dominator II
15-30-55 Gallon Electric Vacuums
Dominator II Vacuum Configurations
Part
340.839105.15
15 Gal, Stainless Steel
340.39105.15
15 Gal, Stainless Steel
340.839105.30
30 Gal, Steel, Painted
340.39105.30
30 Gal, Steel, Painted
340.839105.55
55 Gal, Steel, Painted
340.39105.55
55 Gal, Steel, Painted
23031 Arroyo Vista ● Rancho Santa Margarita, CA 92688
949.858.7400 ● 949.858.9141 fax ● 800.337.2648 toll free
www.descomfg.com ● info@descomfg.com
ULPA Filtration and Wet/Dry Configurations
Tank
5-stage, w/ULPA
2-stage, (optional)
4-stage, w/ULPA
2-stage, (optional)
4-stage, w/ULPA
2-stage, (optional)
DESCO Mfg. Co., Inc.
Filtration
Pickup
Dry only
Wet or Dry
Dry only
Wet or Dry
Dry only
Wet or Dry
Advertisement
Table of Contents
Related Manuals for Desco Dominator II
Summary of Contents for Desco Dominator II
- Page 1 2-stage, (optional) Wet or Dry DESCO Mfg. Co., Inc. 23031 Arroyo Vista ● Rancho Santa Margarita, CA 92688 Industrial 949.858.7400 ● 949.858.9141 fax ● 800.337.2648 toll free Vacuums www.descomfg.com ● info@descomfg.com Vacuum, Electric, 15-30-55 Gallon Dominator II, Mar2015.PDF March 2015...
-
Page 2: Table Of Contents
Contents GENERAL INFORMATION ..................... 1 ........................1 NTRODUCTION ....................1 ECHNICAL PECIFICATIONS ........................1 CCESSORIES ........................2 ONSUMABLES ................3 ROVISIONING OF ACUUM ONSUMABLES ..............3 RITICAL ILTRATION AND ACUUM FFICIENCY ..............3 ILTRATION TAGES AND AINTENANCE TEPS SAFETY ........................... 4 ................... -
Page 3: General Information
DESCO Innovative Solutions 1.0 General Information Introduction This manual is furnished with each new DESCO Dominator II Vacuum. This provides the necessary operating and preventive maintenance instructions. Operators must read and understand this manual before operating or servicing this machine. -
Page 4: Consumables
55 gal – 340.805046 55 gal – 340.805046 Drum Liner (Optional) (Optional, dry only) 15 gal – 340.760598PKG (10 pk) 30 gal – n/a 55 gal – n/a Collection Bag Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 2 March 2015... -
Page 5: Provisioning Of Vacuum Consumables
Change when compromised: punctured, visibly contaminated or air flow is restricted. • Always change. Never clean and reuse. • When replaced, stages 1, 2, 3 and 4 should also be replaced. Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 3 March 2015... -
Page 6: Safety
Risk of explosion is possible if operated near explosive materials or vapors. Do not operate this equipment near flammable materials such as solvents, thinners, fuels or grain dust. Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 4 March 2015... -
Page 7: Warning - Reduce Risk Of Fire, Electric Shock, Or Injury
• Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present. • Connect to a properly grounded outlet only. See grounding instructions. SAVE THESE INSTRUCTIONS Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 5 March 2015... -
Page 8: Operating Instructions
The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. No adapter should be used with this appliance. Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 6 March 2015... -
Page 9: Operation
ULPA specification while, 2) maintaining rated vacuum air flow as measured in cubic feet per minute (CFM). The key factor affecting airflow is filter maintenance. Dirty filters reduce air flow. See paragraph 1.7 for filtration stages and maintenance steps. Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 7 March 2015... -
Page 10: Maintenance
Loss of vacuum air flow Filter(s) clogged Check & replace filters as needed. See paragraph 1.7 for further information. Other malfunction Contact your Desco representative for evaluation and repair assistance. Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 8 March 2015... -
Page 11: Schematics
Adapter Comp 55 Gallon 340.805037 Pkg Drum Liner 30 Gallon 340.805046 Pkg Drum Liner 55 Gallon 340.C90007-80 30 Gallon Drum 340.900015 55 Gallon Drum 340.900048 Dolly Cart Comp 30/55 Gallon Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 9 March 2015... -
Page 12: Lid Assembly - Ulpa Configuration
DESCO Innovative Solutions Lid Assembly – ULPA Configuration Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 10 March 2015... - Page 13 340.831484 GASKET 3.5 X 4.5 X .37 340.831626 GASKET 4 X 7.37 X .250 340.831652 SPACER-.264 X .344 X .750 ALM 340.832070 CONNECTOR 340.833237 STRAIN RELIEF W/ NUT Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 11 March 2015...
-
Page 14: Lid Assembly - Wet/Dry Configuration
DESCO Innovative Solutions Lid Assembly – Wet/Dry Configuration Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 12 March 2015... - Page 15 340.712667 Nut-Hex 1/4-20 SS Nyloc 340.711505 WSR-Flat 1/4 340.711803 Cotter Pin 340.760904 Snub Bushing 340.715069 Decal, Check Filters 340.740088 Vac Light 340.740116 Ground Wire 340.760212 Vac Sensor Tube Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 13 March 2015...
-
Page 16: Tank Assembly - 15 Gallon
DESCO Innovative Solutions Tank Assembly – 15 Gallon Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 14 March 2015... - Page 17 Washer-Wave .52 x .87 x .01 340.900040 Wheel 340.130032 Cap, Retainer 340.711591 Washer-Rubber 340.711505 Washer-Flat 340.711202 Blt-HH 1/4-20 X .50 340.711594 Washer-Flat .88 x .03 NI 340.390110 Intake Assy Aluminum Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 15 March 2015...
-
Page 18: Tank Assembly - 30 & 55 Gallon
Tank 30 Gal. PTD Less Handles 340.900015PTD Tank 55 Gal. PTD Less Handles 340.900047 Dump Valve 340.900031POL Handle, Tank Polished 340.711203 BLT, HH 1/4-20 x .62 340.711591 Washer, Rubber 340.711505 WSR, Flat 1/4 Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 16 March 2015... -
Page 19: Adapter Assembly
Rivet-Tube .19 x .28 NI PL 340.711503 WSR-Flat #10 340.711543 WSR-Helical #10 340.712638 Nut Hex 10/24 SS Nyloc 340.711502 WSR-Flat #8 340.711542 WSR-Helical #8 340.711304 Nut-Hex 8-32 STPL Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 17 March 2015... -
Page 20: Dolly Assembly
Grip, handle 340.900080 Spring, torsion RH 340.900081 Spring LH 340.711642 Rollpin 340.761050 Caster, rigid 5" 340.761049 Caster, swivel 5" 340.711545 WSR, helical Spr Loc 5/16 340.711379 Nut-Flanged Wizz 5/16-18 Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 18 March 2015... -
Page 21: Bag Assembly
DESCO Innovative Solutions Bag Assembly Part Description 340.760131 Molded bag ring 340.750097 Bag frame 340.805054 Cloth bag only 340.805058 Bag assy. complete Dominator II – 15-30-55 Gallon, ULPA and Wet/Dry Page 19 March 2015...
